143 BÜRKLE máquina utilizada para venda

Manufacturer: Bürkle , Type: Tansportband, Working length mm: 2500, Working widht mm: 1300, Total hight mm: 980, Belt width: 1300, Own controller: no, Engine power kW: ca.0,5, Feeding speed min-max m/min: 10-30, Feeding speed continous adjustable: über Regler möglich, Working hight adjustable mm: yes, Movable: no,

Spare roller: SLC, Bürkle: yes, Stahlkerndurchmesser ca. mm: 186, Total lenght mm: 1300,

Máquina de enchimento Bürkle CASC 1300

- Manufacturer: Bürkle - Type: SLC - Year of manufacture: 2001 - Right -hand operation - For single -sided application of lacquer - Oscillating application roller squeegee Technical data: - Maximum working width: 1300 mm - Conveyor belt width: 1270 mm - Workpiece thickness 3 - 120 mm - Installation length: ~ 800 mm - Width: ~ 2,800 mm - 1 piece, rubberized application roller, approx. D: 238 mm - Application roller Shore hardness: 45 (can be changed) - 1 piece, chrome -plated metering roller, D: 174 mm - 1 piece, counterpressure roller, D: 186 mm - Transport speed, adjustable from approx. 6 - 30 m/min. - Working height ~ 900 mm - Passage height approx. 3 - 80 mm - Compressed air 6 bar, G1/4 inch, approx. 50 NL/min. - Operating voltage 400 V, 50 Hz, 3 phases - Total connected load approx. 2 kW - With control cabinet - Weight approx. 1,400 kg - Location: in wareh ...

- Producer Bürkle - Type CASC 1400 - Year of construction 2001 - Working width 1350 mm - Working height 900 + - 20 mm - Part height ~ 5 - 100 mm - Operating side, right - Roller for putty EPDM, 240 mm - Qick changes system for roller - Metering roller 198 mm - Smoothing roller hard chromed 240 mm - Belt transport system - Length ~ 1.450 mm - Width ~ 2980 mm - Mobile, with flange of wheel - Feed speed 5 - 25 m/min - With switch cabinet - Voltage / HZ 400 / 50 - Location, on stock - Commodity code 84242000 - Voltage fluctuation max. +/ - 5 %

Printing machine for non -synchronized printing of wood grains or other designs from above on flat workpieces in one -colour printing, suitable for aqueous and UV printing inks. - Type: SLDR 1300 - Year of manufacture: 2008 - Operating side: right - Workpiece width: 1.250mm - Min. workpiece length: 350mm (300mm) - Workpiece height: ~ 3 -100mm - Suitable for printing ink, water -soluble and UV printing inks Transport system: - Conveyor belt width: 1,230mm - Max. Production speed: 10m/min. - Feed speed: 8 -25m/min. - Rubber coating 60Shore (6By1) - Diameter 186mm Application unit: - Rubber coating 50Shore (5by1) - Diameter: 238mm - Engraving cylinder, diameter: 174mm - Separate, infinitely variable FU direct drive for engraving cylinder and application roller. Engraving roller: - Diameter - circumferential speed Machine dimensions: - Installation length: 800mm - Workin ...

- Manufacturer: Bürkle - Type: SLC - Year of manufacture: 2001 - Operating side: left - For single -sided application of lacquer - Oscillating application roller squeegee Technical data: - Maximum working width: 1.300 mm - Minimum workpiece length: 350 mm - Maximum workpiece weight: 250 kg - Conveyor belt width 1.270 mm - Workpiece thickness 3 - 100 mm - Machine length: 800 mm - Machine width: 3.200 mm - Application roller, rubberized, EPDM approx. D: 238 mm - Application roller Shore hardness: 45 (can be changed) - Metering roller, chrome -plated, D: 174 mm - Counterpressure roller, rubberized, D: 186 mm - Conveyor speed, adjustable from approx. 8 -25 m/min. - Working height ~ 900 mm + - 30 mm - Clearance height approx. 3 - 80 mm - Compressed air 6 bar, G1/4 inch, approx. 50 NL/min. - Operating voltage 400 V, 50 Hz, 3 phases - Total connected load approx. 5.5 ...

Aplicador de cola Bürkle DAK 1400 do primeiro proprietário em estado impecável: – Máquina para aplicação de cola num e em ambos os lados – Aplicação de cola no topo e na base (máquina de 4 roletes) – Design industrial estável – Acionamento direto dos rolos aplicadores – Acionamento direto separado dos rolos de dosagem – Ajuste da lacuna de dosagem com ecrã digital mecânico – Ajuste de altura com ecrã digital mecânico – Paralelismo de rolos ajustável por embraiagem deslizante – Alimentação de entrada com 3 rolos acionados para comprimento de peça mínimo 350 mm – Bico com 3 discos de faca acionados para comprimento mínimo de 350 mm – Acionamento controlado por frequência 6-30 m/min – Ajuste motorizado de altura por botão – Largura de trabalho máx. 1400 mm – Altura da passagem até 80 mm – Altura de trabalho acima d ...
