11 MENGELE máquina utilizada para venda

pressure: 1.500 t chamfer lenght: 15000 mm distance between columns: 10160 mm control: CNC 10 Grafik throat: 770 mm table length: 15000 mm weight of the machine ca.: 170 t dimensions of the machine ca.: 17000 x 5400 x 5900 m - Pressure: 1.250t - Bending length:15.000mm - Control: CNC 10 graphics - No. of axes axes: min. 10 - Frame width: 10.160mm - Projection: 770mm - Table length: 15,000mm - Dimensions: 17,000mm x 5,400mm x 5,900mm - Mass: approx. 230t Equipment - Crowning device - CNC 10 control with graphics - Hydr. clamping of the upper tools - Multi-man operation - Increased speeds - Automatic height-adjustable rear sheet stop - die cushion device - Horn length 2,200 mm on both sides The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 160 t chamfer lenght: 3000 mm distance between columns: 2650 mm Control: Cybelec DNC 800 total power requirement: kW weight of the machine ca.: 16 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 130 t chamfer lenght: 3550 mm distance between columns: 3050 mm stroke: 250 mm Control: Cybelec weight of the machine ca.: 11.600 kg dimensions of the machine ca.: 4000x2000x3000 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 250 t chamfer lenght: 3550 mm distance between columns: 3050 mm total power requirement: kW weight of the machine ca.: 27.000 kg dimensions of the machine ca.: 4500 x 2000 x 3400 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

CONTROLS   electronic controls WORKING RANGE SURFACE GRINDING   grinding length: 600 mm   grinding width: 350 mm   distance of axis of horizontal spindle - clamping surface (max.): 640 mm TABLE (SURFACE GRINDING)   table surface (left-right): 1320 mm   table surface (front-back): 300 mm MAGNETIC TABLE   length: 600 mm   width: 300 mm SPINDLESTOCK GRINDING SPINDLE   spindle revolutions (min): 1440 /min   spindle revolutions (max): 2880 /min   continuous speed variation: yes   drive power: 7.5 kW GRINDING TOOL   type of grinding tool: wheel   diameter (min): 300 mm   diameter (max): 450 mm   width: 80 mm DIMENSIONS / WEIGHTS   space requirements -left/right-: 2200 mm   space requirements -front/back-: 1900 mm   total height: 2000 mm   total weight approx.: 3450 kg ATTACHMENTS (GRINDING)   coolant unit: yes

Hydraulic cylinders, support cylinders, hydraulic rams, pressure rams -Spare part: Hydraulic cylinder from Mengele press brake -Equipment: with threaded stop for depth limitation -Piston diameter: approx. 240 mm -Piston rod: Ø 200 mm -Stroke: approx. 380 mm -Piston rod mounting: 212 x 212 mm -Number: 2x cylinders available -Price: per piece -Dimensions: 840/410/H355 mm -Weight: 430 kg/piece -Weight: 430 kg/piece

Travão de pressão hidráulica Fabricante: MENGELE Tipo: A 100-2 Pressão de pressão: 100t Curso: 160mm electr. Ligação: 400V 3Ph Ano de construção: 1964 Condição: usada e funcional

Largura da chapa: 3050 mmplate espessura: 25 mmdistância entre colunas: requisito de potência mmtotal : kW peso da máquina ca.: tdimensions da máquina ca.: m

pressure: 200 t chamfer lenght: 3000 mm distance between columns: 2560 mm dayligth: 450 mm throat: 450 mm adjustment of stroke: 240 mm horn length over column outer edge each: 175 mm table length: 3050 mm table width: 280 mm table height over floor: 820 mm electrics - voltage/frequency: 220/50 V/Hz control: CYBELEC, DNC60 stroke: 250 mm operating pressure: 150 bar total power requirement: kW weight of the machine ca.: 15 t dimensions of the machine ca.: L:4,0 x B:3,2 x H:3,44 m • hydraulical press brake, • new control CYBELEC DNC60 (in 2005), • lower part of the machine moves down 500 mm to the floor, at the moment the machine is mounted on a double-T-support, • prism and upper part of the machine in 3000 mm length The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 160 t chamfer lenght: 4000 mm distance between columns: 3060 mm control: FORTRON CNC 10 H 4 throat: 280 mm stroke: 250 mm dayligth: 500 mm table length: 4050 mm table width: 280 mm feed down: 70 mm/sec feed up: 68,4 mm/sec working feed: 9 / 3,5 mm/sec operating pressure: max. 205 bar oil volume: 400 l total power requirement: 19,5 kW weight of the machine ca.: 20,8 t Total weight including accessories: 22 t dimensions of machine L x W x H: 4,8 x 1,88 x 2,93 m dimensions of switch cabinet: 1,6 x 0,5 x 2,25 m Acc.: programmable back gauge, upper and lower dies, table extensions The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Pressione a prensa de banco de borda da borda da borda do travão do travão usada Fabricante: Mengele Tipo: C320-4B Construído: 1966 última revisão e reparação: 2000 Localização D-01587 Riesa Dimensões WxH: 6.250 x 3.650 mm Largura da faca de borda: 6.150 mm espessura da chapa a 6.000 mm de comprimento de flexão: aproximadamente 7,5 mm. As máquinas são projetadas para curvas de eixos muito profundas, portanto, recantos de bochechas muito profundas. Força de prensagem original 300 t - Em 1989 a força de prensagem foi aumentada para 350 t. A imprensa está em muito bom estado, apesar da sua idade. A máquina está desmontada e pronta para ser carregada. documentação para a máquina está disponível. Peso: cerca de 45 t
