Brueckner Power-Predry HDVB3 CF 20/2 Secador Têxtil

Manufacturer: Brueckner

Model: Power-Predry HDVB3 CF 20/2

Year of Manufacture: 2016

Application: Thermal treatment of flat textile webs

Working Width: 600 mm min. to 2000 mm max.

Web Speed: 2.5 m/min min. to 50 m/min max.

Drive Side: Right

Operating Side: Right

Number of Drying Fields: 2

Field Lengths

- Infeed conveyor belt: 2.4 m
- Infeed tower: 0.7 m
- Drying fields: 1.6 m (with 1 heating and ventilation section)
- Outfeed tower: 0.7 m

Ventilation and Heating

- Ventilation System: Classic-Flow with adjustable flaps for upper and lower airflow
- Heating Medium: Gas
- Circulation Temperature: 75 to 150 degrees C
- Exhaust Air Volume: max. 6000 m3/h

Electrical and Safety Data

- Operating Voltage: 400 V AC, plus/minus 5%, 50 Hz
- Control Voltage: 230 V AC, 50 Hz / 24 V DC
- Signal Voltage: 24 V DC
- Noise Emission: equivalent continuous sound level at workstation, A-weighted: 80 dB(A)
- Vibration: less than 2.5 m/s2

Included with the Machine

New radial air ventilation unit. Carrier platform. Additional accessories.

Condition

As new. The machine was only ever shown at a trade fair and has never been used in production.
