Perfuradoras radial CSEPEL RF 31/B

Offer 24456

Technical data:

- Drilling capacity in steel ST 60 approx. 60 mm
- Drilling capacity boring approx. 80 mm
- Thread cutting up to approx. M 40
- Drilling spindle holder MK 5
- Drilling spindle stroke 380 mm
- Radius min. / max. approx. 420 / 2000 mm
- Column diameter approx. 500 mm
- Stroke of the boom approx. 1350 mm
- Min. / max. distance:
- Spindle – base plate approx. 370 - 1700 mm
- Machined base plate clamping surface approx. 1100 - 2300 mm
- 12 spindle speeds 19 - 1900 rpm
- 9 feeds 0.09 - 0.75 m/rev
- Drilling spindle drive 400 V / 10 kW
- E - Central clamping
- Coolant device
- Space requirement approx. W 1400 x H 3400 x D 3600 mm
- Weight approx. 7500 kg

seller offer No. resale Lg.-Nr. 24456
