Centros de torno CNC MORI SEIKI NTX1000
máquinas para trabalhar metal / tornos / Centros de torno CNC
turning diameter: 370 mmturning length: 424 mmcontrol: MSX-711-IV Mori Seikiswing diameter: 370 mmX1- Axis: 380 mmX2- Axis: 155 mmZ1- Axis: 460+155 mmZ2- Axis: 610 mmy-axis: +/- 105 mmB - axis: +/- 120 °bar material dia.: 65 mmspeed spindle max.: S1 5.000 / S2 6.000 U/min.spindle bore: S1/S2 65/38 ...
Fabricante: MORI SEIKI
Modelo:NTX1000
Tipo de máquina: Centros de torno CNC
Número do item: 169723566
Quantidade: 1
Data: 19.06.2026
Ano de fabricação: 2012
Localização: Nürnberg
Preço:
Máquina em estoque:Sim
Seller-item-No.:1006-17959
turning diameter: 370 mm
turning length: 424 mm
control: MSX-711-IV Mori Seiki
swing diameter: 370 mm
X1- Axis: 380 mm
X2- Axis: 155 mm
Z1- Axis: 460+155 mm
Z2- Axis: 610 mm
y-axis: +/- 105 mm
B - axis: +/- 120 °
bar material dia.: 65 mm
speed spindle max.: S1 5.000 / S2 6.000 U/min.
spindle bore: S1/S2 65/38 mm
: 12000 1/min
tool taper: Capto C5
toolpiece magazine: chain magazine: 76 Stück
tool turret with 10 work positions:
total power requirement: 45 kW
weight of the machine ca.: 10,5 t
dimensions of the machine ca.: 2,71 x 2,43 x 2,40 m
MAPPS control system
Renishaw HPRA (manual tool presetter)
Blum Laser Control
Direct measuring system X,Y,Z,B
Collet chuck SMW Autoblok KSZ-MB-040-Z140
Workpiece conveyor belt
Bar feeder Breuning Irco ILS-RBK-10012
Knoll band filter KF10/500 / IKZ with milling spindle 7 stages up to 70 bar
Chip conveyor ConSep 2000
The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
turning length: 424 mm
control: MSX-711-IV Mori Seiki
swing diameter: 370 mm
X1- Axis: 380 mm
X2- Axis: 155 mm
Z1- Axis: 460+155 mm
Z2- Axis: 610 mm
y-axis: +/- 105 mm
B - axis: +/- 120 °
bar material dia.: 65 mm
speed spindle max.: S1 5.000 / S2 6.000 U/min.
spindle bore: S1/S2 65/38 mm
: 12000 1/min
tool taper: Capto C5
toolpiece magazine: chain magazine: 76 Stück
tool turret with 10 work positions:
total power requirement: 45 kW
weight of the machine ca.: 10,5 t
dimensions of the machine ca.: 2,71 x 2,43 x 2,40 m
MAPPS control system
Renishaw HPRA (manual tool presetter)
Blum Laser Control
Direct measuring system X,Y,Z,B
Collet chuck SMW Autoblok KSZ-MB-040-Z140
Workpiece conveyor belt
Bar feeder Breuning Irco ILS-RBK-10012
Knoll band filter KF10/500 / IKZ with milling spindle 7 stages up to 70 bar
Chip conveyor ConSep 2000
The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
