10 HOEFLER máquina utilizada para venda

Máquina de Gringing de engrenagens CNC HOFLER H4000 Ano 1990 Diâmetro máximo da peça 4000mm Largura da engrenagem 1560mm Módulo 3-32 Número de dentes 12-768 Ângulo máximo dos dentes 35 R/L Grad Ângulo de pressão 14-31 graus Diâmetro da mesa 1900mm Tabela Diâmetro do furo 750mm Peso máximo da peça 35000kg Curso da cabeça de moagem 1600mm Formas hidrostáticas Líquido de arrefecimento, Sistema de filtração Way Covers: borracha roll-up, metal telescópico e fole neoprene Potência 3 PH / 60 Hz / 230 – 460 V Equipado com: Balanceador Reutlinger Sistema de extração de névoa de óleo Máquina de medição HOFLER TPF-40/1100 Ano: 1990 Diâmetro máximo da engrenagem: 4000mm Ambas as máquinas estão em excelente estado Esta máquina foi usada para moer as engrenagens para as transmissões de submarinos nucleares dos EUA (caixas de velocida ...

max. wheel diameter: 1500 mm gear width: 550 mm max. module: 25 min. module: 2 workpiece weight max.: 6000 kg max. number of teeth: 432 min. number of teeth: 12 table diameter: 990 mm grinding wheel size: 400 mm total power requirement: 75 kW weight of the machine ca.: 20,5 t dimensions of the machine ca.: m With tailstock max. wheel dia. 1250mm, without tailstock 1500mm The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forwa ...

max. wheel diameter: 2500 mm gear width: 1200 mm max. module: 32 min. module: 3 total power requirement: 25 kW weight of the machine ca.: 60 t dimensions of the machine ca.: m Gear , min. / max. 180 / 2,500 mm Module 3 - 32 Helix angle, max. 10 - 35 ° Gear width for straight gears 1,200 mm Stroke length, approx. 100 - 1,200 mm No. of strokes 80 - 350 /min Stroke position adjustable 300 mm Stroke speed 4 - 40 mm Max. weight of workpiece, approx. 18,000 kg Min. / max. no. of teeth 16 / 576 Table size x bore 1,400 x 500 mm Grinding wheel Ø, approx. 500 mm Grinding wheel peripheral speed 34 m/s Total electrical load, approx. 45 kW - 380 V - 50 Hz Weight of machine, approx. 60,000 kg Accessories / Special Features: Hydrostatic guides in grinding slide, table and in all other guideways. Completely covered working area with sliding doors. Automatic grinding process for various cycles, with ...

: workpiece length - max.: mm max. module: 0 total power requirement: kW weight of the machine ca.: t required space: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. wheel diameter: 1400 mm gear width: 400 mm max. module: 25 min. module: 1 total power requirement: - kW weight of the machine ca.: 7,0 t dimensions of the machine ca.: 3,0 x 1,2 x 3,2 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. wheel diameter: 2500 mm gear width: 980 mm max. module: 34 min. module: 2 grinding stroke stepless adjustable: 1000 mm root circle dia. min.: 180 mm number of teeth: frei wählbar max.helical angle: 0 - 35 ° grinding slide stroke: 20 / 200 U/mm grinding wheel peripheral speeds:: 35 / 45 m/s grinding wheel diameter: 340 / 435 mm grinding motor: 22 kW pressure angle: 12,5 - 30 ° table diameter: 1300 mm table load capacity: 10000 kp table bore diameter: 300 mm depth of hole: 300 mm roll feed: 0 - 1000 m/min table diameter: 1300 mm workpiece weight: 10000 kg clamping length: 2760 mm clamping height: 420 - 590 mm table bore diameter: 280 mm depth of hole: 300 mm Control: BWO H+K CNC 785 total power requirement: 79 kVA weight of the machine ca.: 40 t dimensions of the machine ca.: 7,3 x 7,9 x 4,5 m - 10 axis CNC control BWO H+K CNC 785 (2nd Generation from 2009) - integrated measurement ...

max. wheel diameter: 600 mm gear width: 0 mm max. module: 16 (25) min. module: 1 center distance betw. workpiece-tool min/max.: 40 - 590 mm diameter of hob: 290 mm cutter length max.: 470 mm tangential adjustment: 450 mm milling head -swivable +/-: 45 ° milling head speed: 15 - 380 U/min table rotation speed: 50 U/min milling spindle drive: 37 kW table diameter: mm table load: 3750 kg feeds: 2000 mm/min Control: Siemens 840D total power requirement: 115 kVA weight of the machine ca.: 31 t dimensions of the machine ca.: m - 6-axis CNC control Siemens Sinumerik 840 D - complete covering - counter stay - Coolant Unit - Chip Conveyor The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

A Höfler gear grinding machine is offered. Module range: 2-25, max. gear diameter: 1500mm, max. gear width: 720mm, min./max. generating grinding stroke: 60mm/750mm, ram stroke rate: 20-200double strokes/min, number of teeth: freely selectable, max. generating speed: 900mm/min, table diameter: 1000mm, distance between centers: 1250mm, min./max. grinding wheel diameter: 300mm/400mm, grinding wheel bore: 127mm, grinding wheel width: 45mm, weight: approx. 34t. Including paper band filter, counter support with steady rest and balancing unit. Documentation available. Inspection possible by prior arrangement.

Key data: 400 mm, 200 mm, 10

1-- Máquina de retificação de engrenagens controlada por CNC de 4 eixos para sistemas cilíndricos, de dentes retos, involutos e de dentes especiais. Marca: Höfler Modelo: Promat 400 Ano de Fabricação: 2000 A roda de rectificação é perfilada com uma cómoda CNC integrada. Dados técnicos: • Diâmetro máximo da roda 240-400 mm • Largura máxima da roda de moagem 30 mm • Roda de moagem de potência nominal 15 kW • Velocidade máxima de corte 60 m/s • Módulo: 0,5 - 10 • Largura máxima de dente 200 mm • Curso máximo de trabalho 210 mm • Velocidade do curso do suporte da peça de trabalho 6.000 mm / min • Número de dentes livremente selecionáveis • Número de eixos controlados: 4 (máquina) + 2 (cómoda) • Carga máxima da mesa 100 kg • Carga total ligada 30 kVA • Peso da máquina aproximadamente: 9 para.

A horizontal Höfler CNC gear grinding machine is available. Machining diameter: 650mm, min. workpiece diameter: 30mm, max. gear width: 530mm, module range: 1.5-18, max. helix angle: 40°, table diameter: 490mm, max. table load: 1000kg. Machine dimensions X/Y/Z: approx. 4500mm/3000mm/3000mm, weight: approx. 22000kg. Including Rittal cooling unit and ISI extraction system. The machine has been out of operation since 2010. Documentation available. An on-site inspection is possible.
