47 GIARDINA máquina utilizada para venda

Manufacturer: Giardina UV Walzenbeschichtungsanlage UV, Type: GS 01 FWM + ST/SPC 302/12, Year: 2002, Control: Siemens, Work piece width min-max mm: 85-250, Min.-max. workpiece length in mm: 1600, Min.-max. workpiece height in mm: 8-30, Working widht max mm: 300, Operating side: links, Working height: 950, regelbarer Direktantrieb für Auftragswalze: yes, Auftragswalzengeschwindigkeit m/min.: 60, Gummierte Auftragswalze mm: yes, Direktantrieb Dosierwalze: yes, Verchromte Dosierwalze mm: yes, Metering roller drive m/min: 20-30, Glättwalzengeschwindigkeit ca. m/min.: 10-40, Widht of roller coater: 320, rbakel: yes, Feeding speed min/max: 60, Pump system: yes, UV dryer: 12 Lampen, Ein Mann Bedienung: yes, Vor und Rücklauf: yes, kW power 1 lamp: ca.2,5, Adjustable: yes, Position of lamps: gerade, Conveyor lenght mm: 4500, FREE TEXT: Giesskopf zum Aufgiessen von UV-Lacken Kantenbürsten rech ...

Manufacturer: Giardina , Type: Wasser UV Spritzstrasse, Year: 2005, Maschinensteuerung übergeordnet: yes, Work piece width min-max mm: 900, Work piece hight min-max mm: 10-100, Work piece length min-max mm: 4500, Feeding speed m/min: 2-6, UV track: yes, Wasserlackstrasse + UV: yes, Inlet conveyor: 2500, Dedusters: yes, Spraying machine: Dualtech 301, 2 Lackkreise: yes, Belt conveyor: yes, Einlaufrollgang: yes, Angular transfer: yes, Microwellentrocknung: yes, Jet drier mm: yes, Heating medium hot water: yes, Outlet roller conveyor mm: yes, UV Trockner Lampen: 2 von oben 1 von unten, Wattleistung: 120, Adjustable: yes, Outlet transport mm: 4500, Jet drier: 1, Inlet conveyor: 2500, Spraying heads - total: 4, work piece detection: yes, Conveyour system: Rolle-Band, Spraying stations: 2, Fast exchange system spray gun carrier: yes, Laquer system - airmix: yes, Laquer recharging: yes, by rol ...

Manufacturer: Giardina, Type: G02/05, Year: 2008, Control: Giardina, Work piece width min-max mm: 1300, Min.-max. workpiece length in mm: 150, Min.-max. workpiece height in mm: 3-120, Operating side: links, Working height: 900, Lackauftragseinheiten: 1, Vorschub Transport m/min min - max: 7-20, kW - Leistung Transport: ca.1,2, Auftragswalzengeschwindigkeit m/min min-max: 720, Gummierte Auftragswalze(n): yes, Durchmesser Auftragswalze mm: ca.240, Reverse und Gegenlauf: yes, kW - Leistung Dosierwalze: yes, rbakel: yes, Roller lift out: yes, Hight adjustment by engine: yes, Type of transportation: band, Pump system: membrane, Carriage: yes, Electronic control board: yes, Strassenbetrieb: möglich, Einbaulänge Auftragsmaschine mm: ca.900, Carriage: yes, Year :2008

Manufacturer: Spritzstrasse Giradina, Type: Frontenlackieranlage, Year: 2005, Work piece width min-max mm: 10-1300, Work piece hight min-max mm: 5-60, Work piece length min-max mm: 100, Geamtlänge Meter: ca.30, Feeding speed m/min: 2,5-5, UV-Strasse: yes, Wasserlackstrasse: yes, Conveyor belts: 2, Schleifmaschinen: kein, Enstaubungsmaschinen: 1, Spraying machine: 1, UV dryer: yes, Anzahl Lampen: 3, Jet drier: 1 MOS Trockner 1 Düsentrockner, Outlet conveyor: yes, wast cleaning: yes, work piece detection: yes, Spraying heads - total: 8, work piece detection: yes, Conveyour system: Band, Fast exchange system spray gun carrier: yes, Laquer circles: 2, Laquer system - airless: yes, Laquer system - airmix: yes, Laquer recharging: yes, by rollers: yes, by scraper: yes, Water cleaning: no, Dry exhauster: yes, Jet drier length in mm: 10000+17000, Outlet conveyor: yes, FREE TEXT: Inkl. Reinraumk ...

Manufacturer: Giardina, Type: Lackwalze, Year: 1996, Control: Programm, Work piece width min-max mm: 1300, Min.-max. workpiece length in mm: 250, Min.-max. workpiece height in mm: 6-120, Working widht max mm: 1350, Operating side: links, Working height: 920, UV-laquer roller: yes, Widht of roller coater: 1300, Application roller drive m/min: yes, Widht of metering roller: 1300, Attachment bracket roller: yes, everse drive: yes, rbakel: yes, Feeding speed min/max: 8-25, Roller lift out: yes, Hight adjustment by engine: yes, Type of transportation: Rolle, Pump system: Membrane, Compressed air bar: 6, Year :1996

Manufacturer: Giardina Lackwalze, Year: 1999, Control: Siemens, Program: yes, Work piece width min-max mm: 10-1300, Min.-max. workpiece length in mm: 300, Min.-max. workpiece height in mm: 3-80, Durchlassbreite min-max mm: 1400, Working height: 890, Lackauftragseinheiten: 1, Vorschub Transport m/min min - max: 5-25, kW - Leistung Transport: ca.1,5, Auftragswalzengeschwindigkeit m/min min-max: 5-25, Gummierte Auftragswalze(n): yes, Roller lift out: yes, Hight adjustment by engine: yes, Type of transportation: Rolle, Pump system: Membrane, Carriage: yes, Electronic control board: yes, Strassenbetrieb: möglich, Einbaulänge Auftragsmaschine mm: 900, Carriage: yes, Year :1999

Manufacturer: Giardina 4 Zonen Trockner, Year: 2007, Control: SPS TX 37, Work piece width min-max mm: 100-1320, Min.-max. workpiece length in mm: 300-3500, Min.-max. workpiece height in mm: 6-70, Working widht max mm: 1320, Number of pallets: 92, Palettenausmass LxBxH mm: 3665 X 1400 X 90, Lichte weite Paletten: 115, Tragfähigkeit Palette kg: 180, Palettenausmass LxBxH mm: 3665 X 1400 X 90, Trockenzonen: 4, Abluftzone 1 Abluftmenge m/h³: 6000, Heizregister 1 kcal/h³: 30000, Trockenzone 2 Abluftmenge m/h³: 4000, Heizregister 2 kcal/h³ : 57000, Trockenzone 3 Abluftmenge 3 m/h³: 4000, Heizregister 3 kcal/h³ : 57000, Kühlzone 4 Abluftmenge 3 m/h³: 8000, Heizregister 4 kcal/h³ : Möglich 57000, Feeding speed m/min: 3-5, Conveyor/Conveyor belt: Stange, Heizmedium Warwasser: 3 X Viessman 60 kw Gastherme, Max.Temperatur Grad: 50, Damper register - items: 3 evtl.4, Compressed air bar: 6 ...

Manufacturer: Giardina, Type: GST 1400, Year: 2005, Work piece width min-max mm: 50-1350, Min.-max. workpiece length in mm: 150, Min.-max. workpiece height in mm: 10-60, Working widht max mm: 1300, Number of lamps: 1, kW power 1 lamp: 12, Lampen gerade eingebaut: yes, Adjustable: no, Power per lamp watt UV: 80, od distance mm: 100, Conveyor lenght mm: 2000, Outer belt width mm: 2450, Feeding speed m/min: 8-20, Conveyor: Stange, Drive power kW: 1,2, Year :2005

Hersteller : Giardina, Spare roller: UV Walze, Giradina: yes, Roller rubber coating: yes, Rubber coating length cm: 1450, Shore Härte: ca.30, Approx. thickness of rubber coating in mm: 30, Stahlkerndurchmesser ca. mm: 170, EPDM: Poore 2, Diameter of neck: 30-40-60/40-60, Total lenght mm: 1820, Wedge follower: yes, Rubber coating defective: Neu,

Manufacturer: Giardina 1450 mm 40 shore 10 Gummierung , Giradina: yes, Roller rubber coating: yes, Rubber coating length cm: 1450, Approx. thickness of rubber coating in mm: 10,

Manufacturer: Giradina Lackwalze, Type: gelaufen in Maschine BMG/95/07, Year: 1998, Year :1998

Manufacturer: Giardina, Type: MOS-Micrwellentrockner, Year: 2008, Control: Programm, Channel width in mm: 1500, Channel height in mm: 2000, Channel length in mm: 2900, Heating zone length in mm: MOS, Thermal output: 30.000 kcal H²O, Damper register - items: 1 Vorlauf 75/55 Grad, Heating battery: 1, Year :2008

Manufacturer: Giardina Lackwalze 1450 mm 60 shore gerillt Neu, Giradina: yes, Roller rubber coating: 1450, Shore Härte: 60, Approx. thickness of rubber coating in mm: ca.30, Creasing on a 1 cm: gerillt,

Manufacturer: Giardina, Type: G 84/20, Year: 1994, Control: yes, Brush type: gekordelt, Diameter of brushes: 150, Compressed air cleaning: yes, Number of units: 2, kW Leistung Motoren: ca.2, Number of rotations controlled: yes, Fast exchange device: no, Working width mm: 1400, Through running hight mm: 150, Vacuum belt: no, Feeding speed continous adjustable: yes, Feeding speed min-max m/min: 7-21, kW-Vorschub: ca.1,5, Operating side: rechts, Product detection: no, Electrical hight adjustment: yes, rotor jets: yes, Year :1994

Manufacturer: Giardina 3 D UV-Trockner, Type: GST 1400/3 Albatros, Year: 2005, Work piece width min-max mm: 100-1300, Min.-max. workpiece length in mm: 150, Min.-max. workpiece height in mm: 10-60, Number of lamps: 3, kW power 1 lamp: 12, Lampen gerade eingebaut: yes, Adjustable: yes, Position of lamps: gerade, Power per lamp watt UV: 80, od distance mm: 120, Conveyor lenght mm: 3500, Feeding speed m/min: 2-7, Drive power kW: 1,5, Electrical power consumption kW: 44,1, Year :2005

Manufacturer: Giardina 1450 mm 20 shore 25 Gummierung Neu, Spare roller: Ölwalze, Giradina: yes, Rubber coating length cm: 1450, Shore Härte: 18, Approx. thickness of rubber coating in mm: 25, Stahlkerndurchmesser ca. mm: 170, Diameter of neck: 30-40-60/40-60, Total lenght mm: 1820, Wedge follower: yes,

Hersteller : Giardina, Giradina: yes, Roller rubber coating: yes, Rubber coating length cm: 840, Shore Härte: ca 30, Approx. thickness of rubber coating in mm: 28, Stahlkerndurchmesser ca. mm: 170, Total lenght mm: 1200,

Manufacturer: Giardina Lackwalze 1450 mm 30 shore gerillt Neu, Spare roller: UV Walze, Giradina: yes, Roller rubber coating: yes, Rubber coating length cm: 1450, Shore Härte: ca.30, Approx. thickness of rubber coating in mm: 35, Stahlkerndurchmesser ca. mm: 170, Creasing on a 1 cm: gerillt, Diameter of neck: 30-40-60/40-60, Total lenght mm: 1820, Wedge follower: yes, Rubber coating defective: Neu,

Manufacturer: Giardina Lackersatzwalze 1450 mm shore 25 30Gummi, Giradina: yes, Rubber coating length cm: 1450, Shore Härte: 25, Approx. thickness of rubber coating in mm: 30,

Hersteller : Giardina, Spare roller: UV Walze, Giradina: yes, Roller rubber coating: yes, Rubber coating length cm: 1450, Shore Härte: ca.30, Approx. thickness of rubber coating in mm: 30, Stahlkerndurchmesser ca. mm: 170, Diameter of neck: 30-40-60/40-60, Total lenght mm: 1820, Wedge follower: yes, Rubber coating defective: Riss,

Manufacturer: Giardina Lackwalze 1450 mm Poore Neu NeuGiardina, Spare roller: Öl Walze, Giradina: yes, Roller rubber coating: yes, Rubber coating length cm: 1450, Stahlkerndurchmesser ca. mm: 170, Diameter of neck: 30-40-60/40-60, Total lenght mm: 1820, Wedge follower: yes, Rubber coating defective: schleifen,

Manufacturer: Giardina Lackwalze 1450 mm ca 35 shore muss geschliffen werden, Giradina: yes, Roller rubber coating: yes, Rubber coating length cm: 1450, Shore Härte: 18, Approx. thickness of rubber coating in mm: 35, Stahlkerndurchmesser ca. mm: 170, Diameter of neck: 30-40-60/40-60, Total lenght mm: 1820, Wedge follower: yes,

Manufacturer: Giradina Lackersatzwalze 1300 shore 35, Giradina: yes, Roller rubber coating: yes, Rubber coating length cm: 1300, Approx. thickness of rubber coating in mm: ca 25,

Manufacturer: Giardina, Type: Dualtech 401, Year: 2007, Control: Programm, Work piece width min-max mm: 1300, Min.-max. workpiece length in mm: 1500, Spraying line: Ja, Conveyour system: Band, Laquer circles: 3, by rollers: Ja, Jet dryers (number): 2, Sanding machines (number): 1, Design sanding machine no 1: Costa CT 32/1350, IR dryers (number): 1, Belt conveyors (number): 1, Jet dryers (number): 2, Year :2007

Manufacturer: Giardina, Working length mm: 4100, Working widht mm: 1400, Total hight mm: 950, Feeding speed max m/min: ca 25, Feeding speed min m/min: ca 10, Feeding speed continous adjustable: yes,

Manufacturer: Giardina, Working length mm: 3500, Working widht mm: 1400, UV-Band: ca 920, UV conveyor belt: 120, Bandkühlung: 60, Frequency converter: yes, Engine power kW: 3500 X 1700, Belt 13 length width mm: Spezialband mit Vibrationsmotor um Wasserbestand und Verlauf des Materials zu egalisieren,

Manufacturer: Giardina, Working length mm: 5000, Working widht mm: 1400, Total hight mm: ca 920, Feeding speed max m/min: 20, Feeding speed min m/min: 8, Feeding speed continous adjustable: yes, Belt 1 length width mm: 5000 X 1700,
