Lathe - cycle controled GILDEMEISTER N.E.F. Plus 500
máquinas para trabalhar metal / tornos
turning diameter:500 mmturning length:1000 mmcontrol:MANUAL PLUS Grundig total power requirement:24 kVAweight of the machine ca.:2650 kgdimensions of the machine ca.:2500 x 1750 x 1850 mmswing diameter over face slide:290 mmchuck:Ø max. 260 mmcross movement:260 mmspindle head:DIN 55027 Größe 8 ...
Fabricante: GILDEMEISTER
Modelo:N.E.F. Plus 500
Tipo de máquina: Lathe - cycle controled
Número do item: 169799078
Quantidade: 1
Data: 02.07.2026
Ano de fabricação: 1997
Localização: ab Lager Jena
Preço:
Máquina em estoque:Sim
Seller-item-No.:1106-DR274
turning diameter:500 mm
turning length:1000 mm
control:MANUAL PLUS Grundig
total power requirement:24 kVA
weight of the machine ca.:2650 kg
dimensions of the machine ca.:2500 x 1750 x 1850 mm
swing diameter over face slide:290 mm
chuck:Ø max. 260 mm
cross movement:260 mm
spindle head:DIN 55027 Größe 8
spindle bore diameter:70 mm
rapid travel - longitudinal/face:8 /6 m/min
spindle speeds::8 - 2800
tailstock travel:180 mm
tailstock quill taper MT:5
Documents:vorhanden
turning length:1000 mm
control:MANUAL PLUS Grundig
total power requirement:24 kVA
weight of the machine ca.:2650 kg
dimensions of the machine ca.:2500 x 1750 x 1850 mm
swing diameter over face slide:290 mm
chuck:Ø max. 260 mm
cross movement:260 mm
spindle head:DIN 55027 Größe 8
spindle bore diameter:70 mm
rapid travel - longitudinal/face:8 /6 m/min
spindle speeds::8 - 2800
tailstock travel:180 mm
tailstock quill taper MT:5
Documents:vorhanden
