Fresadoras de consola universais (46)

Key data: 1400 mm, 630 mm, 500 mm

Tamanho da mesa: 1800 x 630 mm Faixa de velocidade 56 - 2800 1/min Porta-ferramentas ISO 50 Curso X / Y / Z 1400 / 630 / 500 mm Faixa de alimentação X, Y 10 - 2000 (Z 2,5 - 500) mm/min infinitamente variável Motor principal de 15 kW, carga ligada aprox. 20 kW Incl. Cabeça de fresagem universal IUG 32A giratória 360° fuso de fresagem horizontal Travessia rápida, ciclo automático Visor digital Heidenhain ND 750 Configuração do líquido de arrefecimento Revestimento da área de trabalho fixação hidráulica de ferramentas Declaração CE de Conformidade

GeneralVertical Machining Center; Control: Control SIEMENS SINUMERIK ONE CharacteristicsTable surface850 x 650 mmSpeed max.12000 rpmDrive power (100% DC)9 kWDrive power (40% DC)13 kWTorque (100% DC)57 NmMax. torque83 NmTool Magazine with24 PositionsSpindle taperSK 40 DIN 69871 Movement X / Y / Z550/550/510 mmRapid feed X / Y / Z24/24/24 m/minDimensions (L x W x H)3,07 x 2,67 x 2,84 mWeight approx.5600 KgMechanical preparation for Oil-Mist Extractor UnitMechanical preparation for Oil-Mist Extractor Unit (opening diameter: D200 mm) Tropical PackageTropical Package Option includes: - Active cooling unit for electrical cabinet - Additional ventilator for control panel Recommended from 35°C to max. 45°C environmental temperature SK40 interfaceTool clamping SK 40 for pull-studs DIN 69872 Signal lamp with 4 colours standardSignal lamp with 4 colours Red: General error Yellow: Interventio ...

Key data: 1120 mm, 345 mm, 550 mm

Largura da mesa 400 mm, comprimento da mesa 1600 mm Porta-ferramentas SK 50 Faixa de velocidade 28-1400 rpm Faixa de alimentação 16-800 mm/min Curso x 1120 mm; y 345 milímetros; z 550 milímetros Carga ligada aprox. 14,5 kW Acessórios: 2 contra-rolamentos Braçadeira elétrica eixo horizontal e vertical Cabeça de fresagem vertical SK50 com rolamento de encaixe

GeneralVertical-Machining centre Stealth Design; Control: CELOS X with Siemens 840D SL Operate CharacteristicsTable surface1460 x 750 mmMaximum load (table centre)1500 KgTool Magazine with40 PositionsMovement X / Y / Z1150/700/550 mmRapid feed X / Y / Z42/42/42 m/minWeight approx.12900 KgSpindle speed 20 - 12,000 rpm SK50, 288NmSpindle speed 20 - 12.000 rpm SK50 for tool taper according to DIN ISO 7388-1-A50 with power 44/32 kW // 59.0/42.9 hp with torque 288/187 Nm (40/100% DC) (differently from standard) Tool magazine 40 pocketsTool magazine 40 pockets SK50 chain magazine with pockets and double gripper, incl. manually direct loading into the tool magazine Coolant-air blast change-overCoolant - Air-blast changeover external switchable via M-Function Air blast through spindle centreAir blast through spindle centre activated by M function, maintained air with low oil rate Internal c ...

Código: 4923 DESCRIÇÃO Fresadora universal Fazer DEBER Modelo FU 1 N.º de série 228 Ano Tabela 1250 x 300 mm Tabela de longitude 750 mm Mesa vertical 405 mm Mesa transversal 240 mm Cone do eixo 40 ISO Velocidades 40 - 2000 rpm Alimentação X-Y-Z 14 - 700 mm/min Corredeiras 1 e 2 m/min Motor de eixo 5,5 kW - 380 Volts Peso da máquina: 2000 kgs Acessórios cabeça de fresagem universal (2 x giratório) Líquido de arrefecimento A máquina de condição está em muito boas condições

GeneralVertical machining center in C-frame-design New DMG MORI Design Direct Measuring system X,Y,Z; Control: CELOS with Heidenhain TNC 640 Technical DataFeed rate longitudinal/transverse/vertical1-42000/1-42000/1-42000 mm/minRapid traverse longitudinal/transverse/vertical42/42/42 m/minWorking area 1Longitudinal650 mmCross520 mmVertical475 mmTool changerType of magazineChain Type of gripperDouble gripper Number of tools30 TableTable surface 960 x 570 mmMaximum load (table centre) 800 KgSlot width 14 mmNumber of Slots 5 Distance between T-Slots 100 mmSpindle speed 15,000 rpm, 200 NmMotor spindle speedMASTER® SK 40 Spindle speed 20 - 15,000 min-1 Output 46 kW / 30 kW (62 hp / 40 hp) Torque 200 Nm / 130 Nm (148 ft lbs / 96 ft lbs) (40 / 100 % duty cycle) BIG-PLUS® tools possible Tool magazine 30 pockets SK40Tool magazine 30 pockets SK40 Chain magazine with pockets and with double gri ...

Key data: 850 mm, 270 mm, 355 mm

Largura da mesa 315 mm, comprimento da mesa 1250 mm Porta-ferramentas SK 50 Faixa de velocidade 28 - 1400 rpm Faixa de alimentação 16 - 800 mm/min Curso x=850 mm, y= 270 mm, z=355 mm Carga ligada 8 kW Incl. Braçadeira elétrica horizontal Cabeça vertical em X giratória com aperto manual Dispensando como presente, não mais energizado

GeneralVertical machining center in C-frame-design New DMG MORI Design Direct Measuring system X,Y,Z; Control: CELOS with Siemens 840D sl Operate Technical DataFeed rate longitudinal/transverse/vertical1-42000/1-42000/1-42000 mm/minRapid traverse longitudinal/transverse/vertical42/42/42 m/minWorking area 1Longitudinal650 mmCross520 mmVertical475 mmTool changerType of magazineChain Type of gripperDouble gripper Number of tools60 TableTable surface 960 x 570 mmMaximum load (table centre) 800 KgSlot width 14 mmNumber of Slots 5 Distance between T-Slots 100 mmSpindle speed 20.000 rpmMotor spindle speedMASTER® HSK-A63 Spindle speed 20 - 20,000 min-1 Output 35 kW / 25 kW (47 hp / 33 hp) Torque 130 Nm / 86 Nm (96 ft lbs / 63 ft lbs) (40 / 100 % duty cycle) Tool magazine 60 pockets HSK-A63Tool magazine 60 pockets HSK-A63 Chain magazine with pockets and with double gripper, incl. manually di ...

Área de aperto de mesa: 500 x 1600 mm Movimento da mesa x: 1220 mm Movimento da mesa y: 500 mm Movimento da mesa z: 500 mm Suporte do fuso: SK 50 Velocidades do fuso: 56 - 2800 rpm Alimenta longitudinamente e transversalmente: aproximadamente 10 - 1800 mm/min Alimenta-se vertical: 2,5 - 450 mm/min electr. Ligação: 400 V, 16 kVA kW Requisito de espaço: 2000 x 2250 x 2150 mm Peso: 4500 kg

GeneralVertical-Machining centre Stealth Design; Control: CELOS X with Siemens 840D SL Operate CharacteristicsTable surface1460 x 750 mmMaximum load (table centre)1500 KgTool Magazine with30 PositionsMovement X / Y / Z1150/700/550 mmRapid feed X / Y / Z42/42/42 m/minWeight approx.12900 KgSpindle speed 15,000 rpm, 200 NmMotor spindle speedMASTER® SK 40 Spindle speed 20 - 15,000 min-1 Output 46 kW / 30 kW (62 hp / 40 hp) Torque 200 Nm / 130 Nm (148 ft lbs / 96 ft lbs) (40 / 100 % duty cycle) BIG-PLUS® tools possible Tool magazine 30 pockets SK40Tool magazine 30 pockets SK40 Chain magazine with pockets and with double gripper, incl. manually direct loading into the tool magazine Coolant-air blast change-overCoolant - Air-blast changeover external switchable via M-Function Air blast through spindle centreAir blast through spindle centre activated by M function, maintained air with low o ...

GeneralVertical Machining centre; Control: DMG MORI ERGOline IV HEIDENHAIN TNC 7 CharacteristicsTable surface900 x 600 mmTool Magazine with60 PositionsMovement X / Y / Z600/600/510 mmRapid feed X / Y / Z30/30/30 m/minAC main driveSpindle speed range 20 to 15.000 rpm AC main drive:20/14,5 kW (40/100% DC) Tool taper SK40 DIN 69871 Tool clamping according to DIN69872 Direct measuring system X,Y,ZDirect Measuring System X, Y, Z inclusive Air Purge for Measuring System Production Package 20 bar with chip conveyorProduction Package 20 bar with chip conveyor Option includes: - Internal coolant supply 20 bar - Chip conveyor (scraper type) with tank capacity: 200 l(left) - Bed flushing via M-Function - Coolant spray gun for swarf removal - External electronic handwhe Air coolant internal (through spindle centre)Air Coolant Internal (through spindle centre) switchable via M-Function maintained  ...

GeneralVertical Machining centre; Control: DMG MORI ERGOline X Multi-Touch control CharacteristicsTable surface900 x 600 mmTool Magazine with60 PositionsMovement X / Y / Z600/600/510 mmRapid feed X / Y / Z42/42/42 m/minSpindle speed range 20 to 12.000 rpmSpindle speed range 20 to 12.000 rpm AC main drive:13/9 kW (40/100% DC) Tool taper SK40 DIN 69871 Tool clamping according to DIN69872 Direct measuring system X,Y,ZDirect Measuring System X, Y, Z inclusive Air Purge for Measuring System Production Package 20 bar with chip conveyorProduction Package 20 bar with chip conveyor Option includes: - Internal coolant supply 20 bar - Chip conveyor (scraper type) with tank capacity: 200 l(left) - Bed flushing via M-Function - Coolant spray gun for swarf removal - External electronic handwhe Air coolant internal (through spindle centre)Air Coolant Internal (through spindle centre) switchable via  ...

GeneralVertical Machining centre; Control: DMG MORI ERGOline IV Multi-Touch CharacteristicsTable surface900 x 600 mmTool Magazine with30 PositionsMovement X / Y / Z600/600/510 mmRapid feed X / Y / Z30/30/30 m/minAC main driveSpindle speed range 20 to 15.000 rpm AC main drive:20/14,5 kW (40/100% DC) Tool taper SK40 DIN 69871 Tool clamping according to DIN69872 Direct measuring system X,Y,ZDirect Measuring System X, Y, Z inclusive Air Purge for Measuring System Production Package 40 barProduction Package 40 bar Option includes: - Internal coolant supply 40 bar; - Tank capacity: 600l with papertype filter; - Chip conveyor (scraper type) with tank capacity: 200 l (left) - Bed flushing via M-Function - Coolant spray gun for swarf removal - Tool clamping buttons on the headstockTool Clamping and Unclamping Buttons placed on the Headstock Cover Air coolant internal (through spindle centre)A ...

GeneralVertical Machining centre; Control: Control SIEMENS ERGOline IV CharacteristicsTable surface1400 x 600 mmTool Magazine with60 PositionsMovement X / Y / Z1100/600/510 mmRapid feed X / Y / Z30/30/30 m/minAC main driveSpindle speed range 20 to 15.000 rpm AC main drive:20/14,5 kW (40/100% DC) Tool taper SK40 DIN 69871 Tool clamping according to DIN69872 Direct measuring system X,Y,ZDirect Measuring System X, Y, Z inclusive Air Purge for Measuring System Production Package 20 bar with chip conveyorProduction Package 20 bar with chip conveyor Option includes: - Internal coolant supply 20 bar - Chip conveyor (scraper type) with tank capacity: 220 l (left) - Bed flushing via M-Function - Coolant spray gun for swarf removal - External electronic handwh Air coolant internal (through spindle centre)Air Coolant Internal (through spindle centre) switchable via M-Function maintained air with ...

GeneralVertical Machining centre; Control: DMG MORI ERGOline IV Multi-Touch CharacteristicsTable surface900 x 600 mmTool Magazine with30 PositionsMovement X / Y / Z600/600/510 mmRapid feed X / Y / Z30/30/30 m/minAC main driveSpindle speed range 20 to 15.000 rpm AC main drive:20/14,5 kW (40/100% DC) Tool taper SK40 DIN 69871 Tool clamping according to DIN69872 Direct measuring system X,Y,ZDirect Measuring System X, Y, Z inclusive Air Purge for Measuring System Touch Probe Heidenhain TS 460Touch Probe HEIDENHAIN for workpiece measuring Option includes: - TS 460 Touch probe with optical signal transmission - measuring cycles - calibration ring - case for equipment Touch probe Heidenhain TT160Touch Probe HEIDENHAIN for tool length and diameter measurement Option includes: - TT160 probe for tool measurement - measuring cycles with tool breakage monitoring - calibration tool Note: Addition ...

GeneralVertical Machining centre; Control: DMG MORI ERGOline IV HEIDENHAIN TNC 7 CharacteristicsTable surface900 x 600 mmTool Magazine with60 PositionsMovement X / Y / Z600/600/510 mmRapid feed X / Y / Z42/42/42 m/minSpindle speed range 20 to 12.000 rpmSpindle speed range 20 to 12.000 rpm AC main drive:13/9 kW (40/100% DC) Tool taper SK40 DIN 69871 Tool clamping according to DIN69872 Direct measuring system X,Y,ZDirect Measuring System X, Y, Z inclusive Air Purge for Measuring System Production Package 80 barProduction Package 80 bar Option includes: - Internal coolant supply 80 bar - Tank capacity: 600l with papertype filter - Chip conveyor (scraper type) with tank capacity: 200 l (left) - Bed flushing via M-Function - Coolant spray gun for swarf removal - E Active cooling systemActive cooling system for selected mechanical components in order to increase machine thermal stability A ...

GeneralVertical Machining Center; Control: Control SIEMENS 828D CharacteristicsTable surface850 x 650 mmSpeed max.10000 rpmDrive power (100% DC)9 kWDrive power (40% DC)13 kWTorque (100% DC)43 NmMax. torque64 NmTool Magazine with24 PositionsSpindle taperSK 40 DIN 69871 Movement X / Y / Z550/550/510 mmRapid feed X / Y / Z24/24/24 m/minDimensions (L x W x H)3,07 x 2,67 x 2,84 mWeight approx.5600 KgSK40 interfaceTool clamping SK 40 for pull-studs DIN 69872

GeneralVertical-Machining centre Direct Measuring system X,Y,Z; Control: CELOS with Siemens 840D sl Operate Technical DataFeed rate longitudinal/transverse/vertical1-42000/1-42000/1-42000 mm/minRapid traverse longitudinal/transverse/vertical42/42/42 m/minWorking area 1Longitudinal1450 mmCross700 mmVertical550 mmTool changerType of magazineWheel Type of gripperDouble gripper Number of tools30 TableTable surface 1760 x 750 mmMaximum load (table centre) 2000 KgSlot width 14 mmNumber of Slots 7 Distance between T-Slots 100 mmSpindle speed 20.000 rpmMotor spindle speedMASTER® HSK-A63 Spindle speed 20 - 20,000 min-1 Output 35 kW / 25 kW (47 hp / 33 hp) Torque 130 Nm / 86 Nm (96 ft lbs / 63 ft lbs) (40 / 100 % duty cycle) Tool magazine 30 pockets HSK-A63Tool magazine 30 pockets HSK-A63 Chain magazine with pockets and with double gripper, incl. manually direct tool loading into the tool magaz ...

GeneralHigh dynamic Vertical Drill-Tap centre with best milling performance; Control: 3D-control Siemens 840D sl Operate Working area 1Longitudinal700 mmCross420 mmVertical380 mmTechnical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minSpindle speed 24,000 rpmSpindle 24,000rpm with tool taper ISO 7388-2 - J30 BT30 / BBT 30 (BIG PLUS) possible for pull-studs ISO 7388-3 - JD30 (MAS 403-45°) at spindlespeed higher than 20.000 rpm BBT 30 (BIG PLUS) stipulated! AC-Motor 20 / 4 KW (max. / 100% ED) Watercooling Spin Integrated swivel rotary table simultaneousIntegated swivel rotary table 5-Axis simultaneous mode! Torque drives incl. direct measuring in A- and C-Axis Swivel range A-Axis -120 / + 100 degrees Max. load C-axis 100kg Table diameter C-Axis d290mm Inclusive Software package Sinumerik Mdynamics 5-ax  ...

GeneralVertical Machining Center; Control: Control SIEMENS 828D CharacteristicsTable surface850 x 650 mmSpeed max.12000 rpmDrive power (100% DC)9 kWDrive power (40% DC)13 kWTorque (100% DC)57 NmMax. torque83 NmTool Magazine with24 PositionsSpindle taperSK 40 DIN 69871 Movement X / Y / Z550/550/510 mmRapid feed X / Y / Z24/24/24 m/minDimensions (L x W x H)3,07 x 2,67 x 2,84 mWeight approx.5600 KgMechanical preparation for Oil-Mist Extractor UnitMechanical preparation for Oil-Mist Extractor Unit (opening diameter: D150 mm) SK40 interfaceTool clamping SK 40 for pull-studs DIN 69872 Tropical PackageTropical Package Option includes: - Active cooling unit for electrical cabinet - Additional ventilator for control panel Recommended from 35°C to max. 45°C environmental temperature Electronic HandwheelExternal electronic Handwheel

GeneralHorizontal machining centre - Horizontal milling head; Control: CELOS with Siemens 840D sl Operate Technical DataFeed rate longitudinal/transverse/vertical60000/60000/70000 mm/minRapid traverse longitudinal/transverse/vertical60/60/70 m/minWorking area 1Longitudinal800 mmCross1050 mmVertical900 mmCabineFull protection cabin Direct measuring systemDirect path measuring system NC rotary table with pallet changerType of Measuring system Direct measuring system Table surface 630 x 630 mmCentre bore 50 mmMaximum load (table centre) 900 KgSlot width 14 mmNumber of Slots 5 Distance between T-Slots 100 mmRotation speed max.4. Axis 40 rpm4. Axes (swivelling range) 360 x 0,001 degreePackage recirculation ballscrew spindlePackage recirculating ballscrew spindle X-,Z-axis:max. feed speed: 60.000 mm/min Y-axis: max. feed speed: 70.000 mm/min (basic machine without linear drive X-, Y-, Z-axi ...

GeneralVertical Machining Centres; Control: DMG MORI SLIMline® Multi-Touch control CharacteristicsTable surface900 x 560 mmMaximum load (table centre)600 KgSpeed max.12000 rpmDrive power (100% DC)9 kWDrive power (40% DC)13 kWTorque (100% DC)54 NmMax. torque82 NmTool Magazine with30 PositionsSpindle taperSK 40 DIN 69871 Movement X / Y / Z600/560/510 mmRapid feed X / Y / Z30/30/30 m/minDimensions (L x W x H)3,03 x 3,49 x 2,94 (5,8 x 5,5 x2,94) mWeight approx.5200 KgDirect measuring system X,Y,ZDirect Measuring System X, Y, Z inclusive Air Purge for Measuring System DMG MORI IoTconnectorIoTconnector connects DMG MORI machines as well as third-party machines with CELOS. Standardized interfaces enable data exchange between the IoTconnector and CELOS APPs such as the NETservice. The integrated firewall with automatic updates ensures the h Safety Package for Power FailureSafety Package for ...

GeneralVertical Machining Centres; Control: DMG MORI SLIMline® Multi-Touch control CharacteristicsTable surface1100 x 560 mmMaximum load (table centre)800 KgSpeed max.12000 rpmDrive power (100% DC)9 kWDrive power (40% DC)13 kWTorque (100% DC)57 NmMax. torque83 NmTool Magazine with30 PositionsSpindle taperSK 40 DIN 69871 Movement X / Y / Z800/560/510 mmRapid feed X / Y / Z30/30/30 m/minDimensions (L x W x H)3,3 x 2,7 x 2,94 mWeight approx.5550 KgDirect measuring system X,Y,ZDirect Measuring System X, Y, Z inclusive Air Purge for Measuring System inlineMASTER® spindle 12.000 rpminlineMASTER® spindle 12.000 rpm Spindle speed range 20 to 12.000 rpm Tool Taper SK40 DIN69871 with BIG PLUS inteface Tool clamping according to DIN69872 Power: 13kW (40% DC) / 9kW (100% DC) Torque: 83 Nm (40% DC) / 57 Nm (100% DC) bearings oil-air lubr SK40 interfaceTool clamping SK 40 for pull-studs DIN 6987 ...

GeneralHighly productive compact machining centres; Control: Siemens 840D solutionline Technical DataFeed rate longitudinal/transverse/vertical1-60000/1-60000/1-60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minWorking area 1Longitudinal700 mmCross420 mmVertical380 mmMiscellaneousClamping SystemMAS 403 - 45° Floor space/WeightDimensions (L x W x H)1,65 x 2,34 x 2,5 (1,65 x 2,95 x 2,55) mWeight approx.4100 KgSpindle speed up to 24,000 r.p.m. BT30Spindle 24,000rpm with tool taper BT30 JIS B 6339 (MAS 403-45°) AC-Motor 20 / 4 KW (max. / 100% ED) Watercooling Spindle and Spindle motor via heat exchanger (fan) TableTable surface 840 x 420 mmMaximum load (table centre) 300 KgSlot width 14 mmNumber of Slots 2 Clamping grid M 12, 100 x 100 mmTool clamping for BBT 30 (Big+)Tool taper BBT 30 - Big+ Pull stud MAS 403 - 45° Tool magazine 25 placesTool magazine 25 places  ...

GeneralVertical Machining Centres; Control: Control F0iMF CharacteristicsTable surface1400 x 560 mmMaximum load (table centre)1000 KgSpeed max.12000 rpmDrive power (100% DC)11 kWDrive power (25% DC)15 kWTool Magazine with60 PositionsSpindle taperBT 40 Movement X / Y / Z1100/560/510 mmRapid feed X / Y / Z36/36/30 m/minDimensions (L x W x H)3,19 x 2,76 x 2,94 (3,82 x 3,58 x 3,01) mWeight approx.5500 KgStandard spindle 12,000 min-1, 15/ 11 kWStandard Spindle 12,000 min-1, 15/ 11 kW Spindle speed: 12,000 min-1 Output: 15/13/11 kW (20/17.33/15 HP) (25%ED/30min/cont) Torque: 119/70/57 Nm (87.76/51.62/42.04 ft·lbf) (25%ED/30min/cont) Spindle Taper 7/24 Taper #40/ Grip MAS <BT40>Spindle Taper 7/24 Taper #40/ Grip MAS <BT40> This specification uses the spindle No. 40 7/24 taper / Grip MAS tool holder. The grip type and retention knob type of ATC are specified separately. Retenti ...

GeneralHigh dynamic Vertical Drill-Tap centre with best milling performance; Control: 3D-control Siemens 840D sl Operate Working area 1Longitudinal350 mmCross420 mmVertical380 mmTechnical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minMain driveDrive power (100% DC) 6 kWDrive power (40% DC) 8,5 kWTorque (100% DC) 41 NmTorque (40% DC) 48 NmSpeed range 20 - 15000 rpmSpindle taper BT 30 Clamping System ISO 7388-3 - JD30 Toolchangertoolchanger Type of magazine Wheel Number of tools 15 TableTable surface 740 x 420 mmMaximum load (table centre) 400 KgPreparation NC-Devider EA510 indirectPreparation 4.th axis Lehmann EA 510.L indirect measuring System Attention: Customer specific optimisations and adjustments are not part of delivery! Chip removal package with chip conveyorChip removal package with chip conve ...

GeneralVertical Machining Centre; Control: 3D control Heidenhain iTNC 530 Technical DataFeed rate longitudinal/transverse/vertical1-90000/1-90000/1-90000 mm/minRapid traverse longitudinal/transverse/vertical90/90/90 m/minWorking area 1Longitudinal885 mmCross600 mmVertical600 mmMiscellaneousClamping SystemHSK-A 63 Colour Floor space/WeightDimensions (L x W x H)4,9 x 4,3 x 3,2 mWeight approx.12000 KgCabineFull protection cabin DMC 75 V linear in 5-axes-versionAdditional price DMC 75V linear in 5-axes-version - motion in X=885mm und Z=600mm - spindle speed up to 18.000rpm, - tool-taper HSK-A 63, - swiveling range B-axis +10° to -110°, - swiveling speed B-axis 50rpm, - max. torque 750Nm / 553ft/lbs - clampi Tool magazine 150 pocketsTool magazine 150 pockets Tower type magazine Only available for HSK Tool holders. (differently from standard) Number of tools 150 Preparation measuring p ...

GeneralVertical-Machining centre Stealth Design; Control: CELOS with Heidenhain TNC 640 Technical DataFeed rate longitudinal/transverse/vertical1-42000/1-42000/1-42000 mm/minRapid traverse longitudinal/transverse/vertical42/42/42 m/minWorking area 1Longitudinal1450 mmCross700 mmVertical550 mmIntegrated motor spindle speedMASTER®Integrated motor spindle speedMASTER® At speeds > 18.000 min-1, the use of tools with dual contact system (BIG-PLUS®) is stipulated. Drive power (100% DC) 25 kWDrive power (40% DC) 35 kWTorque (100% DC) 86 NmTorque (40% DC) 130 NmSpeed range - 20000 rpmSpindle taper SK40 Tool holder DIN ISO 7388-1-A Clamping System DIN ISO 7388-3-AD TableTable surface 1760 x 750 mmMaximum load (table centre) 1500 KgSlot width 14 mmNumber of Slots 7 Distance between T-Slots 100 mmCabin roofCabin roof In sheet steel design Open and close via front door Special equipmentClam ...

GeneralVertical Machining Center; Control: Control SIEMENS 828D CharacteristicsTable surface850 x 650 mmDimensions (L x W x H)3,07 x 2,67 x 2,84 mRapid feed X / Y / Z24/24/24 m/minMovement X / Y / Z550/550/510 mmSpindle taperSK 40 DIN 69871 Tool Magazine with24 PositionsMax. torque83 NmTorque (100% DC)57 NmDrive power (40% DC)13 kWDrive power (100% DC)9 kWSpeed max.12000 rpmWeight approx.5600 KgMechanical preparation for Oil-Mist Extractor UnitMechanical preparation for Oil-Mist Extractor Unit (opening diameter: D150 mm)SK40 interfaceTool clamping SK 40 for pull-studs DIN 69872Electronic HandwheelExternal electronic Handwheel

GeneralVertical Machining Center; Control: Control SIEMENS 828D CharacteristicsTable surface850 x 650 mmRapid feed X / Y / Z24/24/24 m/minMovement X / Y / Z550/550/510 mmDimensions (L x W x H)3,07 x 2,67 x 2,84 mSpindle taperSK 40 DIN 69871 Tool Magazine with24 PositionsTorque (100% DC)43 NmMax. torque64 NmDrive power (40% DC)13 kWDrive power (100% DC)9 kWSpeed max.10000 rpmWeight approx.5600 KgSK40 interfaceTool clamping SK 40 for pull-studs DIN 69872

GeneralVertical Machining Center; Control: Control SIEMENS 828D CharacteristicsTable surface850 x 650 mmDimensions (L x W x H)3,07 x 2,67 x 2,84 mRapid feed X / Y / Z24/24/24 m/minMovement X / Y / Z550/550/510 mmSpindle taperSK 40 DIN 69871 Tool Magazine with24 PositionsMax. torque83 NmTorque (100% DC)57 NmDrive power (40% DC)13 kWDrive power (100% DC)9 kWSpeed max.12000 rpmWeight approx.5600 KgMechanical preparation for Oil-Mist Extractor UnitMechanical preparation for Oil-Mist Extractor Unit (opening diameter: D150 mm)4th Axis package4th Axis package Option includes: - rotary table type EA-510.L NE with indirect measuring system - electrical and pneumatic preparation - software preparation to work with rotary table - cycle TRACYL which allows to define contour on the cylinder - swSK40 interfaceTool clamping SK 40 for pull-studs DIN 69872Air coolant external and internalAir coolant ...

CharacteristicsTable surface850 x 650 mmDimensions (L x W x H)3,07 x 2,67 x 2,84 mRapid feed X / Y / Z24/24/24 m/minMovement X / Y / Z550/550/510 mmSpindle taperSK 40 DIN 69871 Tool Magazine with24 PositionsMax. torque83 NmTorque (100% DC)57 NmDrive power (40% DC)13 kWDrive power (100% DC)9 kWSpeed max.12000 rpmWeight approx.5600 KgGeneralVertical Machining Center; Control: Control SIEMENS 828D Mechanical preparation for Oil-Mist Extractor UnitMechanical preparation for Oil-Mist Extractor Unit (opening diameter: D150 mm)SK40 interfaceTool clamping SK 40 for pull-studs DIN 69872Air coolant external and internalAir coolant external and internal (through spindle centre) switchable via M-FunctionElectronic HandwheelExternal electronic Handwheel

GeneralVertical Machining Center; Control: Control SIEMENS 828D CharacteristicsTable surface850 x 650 mmDimensions (L x W x H)3,07 x 2,67 x 2,84 mRapid feed X / Y / Z24/24/24 m/minMovement X / Y / Z550/550/510 mmSpindle taperSK 40 DIN 69871 Tool Magazine with24 PositionsMax. torque83 NmTorque (100% DC)57 NmDrive power (40% DC)13 kWDrive power (100% DC)9 kWSpeed max.12000 rpmWeight approx.5600 KgMechanical preparation for Oil-Mist Extractor UnitMechanical preparation for Oil-Mist Extractor Unit (opening diameter: D150 mm)SK40 interfaceTool clamping SK 40 for pull-studs DIN 69872Electronic HandwheelExternal electronic Handwheel

CharacteristicsTable surface850 x 650 mmDimensions (L x W x H)3,07 x 2,67 x 2,84 mRapid feed X / Y / Z24/24/24 m/minMovement X / Y / Z550/550/510 mmSpindle taperSK 40 DIN 69871 Tool Magazine with24 PositionsMax. torque83 NmTorque (100% DC)57 NmDrive power (40% DC)13 kWDrive power (100% DC)9 kWSpeed max.12000 rpmWeight approx.5600 KgGeneralVertical Machining Center; Control: Control SIEMENS 828D Mechanical preparation for Oil-Mist Extractor UnitMechanical preparation for Oil-Mist Extractor Unit (opening diameter: D150 mm)SK40 interfaceTool clamping SK 40 for pull-studs DIN 69872Electronic HandwheelExternal electronic Handwheel

GeneralVertical Machining Center; Control: Control SIEMENS 828D CharacteristicsTable surface850 x 650 mmSpeed max.12000 rpmDrive power (100% DC)9 kWDimensions (L x W x H)3,07 x 2,67 x 2,84 mRapid feed X / Y / Z24/24/24 m/minMovement X / Y / Z550/550/510 mmSpindle taperSK 40 DIN 69871 Tool Magazine with24 PositionsMax. torque83 NmTorque (100% DC)57 NmDrive power (40% DC)13 kWWeight approx.5600 KgMechanical preparation for Oil-Mist Extractor UnitMechanical preparation for Oil-Mist Extractor Unit (opening diameter: D150 mm)Tool Clamping BT 40Tool Clamping BT 40 for pull-studs DIN 69872 (differently from standard)Electronic HandwheelExternal electronic Handwheel

GeneralVertical Machining Center; Control: Control SIEMENS 828D CharacteristicsSpeed max.12000 rpmDimensions (L x W x H)3,07 x 2,67 x 2,84 mRapid feed X / Y / Z24/24/24 m/minMovement X / Y / Z550/550/510 mmSpindle taperBT 40 Tool Magazine with24 PositionsTorque (100% DC)57 NmMax. torque83 NmDrive power (40% DC)13 kWDrive power (100% DC)9 kWTable surface850 x 650 mmWeight approx.5600 KgMechanical preparation for Oil-Mist Extractor UnitMechanical preparation for Oil-Mist Extractor Unit (opening diameter: D150 mm)Tool Clamping BT 40Tool Clamping BT 40 for pull-studs DIN 69872 (differently from standard)Electronic HandwheelExternal electronic Handwheel

GeneralVertical Machining Center; Control: Control SIEMENS SINUMERIK ONE CharacteristicsTable surface1400 x 600 mmDimensions (L x W x H)2,74 x 2,74 x 2,86 mRapid feed X / Y / Z24/24/24 m/minMovement X / Y / Z1100/550/510 mmSpindle taperSK 40 DIN 69871 Tool Magazine with24 PositionsMax. torque83 NmTorque (100% DC)57 NmDrive power (40% DC)13 kWDrive power (100% DC)9 kWSpeed max.12000 rpmWeight approx.6950 KgMechanical preparation for Oil-Mist Extractor UnitMechanical preparation for Oil-Mist Extractor Unit (opening diameter: D150 mm)SK40 interfaceTool clamping SK 40 for pull-studs DIN 69872Electronic HandwheelExternal electronic Handwheel

GeneralVertical Machining Centres; Control: 3D-control Heidenhain TNC 620 CharacteristicsMaximum load (table centre)1000 KgDimensions (L x W x H)3,93 x 3,49 x 2,94 (6,3 x 5,5 x 2,94) mRapid feed X / Y / Z30/30/30 m/minMovement X / Y / Z1100/560/510 mmSpindle taperSK 40 DIN 69871 Tool Magazine with30 PositionsDrive power (40% DC)13 kWMax. torque83 NmTorque (100% DC)57 NmDrive power (100% DC)9 kWSpeed max.12000 rpmTable surface1400 x 560 mmWeight approx.6050 KgDirect measuring system X,Y,ZDirect Measuring System X, Y, Z inclusive Air Purge for Measuring SystemDMG MORI IoTconnectorIoTconnector connects DMG MORI machines as well as third-party machines with CELOS. Standardized interfaces enable data exchange between the IoTconnector and CELOS APPs such as the NETservice. The integrated firewall with automatic updates ensures the hProduction Package 20 bar with chip conveyorProduction Packa ...

GeneralVertical Machining Centres; Control: 3D-control Heidenhain TNC 620 CharacteristicsTable surface1400 x 560 mmDimensions (L x W x H)3,93 x 3,49 x 2,94 (6,3 x 5,6 x 2,94) mRapid feed X / Y / Z30/30/30 m/minMovement X / Y / Z1100/560/510 mmSpindle taperSK 40 DIN 69871 Tool Magazine with60 PositionsMax. torque121 NmTorque (100% DC)84 NmDrive power (40% DC)20 kWDrive power (100% DC)14,5 kWSpeed max.15000 rpmMaximum load (table centre)1000 KgWeight approx.6200 KgDirect measuring system X,Y,ZDirect Measuring System X, Y, Z inclusive Air Purge for Measuring SystemDMG MORI IoTconnectorIoTconnector connects DMG MORI machines as well as third-party machines with CELOS. Standardized interfaces enable data exchange between the IoTconnector and CELOS APPs such as the NETservice. The integrated firewall with automatic updates ensures the hProduction Package 40 barProduction Package 40 bar Optio ...

GeneralVertical Machining Centres; Control: 3D-control Heidenhain TNC 620 CharacteristicsTable surface1400 x 560 mmDimensions (L x W x H)3,93 x 3,49 x 2,94 (6,3 x 5,5 x 2,94) mRapid feed X / Y / Z30/30/30 m/minMovement X / Y / Z1100/560/510 mmSpindle taperSK 40 DIN 69871 Tool Magazine with30 PositionsMax. torque83 NmTorque (100% DC)57 NmDrive power (40% DC)13 kWDrive power (100% DC)9 kWSpeed max.12000 rpmMaximum load (table centre)1000 KgWeight approx.6050 KgDirect measuring system X,Y,ZDirect Measuring System X, Y, Z inclusive Air Purge for Measuring SystemProduction Package 3 with Chip ConveyorProduction Package 3 Option includes: - Internal coolant supply 40 bar; - Tank capacity: 600l with papertype filter; - Chip conveyor (scraper type) with tank capacity: 250 l (left) - Bed and ATC arm flushing via M-Function - Coolant spray gun for swarfPrep. 4th axis EA 510.L indirect (Heidenha ...

GeneralVertical Machining Center; Control: Control SIEMENS 828D CharacteristicsTable surface850 x 650 mmDimensions (L x W x H)3,07 x 2,67 x 2,84 mRapid feed X / Y / Z24/24/24 m/minMovement X / Y / Z550/550/510 mmSpindle taperSK 40 DIN 69871 Tool Magazine with24 PositionsMax. torque83 NmTorque (100% DC)57 NmDrive power (40% DC)13 kWDrive power (100% DC)9 kWSpeed max.12000 rpmWeight approx.5600 KgMechanical preparation for Oil-Mist Extractor UnitMechanical preparation for Oil-Mist Extractor Unit (opening diameter: D150 mm)SK40 interfaceTool clamping SK 40 for pull-studs DIN 69872

GeneralVertical Machining Center; Control: Control SIEMENS 828D CharacteristicsTable surface850 x 650 mmDimensions (L x W x H)3,07 x 2,67 x 2,84 mRapid feed X / Y / Z24/24/24 m/minMovement X / Y / Z550/550/510 mmSpindle taperSK 40 DIN 69871 Tool Magazine with24 PositionsMax. torque83 NmTorque (100% DC)57 NmDrive power (40% DC)13 kWDrive power (100% DC)9 kWSpeed max.12000 rpmWeight approx.5600 KgMechanical preparation for Oil-Mist Extractor UnitMechanical preparation for Oil-Mist Extractor Unit (opening diameter: D150 mm)4th Axis package4th Axis package Option includes: - rotary table type EA-510.L NE with indirect measuring system - electrical and pneumatic preparation - software preparation to work with rotary table - cycle TRACYL which allows to define contour on the cylinder - swSK40 interfaceTool clamping SK 40 for pull-studs DIN 69872

GeneralVertical Machining Center; Control: Control SIEMENS 828D CharacteristicsTable surface850 x 650 mmDimensions (L x W x H)3,07 x 2,67 x 2,84 mRapid feed X / Y / Z24/24/24 m/minMovement X / Y / Z550/550/510 mmSpindle taperSK 40 DIN 69871 Tool Magazine with24 PositionsTorque (100% DC)57 NmMax. torque83 NmDrive power (40% DC)13 kWDrive power (100% DC)9 kWSpeed max.12000 rpmWeight approx.5600 KgMechanical preparation for Oil-Mist Extractor UnitMechanical preparation for Oil-Mist Extractor Unit (opening diameter: D150 mm)4th Axis package4th Axis package Option includes: - rotary table type EA-510.L NE with indirect measuring system - electrical and pneumatic preparation - software preparation to work with rotary table - cycle TRACYL which allows to define contour on the cylinder - swSK40 interfaceTool clamping SK 40 for pull-studs DIN 69872Electronic HandwheelExternal electronic Hand ...

GeneralVertical Machining Center; Control: Control SIEMENS 828D CharacteristicsTable surface850 x 650 mmDimensions (L x W x H)3,07 x 2,67 x 2,84 mRapid feed X / Y / Z24/24/24 m/minMovement X / Y / Z550/550/510 mmSpindle taperSK 40 DIN 69871 Tool Magazine with24 PositionsMax. torque83 NmTorque (100% DC)57 NmDrive power (40% DC)13 kWDrive power (100% DC)9 kWSpeed max.12000 rpmWeight approx.5600 KgMechanical preparation for Oil-Mist Extractor UnitMechanical preparation for Oil-Mist Extractor Unit (opening diameter: D150 mm)SK40 interfaceTool clamping SK 40 for pull-studs DIN 69872Air coolant external and internalAir coolant external and internal (through spindle centre) switchable via M-FunctionElectronic HandwheelExternal electronic Handwheel

GeneralVertical Machining Centres; Control: DMG MORI SLIMline® Multi-Touch control CharacteristicsTable surface1400 x 560 mmDimensions (L x W x H)6,31 x 4,8 x 2,94 mRapid feed X / Y / Z30/30/30 m/minMovement X / Y / Z1100/560/510 mmSpindle taperSK 40 DIN 69871 Tool Magazine with30 PositionsMax. torque82 NmTorque (100% DC)54 NmDrive power (40% DC)13 kWMaximum load (table centre)1000 KgDrive power (100% DC)9 kWSpeed max.12000 rpmWeight approx.5850 KgSK40 interfaceTool clamping SK 40 for pull-studs DIN 69872Preparation 4th axis EA 510.L indirect (Siemens)Preparation for rotary table (4th axis) Lehmann EA-510.L with indirect measuring system Option includes: - Electrical and pneumatic preparation - Software preparation to work with rotary table - Cycle TRACYL which allows to define contour on the cylinDirect measuring system X,Y,ZDirect Measuring System X, Y, Z inclusive air purge for m ...

Working area 1Longitudinal700 mmCross420 mmVertical380 mmGeneralHigh dynamic Vertical Drill-Tap centre with best milling performance; Control: 3D-control Siemens 840D sl Operate Technical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minMain driveDrive power (100% DC) 6 kWDrive power (40% DC) 8,5 kWClamping System ISO 7388-3 - JD30Spindle taper BT 30Speed range 20 - 10000 rpmTorque (40% DC) 48 NmTorque (100% DC) 41 NmIntegrated swivel rotary table simultaneousIntegated swivel rotary table 5-Axis simultaneous mode! Torque drives incl. direct measuring in A- and C-Axis Swivel range A-Axis -120 / + 100 degrees Max. load C-axis 100kg Table diameter C-Axis d290mm Inclusive Software package Sinumerik Mdynamics 5-axRotary joint, 4 channelsRotary joint for integrated swivel rotary table with torque drives 4- cha ...
