12 BODOR máquina utilizada para venda

table length: 3048 mm table width: 1524 mm burner heads: 1 Control: CNC workpiece weight: 1095 kg traversing speed: 180 m/min weight: 4150 kg dimensions of the machine ca.: 9392 x 2232 x 2307 mm Laser cutting system with automatic shuttle table configuration 1. Bodor Power 12kW laser source 2. Bodor Genius laser cutting head with autofocus 3. Bodor Thinker 3.0 control system 4. mortise-and-tenon nameplate welded segmented bed 5. stretched aluminum gantry 6. bodor servo motor and driver 7. bodor rack and pinion 8. one-click processing 9. bodor lightning perforation technology 10. expert database for high-speed cutting 11. automatic adjustment of cutting gas pressure 12. open door protection 13. alarm function for cutting malfunction 14. ergonomic remote control (Bodor Mango®) 15. active anti-collision function 16. intelligent anti-shake 17. gas-saving continuous flow nozzle 18. intelli ...

table length: Rohmateriallänge 6500 mm table width: Rohrdurchmesser max. 230 mm burner heads: 1 Control: CNC workpiece weight: 300 kg traversing speed: 91 m/min weight: 5750 kg dimensions of the machine ca.: 12900 x 2370 x 2650 mm Tube laser with T-loader Configuration 1. Bodor Power laser source 6 KW 2. Bodor Genius laser cutting head with autofocus 3. Bodor Thinker 3.0 control system 4. Pneumatic chuck 5. Adaptive adjustment of jaw clamping force 6. Follow-up servo blanking clamp 7. Support for composite clamping rollers 8. Active collision avoidance 9. Automatic tube inspection 10. Automatic tube edge detection and positioning 11. Automatic adjustment of cutting gas 12. Laser cutting process database 13. Air-saving continuous jet nozzle 14. Intelligent maintenance reminder 15. WIFI internet connection 16. Water cooler 17. Extraction system 18. Wear parts set 19. Auxiliary feeding dev ...

table length: 3048 mm table width: 1524 mm burner heads: 1 Control: CNC workpiece weight: 1450 kg traversing speed: 200 m/min weight: 5010 kg dimensions of the machine ca.: 9450 x 2240 x 2520 mm Laser cutting machine with automatic shuttle table Configuration 1. BodorPower laser source 12 kW 2. BodorGenius laser cutting head with autofocus 3. BodorThinker 3.0 control system 4. Bed made of tenon and mortise structure 5. Stretched aluminum portal 6. One-click fully automatic processing 7. Automatic layout of residual material 8. Edge detection and automatic zeroing of the focal length through intelligent detection 9. Bodor Lightning perforation technology 10. 21.5-inch monitor with touch function 11. Intelligent control of gas pressure 12. Automatic adjustment of cutting gas pressure 13. Bodor Mango® ergonomic remote control 14. Active anti-collision function 15. Intelligent vibration pro ...

table length: 3000 mm table width: 1500 mm burner heads: 1 Control: CNC workpiece weight: 900 kg traversing speed: 91 m/min dimensions of the machine ca.: 5562 x 2270 x 2388 mm Laser cutting machine with manual shuttle table Configuration 1. BodorPower laser source 6 kW 2. Bodor Genius laser cutting head with autofocus 3. Bodor Thinker 3.0 control system 4. Bed made of tenon and mortise structure 5. Bodor servo motor and driver 6. Nitrogen control valve 7. Bodor Lightning perforation technology 8. Automatic layout of residual material 9. 21.5-inch monitor with touch function 10. Automatic adjustment of cutting gas pressure 11. Active anti-collision function 12. Intelligent vibration protection 13. Anti-burn mineral casting 14. Bodor Mango® Ergonomic Remote Control 15. Gas-saving nozzles with stable flow 16. Intelligent maintenance reminder 17. WIFI internet connection 18. Water cooling  ...

table length: 3000 mm table width: 1500 mm burner heads: 1 Control: CNC workpiece weight: 900 kg traversing speed: 91 m/min weight: 4980 kg dimensions of the machine ca.: 5562 x 2270 x 2388 mm Laser cutting machine with manual shuttle table Configuration 1. BodorPower laser source 12 kW 2. Bodor Genius laser cutting head with autofocus 3. Bodor Thinker 3.0 control system 4. Bed made of tenon and mortise structure 5. Bodor servo motor and driver 6. Nitrogen control valve 7. Bodor Lightning perforation technology 8. Automatic layout of residual material 9. 21.5-inch monitor with touch function 10. Automatic adjustment of cutting gas pressure 11. Active anti-collision function 12. Intelligent vibration protection 13. Anti-burn mineral casting 14. Bodor Mango® Ergonomic Remote Control 15. Gas-saving nozzles with stable flow 16. Intelligent maintenance reminder 17. WIFI internet connection 1 ...

Número : 6794 Tipo: 3015 Produtor: BODOR Criado: 2023 Parâmetros: Potência do laser: 12 kW Comprimento da mesa de trabalho: 3000 mm Largura da mesa de trabalho: 1500 mm Peso da máquina: 9000 kg

table length: 3048 mm table width: 1524 mm burner heads: 1 Control: CNC workpiece weight: 911 kg traversing speed: 180 m/min weight: 4150 kg dimensions of the machine ca.: 9392 x 2232 x 2307 mm CUTTING CAPACITY: STRUCTURAL STEEL 25 mm STAINLESS STEEL 15 mm ALUMINUM 12mm BRASS 8mm COPPER 8mm MACHINE AXES: 4 axes [X, Y, Z, U ] CUTTING HEAD: Precitec ProCutter CAD/CAM SOFTWARE: LANTEK EXPERT CUT 4 servo motors for all axial movements CNC CONTROL PANEL 15 5” touch screen IPG laser sources and coolers integrated Precitec Procutter cutting head system AIR FILTER (compressed air filter) CONVEYOR BELT under cutting area Closed housing and specially coated filter protection windows LOADING / DISCHARGING SYSTEM PROPORTIONAL GAS AND PIPE SYSTEM The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

table length: 4000 mm table width: 2000 mm burner heads: 1 Control: CNC workpiece weight: 2510 kg traversing speed: 200 m/min dimensions of the machine ca.: 11599 x 3380 x 2718 mm CUTTING CAPACITY: STRUCTURAL STEEL 25 mm STAINLESS STEEL 15 mm ALUMINUM 12mm BRASS 8mm COPPER 8mm MACHINE AXES: 4 axes [X, Y, Z, U ] CUTTING HEAD: Precitec ProCutter CAD/CAM SOFTWARE: LANTEK EXPERT CUT 4 servo motors for all axial movements CNC CONTROL PANEL 15 5” touch screen IPG laser sources and coolers integrated Precitec Procutter cutting head system AIR FILTER (compressed air filter) CONVEYOR BELT under cutting area Closed housing and specially coated filter protection windows LOADING / DISCHARGING SYSTEM PROPORTIONAL GAS AND PIPE SYSTEM The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

This 3-axis Bodor P3015 was manufactured in 2019 and is a robust fiber laser cutting machine. It features a 1.5 kW fiber laser, capable of cutting a variety of materials including carbon steel and aluminum, with a cutting area of 3000 mm x 1500 mm. It includes a Bodor CNC control system and an exchange table. If you are looking to get high-quality sheet metal cutting capabilities consider the Bodor P3015 machine we have for sale. Contact us for more information.

O laser de fibra BODOR P3015 foi construído em 2020 na China pela Jinan Bodor CNC Machine Co., Ltd. Distinguida pela utilização da tecnologia mais avançada disponível no mercado, a máquina é a escolha perfeita mesmo para os desafios mais intensos. Permite a maquinação precisa de chapas metálicas com comprimento máximo de 3000 mm e largura de 1500 mm através de um feixe de fibra ótica estável de 2 kW. Durante o processo de usinagem, a cabeça de corte com autofoco ajusta automaticamente a posição focal dependendo da espessura do material. Os bocais, por sua vez, são automaticamente alterados, calibrados e limpos para garantir uma operação fiável ao longo de toda a sua vida útil. Tudo isto é completado pelo sistema anti-colisão 360 desenvolvido pela BODOR, que prevê e deteta quaisquer obstáculos. O laser de fibra BODOR P 3015 é também extremamente fácil de ...

O laser de tubos e fibra de perfil BODOR T230 foi construído em 2020 na China pela Jinan Bodor CNC Machine Co., Ltd. A máquina, que se distingue pela utilização da tecnologia de ponta disponível no mercado, é a melhor escolha mesmo para as tarefas mais exigentes em muitos setores. Permite o corte preciso de tubos e perfis com secção transversal quadrada através de um feixe estável de fibra ótica de 1 kW. Durante o processo de maquinação, a cabeça de corte com função de autofoco armazena os valores das distâncias focais no sistema de controlo separadamente para cada tipo de material. A tecnologia inteligente desenvolvida pela BODOR, por sua vez, reduz o tempo de perfuração em 90%, independentemente da espessura e do tipo de material. Todas estas soluções reduzem o consumo de energia e a quantidade de gás reduzido ao mínimo. A máquina de corte a laser de tubos T2 ...

Tubo laser Bodor T230 Potência laser: 1 kW Tubos redondos de 20 mm a 230 mm Tubos quadrados 20 x 20 mm a 160 x 160 mm Corte de conjuntos soldados Ano de construção 2017, mas instalado e posto em funcionamento em 2018
