correias transportadoras usadas para venda (664)

Correia transportadora com motor de engrenagem, largura 900mm comprimento 11 metros

Correia transportadora / transportador de acumulação / transportador de correia Altura de trabalho aprox. 850 mm, pode ser ajustada. Comprimento 1000 mm Largura aprox. 500 mm Equipado com fotocélula para parar o produto quando a máquina a jusante ocupada (contato para máquina pré e redesenhada disponível). Equipado com sua própria unidade e controles. A velocidade de transporte é infinitamente ajustável através do potenciómetro.

Correia transportadora / aba de correia / transportador de acumulação Altura de trabalho aprox. 850 mm, pode ser ajustada. Comprimento aprox. 600 mm Largura aprox. 450 mm Equipado com fotocélula para parar o produto quando a máquina a jusante ocupa. Equipado com sua própria unidade (atenção, atualmente sem controle próprio). Equipado com pega embutida para fácil remoção do produto.

Correia transportadora / aba de correia / transportador de acumulação Altura de trabalho aprox. 850 mm, pode ser ajustada. Comprimento aprox. 800 mm Largura aprox. 450 mm Equipado com fotocélula para parar o produto quando a máquina a jusante ocupa. Equipado com a função de aba de passagem -> as correias param assim que a aba é levantada. Equipado com sua própria unidade e controles. Velocidade de transporte fixa, sem conversor de frequência instalado. A máquina funciona perfeitamente. Novas correias transportadoras foram instaladas.

Correia de distribuição / Sistema de desertificação Para dividir um fluxo de telha em duas linhas de processamento Estado: revisado, com manutenção, totalmente funcional, pronto para uso

Correia transportadora/transportador de acumulação com aba de correia: - Com 3 drives próprios - Com 3 posições de espera - Com sistema de controlo próprio - Comprimento 600 + 600 + 800 mm = 2 m total - Velocidade máxima 90 m/min (ajustável via conversor de frequência) - Carga máxima 25kg/m - Altura máxima de empilhamento 500 mm Aplicação/Funcionalidade: - Permite que você atravesse rapidamente as linhas de produção sem ter que andar ao redor delas ou subir sobre elas com uma escada. A correia transportadora segura quando a aba da correia é levantada. - Se a máquina seguinte estiver ocupada, os pacotes/pacotes são parados em três posições de espera consecutivas até serem libertados pela máquina seguinte. - Contatos para liberação de sinal da máquina upstream e downstream com conexão plugue 24V

Correia transportadora Comprimento 3400 mm Eixo 3300 mm Largura da correia 230 mm Recolha pelo comprador Em bom estado de conservação, pronto a utilizar. Sujeito a alterações, erros, venda prévia! Peças de reposição por MATEC CH-4900 Langenthal/DE-79618 Rheinfelden MATEC sistema+technik GmbH Engenharia mecânica Eisenbahnstrasse 25 CH-4900 Langenthal/Suíça Telefone 0041 62 966 18 32 Fax 0041 62 966 21 12

Banda curva com uma velocidade de até 40 m/min. Largura de banda: máx.

Transportador de correia muito potente. Comprimento 7400 mm x largura 300 mm x altura do solo 800 mm (ajustável) Largura total 430 mm Motor da engrenagem de 1,5 kW Peso total 300 kg Pode suportar a carga ao longo de todo o comprimento de um saco de 25 kg.

Nós vendemos esta correia transportadora de 10 m de comprimento. Largura do transportador 50 cm, largura da correia 40 cm.

Lippert belt conveyor GF 3850-750-600 RA2498 Technical data: Conveying length (NL): 3850 mmFramework width (NB): 750 mmbelt width (GuB): 600 mmheight (BH): 105 mm support feet: optionally availableConveying speed (v m/s): adjustable up and down with frequency converter Drive: SEW gear motor Electrical data: 50Hz V380-500, kW 0.15 / 0.75 / S1Deflection roller (UR): Ø = 64 mmDrive drum (AT): Ø = 81 mmBelt: Type SNB-8EYear of construction: 2001 Optionally available:SupportsSide guides Prices net plus VAT from central warehouse Dr. Sonntag GmbH & Co KG, 97076 WürzburgFeatures: Construction year: 2001condition: good (used)Conveying length in mm: 3850Nominal / outside width in mm: 750Belt width in mm: 600Driven: YESEngine type: SEW Eurodrive Zentralantrieb mit SpannstationKW: 0,75/S1Ampere: 1,90Conveyor speed m / s: freely adjustablescope of delivery: without supports and side guidesFor ind ...

Lippert belt conveyor GF 13585-550-400 RA2497 Technical data: Conveying length (NL): 13585 mmFramework width (NB): 550 mmbelt width (GuB): 400 mmheight (BH): 105 mm support feet: optionally availableConveying speed (v m/s): 0.31Drive: SEW gear motor Electrical data: 50Hz V380-500, kW 0.75 / S1Deflection roller (UR): Ø = 81 mmDrive drum (AT): Ø = 81 mmYear of manufacture. 2001 Optionally available:SupportsSide guide one and both sidesFrequency converter for steples speed control Prices net plus VAT from central warehouse Dr. Sonntag GmbH & Co KG, 97076 WürzburgFeatures: Construction year: 2001condition: good (used)Conveying length in mm: 13585Nominal / outside width in mm: 550Belt width in mm: 400Driven: YESEngine type: SEW Eurodrive Zentralantrieb mit SpannstationKW: 0,75/S1Conveyor speed m / s: 0,31scope of delivery: without supports and side guidesFor individual, professional advice ...

Transnorm belt conveyor GF 4365-600-500RA2493Technical data:Conveyor length (NL): 4365 mmframe width (NB): 600 mm, 800 mm with motorbelt width (GuB): 500 mmOverall height (BH): 80 mm, 300 mm with motor support feet: optionalConveying speed (v m/s): contact usDrive: SEW gear motorElectrical data: 50Hz V380-500, kW 0,37 S1drive drum: Ø = 81 mmbelt return roller: Ø = 45 mmYear of manufacture: 2014 Optionally available:SupportsSide guide on one side and on both sidesFrequency converter for stepless speed changeCustomize length (longer/shorter)Prices net plus VAT ex central warehouse Dr. Sonntag GmbH & Co KG, 97076 Würzburg, GermanyFeatures: Construction year: 2014condition: good (used)Conveying length in mm: 4365Nominal / outside width in mm: 600Belt width in mm: 500Driven: YESEngine type: SEW Eurodrive Zentralantrieb mit SpannstationKW: 0,37/S1Ampere: 1,30Conveyor speed m / s: bitte Kont ...

Transnorm Rising falling Incline belt conveyor with leading belt GF 800+4650+560-600-500RA2494Technical data:Conveyor length (NL): 6100 mm ( 560 mm arch + 4650 mm riser segment + 800 mm leading )frame width (NB): 600 mm, 700 mm with motorbelt width (GuB): 500 mmOverall height (BH): 80 mm, 430 mm with motor Angle: freely adjustable between 0 and 15°Supporting feet: optionally availableConveying speed (v m/s): contact usDrive: SEW gear motor, R17DT71D4/BMG/THElectrical data: 50Hz V380-500, kW 0,37 S1Drive drum: Ø = 81 mmBelt return roller: Ø = 81 mmOptionally available:SupportsSide guide on one side and on both sidesFrequency converter for stepless speed changeAdjust length (longer/shorter)Prices net plus VAT ex central warehouse Dr. Sonntag GmbH & Co KG, 97076 Würzburg, GermanyFeatures: Construction year: 2008condition: good (used)Conveying length in mm: 6100 ( 800 + 4650 + 560 )Nomin ...

Lippert belt conveyor GF 5030-570-450RA2496Technical data:Conveyor length (NL): 5030 mmframe width (NB): 570 mm, 770 mm with motorbelt width (GuB): 450 mmOverall height (BH): 130 mmSupporting feet: optionally availableConveying speed (v m/s): Frequency converter for stepless speed controllDrive: SEW gear motor,Electrical data: 50Hz V380-500, kW 1,1 S1Drive drum: Ø = 81 mmBelt return roller: Ø = 81 mmOptionally available:SupportsSide guide on one side and on both sidesAdjust length (longer/shorter)Prices net plus VAT ex central warehouse Dr. Sonntag GmbH & Co KG, 97076 Würzburg, GermanyFeatures: condition: good (used)Conveying length in mm: 5030Nominal / outside width in mm: 570Belt width in mm: 450Driven: YESEngine type: SEW Movi-MotKW: 1,1/S1Conveyor speed m / s: freely adjustablescope of delivery: without supports and side guidesFor individual, professional advice, simply contact us ...

Lippert belt conveyor GF 5300-570-450RA2495Technical data:Conveyor length (NL): 5300 mmframe width (NB): 570 mm, 770 mm with motorbelt width (GuB): 450 mmOverall height (BH): 130 mmSupporting feet: optionally availableConveying speed (v m/s): Frequency converter for stepless speed controllDrive: SEW gear motor,Electrical data: 50Hz V380-500, kW 1,1 S1Drive drum: Ø = 81 mmBelt return roller: Ø = 81 mmOptionally available:SupportsSide guide on one side and on both sidesAdjust length (longer/shorter)Prices net plus VAT ex central warehouse Dr. Sonntag GmbH & Co KG, 97076 Würzburg, GermanyFeatures: condition: good (used)Conveying length in mm: 5300Nominal / outside width in mm: 570Belt width in mm: 450Driven: YESEngine type: SEW Movi-MotKW: 1,1/S1Conveyor speed m / s: freely adjustablescope of delivery: without supports and side guidesFor individual, professional advice, simply contact us ...

Conveyor belts for PET bottles, with 1-lane hinged belt chain and 6 lanes. Capacity: 24,000 bottles/hour, Additional title: Free bottle conveyors, Capacity: 24000 b/h, Free bottle transport approx.: 30 m, 90° bottle transport curves: 1 piece 1-chain conveyor, 180° bottle transport curve: 1 piece 6-chain conveyor, Formats: PET-bottles in 0,5 l, 1,0 l, 1,5 l, Operation / Control: controlbox / Siemens S7-300, Material: mainly stainless steel, Position: free-standing, Features: Conveyor frames, deflection stations, drives, frequency controls, electrical switchgear, automatic belt lubrication

Lippert belt conveyor GF 5550-570-450RA2488Technical data:Conveyor length (NL): 5550 mmframe width (NB): 570 mm, 770 mm with motorbelt width (GuB): 450 mmOverall height (BH): 130 mmSupporting feet: optionally availableConveying speed (v m/s): Frequency converter for stepless speed controllDrive: SEW gear motor,Electrical data: 50Hz V380-500, kW 1,1 S1Drive drum: Ø = 81 mmBelt return roller: Ø = 81 mmOptionally available:SupportsSide guide on one side and on both sidesAdjust length (longer/shorter)Prices net plus VAT ex central warehouse Dr. Sonntag GmbH & Co KG, 97076 Würzburg, GermanyFeatures: condition: good (used)Conveying length in mm: 5550Nominal / outside width in mm: 570Belt width in mm: 450Driven: YESEngine type: SEW Movi-MotKW: 1,1/S1Conveyor speed m / s: freely adjustablescope of delivery: without supports and side guidesFor individual, professional advice, simply contact us ...

Lippert belt conveyor GF 4585-570-450RA2487Technical data:Conveyor length (NL): 4585 mmframe width (NB): 570 mm, 770 mm with motorbelt width (GuB): 450 mmOverall height (BH): 130 mmSupporting feet: optionally availableConveying speed (v m/s): Frequency converter for stepless speed controllDrive: SEW gear motor,Electrical data: 50Hz V380-500, kW 1,1 S1Drive drum: Ø = 81 mmBelt return roller: Ø = 81 mmOptionally available:SupportsSide guide on one side and on both sidesAdjust length (longer/shorter)Prices net plus VAT ex central warehouse Dr. Sonntag GmbH & Co KG, 97076 Würzburg, GermanyFeatures: condition: good (used)Conveying length in mm: 4585Nominal / outside width in mm: 570Belt width in mm: 450Driven: YESEngine type: SEW Movi-MotKW: 1,1/S1Conveyor speed m / s: freely adjustablescope of delivery: without supports and side guidesFor individual, professional advice, simply contact us ...

Lippert belt conveyor GF 3860-570-450RA2486Technical data:Conveyor length (NL): 3860 mmframe width (NB): 570 mm, 770 mm with motorbelt width (GuB): 450 mmOverall height (BH): 130 mmSupporting feet: optionally availableConveying speed (v m/s): Frequency converter for stepless speed controllDrive: SEW gear motor,Electrical data: 50Hz V380-500, kW 0,37 S1Drive drum: Ø = 81 mmBelt return roller: Ø = 81 mmOptionally available:SupportsSide guide on one side and on both sidesAdjust length (longer/shorter)Prices net plus VAT ex central warehouse Dr. Sonntag GmbH & Co KG, 97076 Würzburg, GermanyFeatures: condition: good (used)Conveying length in mm: 3860Nominal / outside width in mm: 570Belt width in mm: 450Driven: YESEngine type: SEW Movi-MotKW: 0,37/S1Conveyor speed m / s: freely adjustablescope of delivery: without supports and side guidesFor individual, professional advice, simply contact  ...

Lippert belt conveyor GF 10270-570-450RA2489Technical data:Conveyor length (NL): 10270 mmFrame width (NB): approx. 570 mmBelt width (GuB): 450 mmOverall height (BH): 130 mmSupport feet optionally availableConveyor speed (v m/s): please contact usDrive: SEW geared motor, R37 DRE80M4/TH/ZElectrical data: 50Hz V380-500, kW 0.75 / S1Return pulley (UR): Ø = 81 mmDrive drum (AT): Ø = 81 mmOptionally available:SupportsSide guidesFrequency converter for stepless speed controlPrices net plus VAT ex central warehouse Dr. Sonntag GmbH & Co KG, 97076 WürzburgFeatures: condition: good (used)Conveying length in mm: 19270Nominal / outside width in mm: 570Belt width in mm: 450Driven: YESEngine type: SEW EurodriveKW: 0,75/S1Conveyor speed m / s: bitte Kontaktierenscope of delivery: without supports and side guidesFür eine individuelle, fachmännische Beratung setzten Sie sich einfach mit uns in Verbi ...

Lippert Belt Conveyor Riser with Arch and Straight GF 6005-650-500 RA2485 Technical data: Conveying length (NL): 6005 mm (ascending conveyor 2420 mm + arch 500 mm + upper straight 3085 mm)Framework width (NB): 650 mmbelt width (GuB): 500 mmheight (BH): 105 mm support feet: optionally availableConveying speed (v m/s): adjustable up and down with frequency converterDrive: SEW gear motor S37 DT80N4/MM07/BW1Electrical data: 50Hz V380-500, kW 0.15 / 0.75 / S1Deflection roller (UR): Ø = 34 mmDrive drum (AT): Ø = 81 mmBelt: Type HSL 8 EYear of construction: 2001Slope / Slope: adjustable Optionally available:SupportsSide guides Prices net plus VAT from central warehouse Dr. Sonntag GmbH & Co KG, 97076 WürzburgFeatures: Construction year: 2001condition: good (used)Conveying length in mm: 6005 ( 2420 + 500 + 3085 )Nominal / outside width in mm: 650Belt width in mm: 500Driven: YESEngine type: SE ...

Lippert belt conveyor GF 1715-650-500 RA2484 Technical data: Conveying length (NL): 1715 mmFramework width (NB): 650 mmbelt width (GuB): 500 mmheight (BH): 105 mm support feet: optionally availableConveying speed (v m/s): adjustable up and down with frequency converter Drive: SEW gear motor R17 DT71D4/MM03/BW1Electrical data: 50Hz V380-500, kW 0.075 / 0.37 / S1Deflection roller (UR): Ø = 34 mmDrive drum (AT): Ø = 81 mmBelt: Type SNB-8EYear of construction: 2001 Optionally available:SupportsSide guides Prices plus VAT from central warehouse Dr. Sonntag GmbH & Co KG, 97076 WürzburgFeatures: Construction year: 2001condition: good (used)Conveying length in mm: 1715Nominal / outside width in mm: 650Belt width in mm: 500Driven: YESEngine type: SEW Eurodrive Zentralantrieb mit SpannstationKW: 0,37/S1Conveyor speed m / s: freely adjustablescope of delivery: without supports and side guidesFor ...

Transnorm conveyor belt with leading belt GF 4050+4890-600-500RA2051Technical data:Conveyor length (NL): 8940 mm (4050 mm + 4890 mm)frame width (NB): 600 mm, 700 mm with motorbelt width (GuB): 500 mmOverall height (BH): 80 mm, 430 mm with motor Supporting feet: optionally availableConveying speed (v m/s): Contact us and we will try to meet your preferred conveying speed.Drive: SEW gear motor and overdrive from belt one to belt twoElectrical data: 50Hz V380-500, kW 0,75 S1Drive drum: Ø = 81 mmBelt return roller: Ø = 81 mmOptionally available:SupportsSide guide on one side and on both sidesFrequency converter for stepless speed changeAdjust length (longer/shorter)Prices net plus VAT ex central warehouse Dr. Sonntag GmbH & Co KG, 97076 Würzburg, GermanyFeatures: condition: good (used)Conveying length in mm: 8940 ( 4050 + 4890 )Nominal / outside width in mm: 600Belt width in mm: 500Driven ...

Transnorm conveyor belt with leading belt GF 4070+4430 -600-500RA2052Technical data:Conveyor length (NL): 8500 mm (4070 mm + 4430 mm)frame width (NB): 600 mm, 700 mm with motorbelt width (GuB): 500 mmOverall height (BH): 80 mm, 430 mm with motor Supporting feet: optionally availableConveying speed (v m/s): Contact us and we will try to meet your preferred conveying speed.Drive: SEW gear motor and overdrive from belt one to belt twoElectrical data: 50Hz V380-500, kW 0,75 S1Drive drum: Ø = 81 mmBelt return roller: Ø = 81 mmOptionally available:SupportsSide guide on one side and on both sidesFrequency converter for stepless speed changeAdjust length (longer/shorter)Prices net plus VAT ex central warehouse Dr. Sonntag GmbH & Co KG, 97076 Würzburg, GermanyFeatures: condition: good (used)Conveying length in mm: 8500 ( 4070 + 4430 )Nominal / outside width in mm: 600Belt width in mm: 500Drive ...

Lippert belt conveyor GF 1810-650-500 RA1438 The Lippert conveyor belt is from 2001 and in good (used) condition. The belt conveyor has a SEW motor with MOVIMOT frequency inverter to control the speed. Lateral guides and/or light barriers can be installed on request at extra cost. Supports are not included in the delivery. These are optionally available on request. The pictures of the conveyor system shown here were taken in a logistics center while still installed. Technical data: Conveying length (NL): 1810 mmFramework width (NB): 650 mmbelt width (GuB): 500 mmheight (BH): 105 mm support feet: optionally availableConveying speed (v m/s): adjustable up and down with frequency converter Drive: SEW gear motor R17 DT71D4/MM03/BW1Electrical data: 50Hz V380-500, kW 0.075 / 0.37 / S1Deflection roller (UR): Ø = 34 mmDrive drum (AT): Ø = 81 mmBelt: Type SNB-8EYear of construction: 2001 Optio ...

Rotary table disc conveyor 1700-1600-Ø1500 with ejector 1330-100RA2025Technical data rotary table:Length table: 1700 mmwidth table: 1600 mmdiameter turntable: 1500 mmOverall height: 100 mmAdjusted table height: 790 mm, can be moved down to 590 mmElectrical data SEW motor: 380-415 V, 0,37 kWElectrical data drum motor: 24VTechnical data diverter:Length/ belt length: 1330 mmbelt width: 100 mmoverall height: 840 mmElectrical data: 380-415 V, 0,25 kWIncluded in delivery:Turntable with feetSide guideEjector with standOptional:Light barriers24V power supply for drum motorcontrol cabinet/controlPrices net plus VAT ex central warehouse Dr. Sonntag GmbH & Co KG, 97076 Würzburg, GermanyTranslated with

Transnorm conveyor belt GF 1500-600-500RA2070Technical data:Conveyor length (NL): 1500 mm frame width (NB): 600 mm, 700 mm with motorbelt width (GuB): 500 mmOverall height (BH): 80 mm, 430 mm with motor Supporting feet: optionally availableConveying speed (v m/s): Contact us and we will try to meet your preferred conveying speed.Drive: SEW gear motorElectrical data: 50Hz V380-500, kW 0,37 S1Drive drum: Ø = 81 mmBelt return roller: Ø = 81 mmOptionally available:SupportsSide guide on one side and on both sidesFrequency converter for stepless speed changeAdjust length (longer/shorter)Prices net plus VAT ex central warehouse Dr. Sonntag GmbH & Co KG, 97076 Würzburg, GermanyFeatures: Construction year: 1998condition: good (used)Conveying length in mm: 1500Nominal / outside width in mm: 600Belt width in mm: 500Driven: YESEngine type: SEW Eurodrive Zentralantrieb mit SpannstationKW: 0,37/S1C ...

Transnorm conveyor belt GF 15000-600-500RA2067Technical data:Conveyor length (NL): 15000 mm frame width (NB): 600 mm, 700 mm with motorbelt width (GuB): 500 mmOverall height (BH): 80 mm, 430 mm with motor Supporting feet: optionally availableConveying speed (v m/s): Contact us and we will try to meet your preferred conveying speed.Drive: SEW gear motor Electrical data: 50Hz V380-500, kW 1,1 S1Drive drum: Ø = 81 mmBelt return roller: Ø = 81 mmOptionally available:SupportsSide guide on one side and on both sidesFrequency converter for stepless speed changeAdjust length (longer/shorter)Prices net plus VAT ex central warehouse Dr. Sonntag GmbH & Co KG, 97076 Würzburg, GermanyFeatures: Construction year: 1998condition: good (used)Conveying length in mm: 15000Nominal / outside width in mm: 600Belt width in mm: 500Driven: YESEngine type: SEW Eurodrive Zentralantrieb mit SpannstationKW: 1,1/S ...

Transnorm conveyor belt GF 1250-600-500RA2096Technical data:Conveyor length (NL): 1250mm frame width (NB): 600 mm, 700 mm with motorbelt width (GuB): 500 mmOverall height (BH): 80 mm, 430 mm with motor Supporting feet: optionally availableConveying speed (v m/s): Contact us and we will try to meet your preferred conveying speed.Drive: SEW gear motorElectrical data: 50Hz V380-500, kW 0,37 S1Drive drum: Ø = 81 mmBelt return roller: Ø = 81 mmOptionally available:SupportsSide guide on one side and on both sidesFrequency converter for stepless speed changeAdjust length (longer/shorter)Prices net plus VAT ex central warehouse Dr. Sonntag GmbH & Co KG, 97076 Würzburg, GermanyFeatures: Construction year: 1998condition: good (used)Conveying length in mm: 1250Nominal / outside width in mm: 600Belt width in mm: 500Driven: YESEngine type: SEW Eurodrive Zentralantrieb mit SpannstationKW: 0,37/S1Co ...
