114 MORI SEIKI máquina utilizada para venda

This 3s MORI SEIKI SV-50s was manufactured in 1997. The CNC milling machine is in good working condition and has been used only a few times for prototype work. It features a FANUC spindle with a speed of 10,000 rpm and a tool changer with 30 positions. Consider the opportunity to buy this MORI SEIKI SV-50 vertical machining centre. Contact us for further details.

This 3-axis MORI SEIKI SL-403BMC/800 was manufactured in 2002. It features a maximum turning diameter of 650 mm and a maximum turning length of 863 mm. The machine offers an X-axis travel of 345 mm and a Z-axis travel of 995 mm. If you are looking to get high-quality turning capabilities, consider the MORI SEIKI SL-403BMC/800 horizontal turning machine we have for sale. Contact us for further details.

Centro de Maquinação Vertical MORI SEIKI, Modelo/Tipo: GV-503/5ax X-travel 610 mm Y-Travel 765 mm Z-travel 460 mm Tamanho da mesa de paletes 550 x 550 mm BT 40 afunilado

Centro de usinagem Mori Seiki M25 – FH 2/35

MORI SEIKI NT6600 CNC INTEGRADO MILL TURN CENTER COM MOAGEM AO VIVO BALANÇO MÁXIMO SOBRE CAMA: 42INCH DIÂMETRO MÁXIMO DA PEÇA DE TRABALHO: 42 polegadas COMPRIMENTO MÁXIMO DA PEÇA DE TRABALHO: 239INCH DIÂMETRO MÁXIMO DA BARRA: 6.4 polegadas FUSO BORE: 7inch X AXIS TRAVEL: 41inch Y AXIS TRAVEL: 26inch Z AXIS TRAVEL: 242inch EIXO B: +/- 120 DEG. VELOCIDADE DO FUSO PRINCIPAL: 1500 RPM MOTOR DO FUSO PRINCIPAL: 40 CV VELOCIDADE DO FUSO DE MOAGEM: 8000 RPM MOTOR DO FUSO DE MOAGEM: 40 CV ELÉTRICOS: 220V/3P/60Hz/216A OAD (APPROXIMATE): 490inch X 182inch X 169inch HIGH PESO (APROXIMADA): 120.560 LBS. EQUIPADO COM: EIXO C RIO YAXIS EIXO B FERRAMENTAS/MOAGEM AO VIVO CHUCK de 20inch Controlo CNC FS-31iA5 140 POSIÇÃO TROCA DE FERRAMENTAS AUTOMÁTICA TAILSTOCK PROGRAMÁVEL REFRIGERANTE ATRAVÉS DE FUSO (ALTA PRESSÃO) TRANSPORTADOR DE CHIPS Opções de controlo ...

standard turning dia.:200 turning length:max. 810 mm control:MSX-701 MAPPS IV greates pass round over bed:800 mm Max. distance between centres:1130 mm max. turning diameter:320 mm max. workpiecediameter:300 mm bar material dia.:65 mm Traverse X-Axis 1:210 Traverse X-Axis 2:210 mm Traverse X-Axis 3:210 mm Traverse Y-Axis 1:110 (+65/-45) mm Traverse Y-Axis 2:110 (+45,/-65) mm Traverse Z-Axis 1:300 mm Traverse Z-Axis 3:300 mm Traverse Z-Axis 2:810 mm Traverse B-Axis:870 mm turning speed range - spindle:5.000 1/min Number of spindle speed ranges:2 . spindle nose:JIS A2-6 spindle bore:73 mm spindle bearing diameter:120 mm C-Axis:0,001 ° turning speed range - spindle:5.000 1/min spindle nose:JIS A2-6 spindle bore:73 mm bar material dia. max:65/52 mm spindle bearing diameter:120 mm C-Axis:0,001 ° Number of Turrets:3 . Number of tool stations:16 x 3=48 pos Schank height for square tool:20 mm D ...

standard turning dia.:200 turning length:max. 810 mm control:MSX-701 MAPPS III greates pass round over bed:800 mm Max. distance between centres:1130 mm max. turning diameter:320 mm max. workpiecediameter:300 mm bar material dia.:65 mm Traverse X-Axis 1:210 Traverse X-Axis 2:210 mm Traverse X-Axis 3:210 mm Traverse Y-Axis 1:110 (+65/-45) mm Traverse Y-Axis 2:110 (+45,/-65) mm Traverse Z-Axis 1:300 mm Traverse Z-Axis 3:300 mm Traverse Z-Axis 2:810 mm Traverse B-Axis:870 mm turning speed range - spindle:5.000 1/min Number of spindle speed ranges:2 . spindle nose:JIS A2-6 spindle bore:73 mm spindle bearing diameter:120 mm C-Axis:0,001 ° turning speed range - spindle:5.000 1/min spindle nose:JIS A2-6 spindle bore:73 mm bar material dia. max:65/52 mm spindle bearing diameter:120 mm C-Axis:0,001 ° Number of Turrets:3 . Number of tool stations:16 x 3=48 pos Schank height for square tool:20 mm  ...

x-travel:800 mm y-travel:410 mm z-travel:510 mm control:Fanuc 10 MA rapid travel x/y/z:20/20/15 mm/min table surface area:1100 x 450 mm tool taper:BT 40 tool magazin::30 BT 40 max. tool length:250 mm max. tool weight:8 kg power requirement:7,5/5,5 kW turning speed range:6000 1/min weight of the machine ca.:6,3 t Under offer is a complete CNC tool shop, which will be given up due to old age of owner. The Mori Seiki is still highly accurate. All existing tool holders, tools, drills, vices etc. come with the machine. All measuring devices also come with the machine. Upon request orders for parts to be made can be passed on to new owner. This is a low cost all inclusive opportunity for a "Startup"

x-travel:1400 mm y-travel:1200 mm z-travel:1350 mm control:MSX- 701 Mapps III table surface area:800 x 800 mm rapid traverse:50 m/min table rotating:360.000 x 0,001 B-Achse ° table load:2,0 t numbers of pallets:2 turning speed range:8000 1/min power capacity - milling spindle:37 kW no. of tools in the magazine:60 Stück tool taper:HSK-A 100 weight:31 t dimensions:5,9 x 3,48 x 3,68 m Equipment: - Thru-the-spindel coolant system Mayfran Consep 2000 70 bar with chipconveyor - Helical cutting + Synchronized tapping - Parts program memory 1 MB - Knoll 70 bar high pressure and filter system - Electrostatic oil dust collector LTA - elect. hand wheel - renishaw probe - abso- scale i X/Y/Z- axis - 5 free m- funktions - 48 extra off sets - dual ballscrews on X/Y/Z- axis

x-travel:630 mm y-travel:600 mm z-travel:650 mm control:MSC 502 (Fanuc 16) Spindle RPM:12000 1/min spindle drive:22 / 18,5 kW rapid travel x/y/z:32 m/min Pallet dimension:500x500 mm numbers of pallets:2 table load:0,5 t working diameter:max. 610 mm Number of tool station:60 BT40 max. tool length:360 mm max. tool weight:12 kg tool changing time:1,3 sec B-axis positioning (non continuous):1 total power requirement:50 kVA weight of the machine ca.:14 t dimensions of the machine ca.:3,3 x 5,8 x 3,2 m spindle load monitor:Typ C This horizontal machining center comes with a pallet changer with 2 pallets, and has the following options: ATC 60 tool stations, High pressure coolant trough spindle interface,

x-travel:800 mm y-travel:460 mm z-travel:510 mm total power requirement:20 kW weight of the machine ca.:8 t Vertical Processing Centre 20kW is the nominal value. The spindle only needs 7.5kW. It looks like 15kW will be enough.

x-travel: 600 mm y-travel: 530 mm z-travel: 510 mm Control: M 730 BM MAPPS IV Main spindle:: max. spindle speed: 10.000 min/-1 power capacity - main spindel: 15 / 11 kW tool taper: SK 40 transmission ratio: 1 spindle diameter in front bearing: 80 mm work table:: table surface area: 900 x 600 mm max. table load: 800 kg T-slots: 6x 18 x 100 mm distance spindle /table: 150 - 660 mm Tool-Presetter:: number of toolpositions: 30 pos. tool taper: SK 40 max. tool diameter: 80 mm max. tool-dia with free toolbox: 150 mm max. tool length: 300 mm max. tool weight: 8,0 kg change-time tool to tool: ca. 1,3 sec change-time chip to chip: ca. 3,45 sec feeds:: rapid traverse ( X / Y / Z ): 30 m/min feed speeds: 1 - 30.000 mm/min Tipp feed: 0 - 5.000 : 20 mm/min total power requirement: 30 kVA weight of the machine ca.: 6,0 t dimensions of the machine ca.: 4,5 x 3,5 x 2,7 m Documents: Chip conveyor:  ...

turning diameter: 660/275 mm turning length: 1498 mm control: Fanuc/Mori Seiki MSX 701 total power requirement: 90 kVA weight of the machine ca.: 26,6 t dimensions of the machine ca.: 5301 x 2997 x 2788 mm 9-axis CNC turning and milling centre Fanuc MSX-701 CNC control Milling spindle at top (B axis), as full 4th axis, positioning 0.0001 deg. 40-position tool magazine 10-position turret at bottom, all positions driven 2 x 3-jaw quick-change chuck KNCS-N 315/91 KNOLL high-pressure coolant system, pressure setting 12/25/35/45/55/62 and 72 bar, with maintenance-free rotary filter system Chip conveyor Drain system for main spindle chuck (controlled via M function) Drain system for tool cutting edge (controlled via M function) Coolant gun incl. accessories Oil mist extraction Direct measuring system X1, X2, Y-axis Bar loader interface Double foot switch for both spindles Island ...

x-travel: 800 mm y-travel: 530 mm z-travel: 510 mm Control: MSC 504 Mori Seiki Main spindle:: turning speeds: max. 10.000 min/-1 power capacity - main spindel: 15 / 11 kW tool taper: SK 40 spindle bearing diameter: 70 mm distance spindle /table: 150 - 660 mm work table:: table surface area: 1.100 x 600 mm max. table load: 800 kg T-slots: 6x 18 mm table height over floor: 900 mm turret:: number of toolpositions: 30 pos. tool taper: SK 40 max. tool diameter: 80 mm max. tool-dia with free toolbox: 125 mm max. tool length: 300 mm max. tool weight: 8,0 kg change-time tool to tool: 1,3 sec change-time chip to chip: 4,1 - max. 9,2 sec feeds:: rapid traverse ( X / Y / Z ): 36 / 36 / 20 m/min feed speeds: max. 6.000 mm/min Tipp feed: 1 - 5.000 mm/min total power requirement: 27 kVA weight of the machine ca.: 6,1 t dimensions of the machine ca.: 3,5 x 3,0 x 2,8 m Documents: Chip conveyor: Co ...

x-travel: 800 mm y-travel: 530 mm z-travel: 510 mm Control: MSC 504 Mori Seiki Main spindle:: turning speeds: max. 10.000 min/-1 power capacity - main spindel: 15 / 11 kW tool taper: SK 40 spindle bearing diameter: 70 mm distance spindle /table: 150 - 660 mm work table:: table surface area: 1.100 x 600 mm max. table load: 800 kg T-slots: 6x 18 mm table height over floor: 900 mm turret:: number of toolpositions: 30 pos. tool taper: SK 40 max. tool diameter: 80 mm max. tool-dia with free toolbox: 125 mm max. tool length: 300 mm max. tool weight: 8,0 kg change-time tool to tool: 1,3 sec change-time chip to chip: 4,1 - max. 9,2 sec feeds:: rapid traverse ( X / Y / Z ): 36 / 36 / 20 m/min feed speeds: max. 6.000 mm/min Tipp feed: 1 - 5.000 mm/min total power requirement: 27 kVA weight of the machine ca.: 6,1 t dimensions of the machine ca.: 3,5 x 3,0 x 2,8 m Documents: Chip conveyor: Co ...

x-travel: 560 mm y-travel: 560 mm z-travel: 630 mm Control: MSX 701 III MAPPS Main spindle:: Max. rpm: 14.000 min/-1 power capacity - main spindel: 18,5 / 11 kW max. Torque: 120 Nm tool taper: MAS BT 40 distance spindle center to table: 80 - 640 mm distance Spindlenose and center of table: 100 - 730 mm pallet changer:: numbers of pallets: 2 size of pallet: 400 x 400 mm max. workpiece weight: 400 kg max. workpiecediameter: 630 mm max. workpiece height: 900 mm change time of pallets: 6,0 sec b - axis: 0,001 ° Tool-Presetter:: number of toolpositions: 60 pos. tool taper: MAS BT 40 max. tool diameter: 70 / (140) mm max. tool length: 400 mm max. tool weight: 8,0 kg feeds:: rapid traverse ( X / Y / Z ): 50 m/min feed speeds: 0 - 50.000 mm/min Tipp feed: 0 - 1.260 mm/min total power requirement: 35 kVA weight of the machine ca.: 9,8 t dimensions of the machine ca.: 5,5 x 3,5 x 2,8 m Docume ...

x-travel: 600 mm y-travel: 400 mm z-travel: 400 mm control: MSX 501 Mori Seiki work table:: table surface area: 700 x 450 mm max. table load: 350 kg number of T-slots: 4 T-slot - width: 18 mm T-slot - distance: 100 mm Main spindle: Number of revolutions: 12.000 U/min power capacity - main spindel: 18,5 / 15 / 11 kW tool taper: BT 40 max. Torque: 110,5 Nm diameter of forward milling spindle bearing: 70 feeds: rapid travel x/y/z: 20.000 mm/min feed speeds: 1 - 20.000 mm/min Tipp feed: 15 Steps / 0 - 1.260 mm/min Tool-Presetter:: Number of Toolpositions in magazine: 40 Pos. Max. mould width: 80 mm max. tool-dia with free toolbox: 125 mm max. tool length: 250 mm max. tool weight: 8 kg change-time chip to chip: 2,8 sec change-time tool to tool: 1,0 sec total power requirement: 34 kVA weight of the machine ca.: 7,2 t dimensions of the machine ca.: 2,8 x 3,0 x 2,9 m Documents: Chip conveyo ...

turning diameter: 390 mm turning length: 507 mm control: MSG 805 MAPPS max. turning diameter: 390 mm greates pass round over bed: 680 mm Swing dia. over traverse guideway: 510 mm centre distance: 618 mm Main spindle:: turning speed range - main spindle: 45 - 4.500 min/-1 power capacity - main spindel: 11 / 7,5 kW spindle bearing diameter: 110 mm spindle bore: 73 mm max. bar capacity: 51 mm spindle nose: JIS A2-6 chucking diameter: 210 mm C-Axis: 0,001 ° axis stroke:: x-axis: 235 (195+40) mm z-axis: 520 mm turret:: number of toolpositions: 12 pos. Number of driven toolspositions: 12 pos. Spindle speed - driven tool stations: max. 3.000 min -1 power capacity driven tool-stations: 5,9 / 4,5 kW Shank height for square tool: 25 mm Drill shank diameter: max. 50 mm turret change time: 0,2 sec. Tailstock:: tailstock adjustment: 490 mm dia. of quill: 85 mm taper of center: MT 4 quill stroke: ...

x-travel: 560 mm y-travel: 510 mm z-travel: 510 mm Control: MSC 502 distance spindle center to table: 50 - 650 mm distance Spindlenose and center of table: 100 - 610 mm Main spindle:: turning speed range - main spindle: max. 12.000 min/-1 power capacity - main spindel: 22 / 18,5 kW tool taper: MAS BT-40 spindle bearing diameter: 70 mm pallet changer:: numbers of pallets: 2 size of pallet: 400 x 400 mm max. workpiecediameter: 580 mm max. workpiece height: 650 mm b - axis: switching time: 90°: 2,5 sec change time of pallets: 6,0 sec Tool-Presetter:: number of toolpositions: 60 pos. tool taper: MAS BT-40 max. tool diameter: 80 mm max. tool-dia with free toolbox: 125 mm max. tool length: 300 mm max. tool weight: 8 kg change-time tool to tool: 1,5 sec change-time chip to chip: 3,7 sec feeds:: rapid traverse ( X / Y / Z ): 32 m/min feed speeds: 1 - 24.000 mm/min Tipp feed: 0 - 1.260 mm/m ...

turning diameter: 370 mm turning length: 424 mm control: MSX-711-IV Mori Seiki swing diameter: 370 mm X1- Axis: 380 mm X2- Axis: 155 mm Z1- Axis: 460+155 mm Z2- Axis: 610 mm y-axis: +/- 105 mm B - axis: +/- 120 ° bar material dia.: 65 mm speed spindle max.: S1 5.000 / S2 6.000 U/min. spindle bore: S1/S2 65/38 mm : 12000 1/min tool taper: Capto C5 toolpiece magazine: chain magazine: 76 Stück tool turret with 10 work positions: total power requirement: 45 kW weight of the machine ca.: 10,5 t dimensions of the machine ca.: 2,71 x 2,43 x 2,40 m MAPPS control system Renishaw HPRA (manual tool presetter) Blum Laser Control Direct measuring system X,Y,Z,B Collet chuck SMW Autoblok KSZ-MB-040-Z140 Workpiece conveyor belt Bar feeder Breuning Irco ILS-RBK-10012 Knoll band filter KF10/500 / IKZ with milling spindle 7 stages up to 70 bar Chip conveyor ConSep 2000 The data for this ad was create ...

turning diameter: max. 320 mm turning length: 810 mm control: MSX 701 MAPPS III standard turning dia.: 200 mm Main spindle:: Number of revolutions: max. 6.000 min/-1 power capacity - main spindel: 22 / 18,5 kW Bar feed: max. 52 mm spindle bore: 61 mm C-Axis: 0,001 ° Subspindel:: Number of revolutions: max. 6.000 min/-1 power capacity - Sub spindle: 22 / 18,5 kW Bar feed: max. 52 mm spindle bore: 61 mm C-Axis: 0,001 ° Turret 1 + 3:: number of toolpositions: je 16 pos. Number of driven toolspositions: je 16 pos. Spindle speed - driven tools: max. 6.000 min -1 power capacity - driven tools: 7,5 / 5,5 kW Y - Axis: 110 (+65 / -45) mm Turret 2:: number of toolpositions: 16 pos. Number of driven toolspositions: 16 pos. Spindle speed - driven tools: max. 6.000 min -1 power capacity - driven tools: 7,5 / 5,5 kW Y - Axis: 110 (+45 / -65) mm axis stroke:: x-travel: 1-3: 210 mm y-travel: 1-3: ...

turning diameter: 176 mm turning length: 570 mm swing diameter: 510 mm working diameter: 420 mm travel -z axis: 570 mm travel -x axis: 245 mm spindle bore: 43 mm diameter of quill: 85 mm quill stroke: 120 mm Spindle Speed: 60-6.000 U/min. rapid power traverse in X-and Z direction: 24 m/min total power requirement: 5,5 kW control: MSG-805 V weight of the machine ca.: 3.400 kg dimensions of the machine ca.: 2000x1700x1800 mm Features/Accessories: - Integrated CNC control - Bed guides and cross-slide guides are induction-hardened and designed as flat guides - Continuously variable AC main spindle drive - Constant cutting speed programming - Cold light lamp integrated into the machine - Power meter for the main spindle drive (ammeter) - Control units for automatic and manual operation, as well as a CNC programming unit and control panel - Tailstock with hydraulically actuated MK 4 tailstock ...

x-travel: 510 mm y-travel: 510 mm z-travel: 510 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m CNC control MSC 803 25-fold automatic tool changer coolant device Technische Daten / technical details: Verfahrweg X / X-Travel 510 mm Verfahrweg Y / Y-Travel 510 mm Verfahrweg Z / Z-Travel 510 mm Tischgröße / table size 750x548 mm Drehzahlbereich / spindle speed 8000 UpM /rpm Anzahl der Werkzeugplätze / tool places in changer 25 fach Antriebsleistung Spindel / drive capacity spindle 11 kW Gewicht der Maschine ca. / weight 4500 Kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Technical data, accessories and description of the machine are not binding. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter: ca. 570 mm turning length: ca. 530-610 mm control: FANUC : ohne Gewähr x-travel: ca 160-200 mm y-travel: ca. 560 mm weight of the machine ca.: 4,5 - 5 t : ca 10 oder 12 spindle bore: 52-76 mm total power requirement: - kW weight of the machine ca.: 4 t dimensions of the machine ca.: - m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter: 190 mm turning length: 210 - 230 mm x-axis: 125 mm z-axis: 195 mm turning speed range: 6.000 U/min greates pass round over bed: 190 - 200 mm spindle bore: 43 mm machine weight ab.: 2.500 kg The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter: 200 mm turning length: 393 mm control: MSX 853 weight of the machine ca.: 3,5 t total power requirement: kW dimensions of the machine ca.: m MSX 853 cnc control 3-jaw chuck diameter 210mm 12-fold revolver C-axis driven tools tail stock coolant device chip conveyor Technische Daten: / technical details Drehdurchmesser / turning diameter 200 mm Drehlänge / turning lenght 393 mm X-Weg / X-travel 160 mm Z-Weg / Z-travel 450 mm max. Drehzahl Spindel / max. spindle speed 50-3000 UpM /rpm Eilgang X/Z / rapid feed X/Z 24/30 Anzahl der Revolverplätze / number of tool places 12 max. Stangendurchmesser / max. bar diameter 51 mm Antriebsleistung Spindel / drive capacity spindle 13,5 kW Gewicht ca. / weight ca. 3500 kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Technical data, accessories and description of the machine are n ...

turning diameter: max. 356 mm turning length: 705 mm control: MSX 850 III MAPPS Mitsubishi greates pass round over bed: 923,8 mm Swing dia. over traverse guideway: 755 mm standard turning dia.: 275 mm Main spindle:: max. spindle speed: 4.000 min/-1 power capacity - main spindel: 18,5 / 15 kW spindle nose: JIS A2-8 spindle bearing diameter: 140 mm spindle bore: 91 mm max. bar capacity: 80 mm chucking diameter: 305 mm C-Axis: 0,001 ° Subspindle:: Spindle speed range subspindle: max. 6.000 min/-1 power capacity - Sub spindle: 11 / 7,5 kW spindle nose: JIS A2-5 spindle bearing diameter: 85 mm spindle bore: 43 mm chucking diameter: 210 mm C-Axis: 0,001 ° turret:: number of toolpositions: 12 pos. Number of driven toolspositions: 12 pos. Shank diameter: 26 mm Drill shank diameter: 50 mm Spindle speed - driven tool stations: max. 6.000 min -1 turret change time: 0,25 sec. axis stroke:: x-a ...

turning diameter: 430 mm turning length: 519-525 mm control: Mori seiki MSX-805 x-axis: 230 mm z-axis: 520 mm total power requirement: kW weight of the machine ca.: 4100 kg dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 1.020 mm y-travel: 510 mm z-travel: 510 mm control: MSC 501 Fanuc table surface area: (APC) 1.200 x 480 mm max. table load: (APC) 550 kg Main spindle:: turning speed range - milling: 10.000 U/min power capacity - milling spindle: 22 / 18,5 kW tool taper: BT 40 Tool-Presetter:: number of toolpositions: 30 pos. tool taper: BT 40 max. tool diameter: 80 mm max. tool-dia with free toolbox: 125 mm max. tool length: 300 mm max. tool weight: 8 kg rapid traverse: 32 m/min feed: 1 ~ 16.000 mm/min Tipp feed: 0 ~ 1.260 mm/min spindle bearing diameter: 85 mm total power requirement: 59,5 kVA weight of the machine ca.: 6,9 t dimensions of the machine ca.: 3,9 x 2,7 x 2,9 m Documents: Chip conveyor: 2x Coolantsystem: high pressure coolant: through spindle coolant: Signal-Light: pallet changer: 2 pos. CNC - Machining Center - Vertical MORI SEIKI - SV 500 B/40 - Clamping devices are NOT  ...

turning diameter: 370 mm turning length: 424 mm control: Fanuc total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
