máquinas de corte e de denteamento usadas para venda (206)

max. wheel diameter:280 mmmax. module:7 weight of the machine ca.:13 ttable turning speeds:100 U/mintable diameter:250 mmmin. number of teeth:4 hob turning speeds:1500 U/minmax. hob diameter:160 cutter length max.:230 mmMachine in good condition.Available 01.08.2024

max. wheel diameter: 420 mmgear width: 120 mmmax. module: 7 mmmin. module: 0,5 gear hobbing diameter - external: 420 mmgear hobbing diameter - internal: 370 mmtable diameter: 400 mmboring diameter: 125 mmspindle stroke: 120 mmstroke position adjustment: 230 mmstrokes - infinitely variable: 30 / 800 Hub/mindepth feed stepless: 0,016 - 0,063 mm/Hubtotal power requirement: 35 kWweight of the machine ca.: 7,5 tdimensions of the machine ca.: 2,46 x 3,48 x 2,66 mAccessories: - Various replacement wheels and blade holders - DocumentationThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. wheel diameter: 180 mmtable diameter: 145 mmmax. module: 3-5 mmgear width: 250 mmtable turning speeds: 800 U/minmilling head vertical adjustable: 400 mmMilling axis swiveling range: + / - 45 °max. milling cutter diameter: 90 mmhob turning speeds: 0 - 6000 U/mincutter length max.: 211 mmcontrol: Siemens 840 Dtotal power requirement: 23 kWweight of the machine ca.: ca. 10 tdimensions of the machine ca.: 4,5 x 3,5 x 2,7 mThe LC series is a machine system for the machining of spur and helical gears and cylindrical gear shafts and helical gears and cylindrical gear shafts, which is characterised by its special performance and versatility.Compared to other gear manufacturing processes, gear hobbing is characterised by its characterised by its high consistency of machining results over the entire tool life.Technical data of the machine:Basic specifications:--> Machining type: dry--> Volta ...

max. wheel diameter: 180 mmgear width: ca. 220 mmmax. module: 3 / 5 mmControl: Siemens 840D sl max. radial velocity: 5000 mm/minmax. workpiece diameter: 180 mmtable rotation speed: 800 U/mintable diameter: 145 mmaxial travel: 250 mm mmback rest:: axial travel: 300 mmclamping force max.: 13 kNmilling head:: swivelable +/-: 45 °drive capacity: 23 kWturning speeds: 6000 U/mindiameter of tools max.: 90 mmtool clamping length max.: 211 mmmodule hobbing max.: 3 module profile milling max.: 5 tangential speed max.: 7500 mm/minweight of the machine ca.: 9,5 tdimensions of the machine ca.: 4,5 x 3,5 x 2,7 mEquipment / Accessories:- The machine is equipped for dry milling.- workpiece magazine- parallel gripper: - workpiece weight form-fit max. 15 kg - workpiece length max. 400 mmThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Maximum workpiece outer diameter: 3420 mmMinimum workpiece inner diameter: 630 mmmax. module: 30 mmcontrol: Siemens Sinumerik 840 D Workpiece tooth width - max.: 600 mmtip circle diameter: 440 mmMilling arbour diameter: 80 mmx-travel: 1110 mmy-travel: 1300 mmspindle turning speed - stepless: 18 - 180 U/minrotary table speeds infinitely variable: 0 - 6 U/minRing stength: 500 mmtotal connected load: 100 kVAweight of the machine ca.: 38 tdimensions of the machine ca.: 8,41 x 9,05 x 5,19 mFeed rate: - X-axis 1 to 3000 mm/min - Z-axis 1 to 4000 mm/min Spindle speeds in 1/min - Tool 18 to 180 - Workpiece table 0 to 6Equipment/accessories: - IFK2 internal milling head - Milling arbor with spacer discs - Chip conveyor - Oil mist extraction - Dry machining only - Technical documentation The data for this ad was created with ModulMWS - the software so ...

ratio of transmission: 10:1 min. number of teeth: 3 max. number of teeth: 200 range of tooth size: 20 mmtooth width max.: 58 mmspindle speeds (infinitely variable): 6000 U/minwork piece spindle speed: 1200 U/mindiameter of tools max.: 230 mmdiameter of tools min: 69,85 mmx-axis: 325 mmy-axis: 350 mmz-axis: 470 mmb-axis: + 90,1 / - 1 °work piece table - Ø: 212,71 mmControl: SIN 840 D SIEMENStotal power requirement: 75 kWweight of the machine ca.: 10.000 Kgdimensions of the machine ca.: 6,10 x 4,40 x 3,30 mInternal probe Renishaw LP2 (axis X2,Y2)Hoffmann coolant filter system HSF 100SE/K (built in 2008)Tank capacity 2500LVT oil mist filter systemThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

ratio of transmission: 10:1 min. number of teeth: 3 max. number of teeth: 200 range of tooth size: 20 mmdiameter of tools min: 69,85 mmtooth width max.: 58 mmdiameter of tools max.: 230 mmx-axis: 325 mmy-axis: 350 mmz-axis: 470 mmwork piece table - Ø: 212,71 mmb-axis: + 90,1 / - 1 °Control: 160 i - MB FANUCtotal power requirement: 75 kWweight of the machine ca.: 10.000 Kgdimensions of the machine ca.: 6,10 x 4,40 x 3,30 mWAGURIWith EWAB robot cell (KUKA robot)without coolant filter systemFire extinguishing system without CO2 bottlesCooling oil return with various pumps / collecting basinsThreading device A1/B2 axes with measuring probeClamping device for a pinion shaftExternal spindle oil coolerExtraction system pinion shaftThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

ratio of transmission: 10:1 min. number of teeth: 3 max. number of teeth: 200 range of tooth size: 20 mmtooth width max.: 58 mmdiameter of tools min: 69,85 mmdiameter of tools max.: 230 mmx-axis: 325 mmy-axis: 350 mmz-axis: 470 mmwork piece table - Ø: 212,71 mmb-axis: + 90,1 / - 1 °Control: SIN 840 D SIEMENStotal power requirement: 75 kWweight of the machine ca.: 10.000 Kgdimensions of the machine ca.: 6,10 x 4,40 x 3,30 mWAGURIwith EWAB load cell built in 2012(Linear loader)no coolant filter system available The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. machining diameter: 3200 mmmax. workpiecediameter: 3200 mmaxial slide way: 2200 mmcontrol: Siemens Sinumerik 840 D table diameter: 2500 mmboring diameter: 800 mmmax. load: 40.000 kgtable rotation speed: 2 U/mingrinding head: grinding head - swivable: +45 / - 45 °turning speed range - grinding wheel: 270 - 2700 U/mintip circle diameter: min. 1500 mmgrinding spindel dia.: 100 mmMax. grinding wheel diameter: 450 mmDressing diameter: min. 250 mmPlaning width: min. 80 mmFast feed speed: axial: 10 m/minFast feed speed: radial: 3 m/minmax. depth of profile: 100 mmtail stock: tailstock travel: 1410 mmtotal power requirement: 225 kVAweight of the machine ca.: 46 tdimensions of the machine ca.: 14,5 x 9,95 x 6,1 mGear Profil-Grinding Machine- CNC Control Siemens 840D- Tailstock- Dressing Unit- Oil Mist suction- CoolantThe data for this ad was created with ModulMWS - the software solution o ...

max. wheel diameter: 5500 mmgear width: 1500 mmmax. module: 32 faceplate diameter: 3740 mmswing diameter: 6200 mmturning height: 1200 mmcontrol: FANUC 31i MODEL B : 1250 mmcross rail - adjustment: 3000 mmturning speeds: 3-15 U/minspindle turning speed - stepless: 15 - 1500 U/minworkpiece weight: 39,4 tmax. dia. of teeth cutting: 5500 mmtooth width: 550 mmmodule: 32 cutter speeds: 10 -150 U/minmilling cutter dia. x width: 450 x 110 mmmilling head axial adjustable: 2060 mmtotal power requirement: - kWweight of the machine ca.: - tdimensions of the machine ca.: - mComplex TurnMill & Gear Cutting Machine- CNC control FANUC 31i B- Turning and Milling Function- ATC- Angular Milling Head- Gear Hobbing (internal and external)- Chip ConveyorThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. wheel diameter: 3000 mmgear width: 500 mmmax. module: 25 / 40 spindle turning speed range: 250 U/minfeed speeds: max. 4000 mm/minfaceplate diameter: 2000 mmtable bore diameter: 700 mmtable turning speeds: 51 U/minpower capacity - milling spindle: 53 kWdrive motor for milling spindle: - kWaxial adjustment: 1200 mmmilling head swivable ca.: +/- 45 °control: Siemens 840D total power requirement: - kWweight of the machine ca.: 55 t- CNC Control Siemens 840D- Internal Hob Head IFK- External Hob HeadThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. wheel diameter: 3000 mmgear width: 1200 mmmax. module: 30/40 min. module: 2 table diameter: 2500 mmtable load capacity: 400 kNhob dia. - max.: 450 x 500 mmmilling spindle speeds: 10 - 165 U/minhob length max.: 500 mmtip circle diameter: 2050 mmtooth helical angle min/max: 0 - 45 °center distance betw. workpiece-tool min/max.: 150 - 1750 mmmilling slide swivelling: 50 Graddistance table / counter stay: 1050 - 2050 mmshifting: 300 mmworkpiece weight: 40 ttable bore diameter: 800 mmdepth of hole: 1100 mmmain drive motor: 37 kWmin. workpiece diameter: 290 mmmin. number of teeth: Wälzfräsen 20 min. number of teeth: Formfräsen 2 taper: MK 100 feeds axial: 1 - 1680 mm/minradial feed: 1 - 500 mm/minfeed: Tangential 1 - 280 mm/minrapid traverse: 1680 / 530 / 280 mm/minelectrics - voltage/frequency: 380 / 50 V/Hzcontrol: Siemens Sinumerik 3M total power requirement: 125 kVAweight of the m ...

max. wheel diameter: 650 mmgear width: 200 mmmax. module: 10 min. module: 1 work accuracy: DIN 6 clamping table diameter: 710 mmtable bore diameter: 150 mmnumber of strokes - stepless: 35,5 - 560 c/minmax. ram stroke: 230 mmfeeds: 3,55 - 40 mm/minradial feed: 0,8 - 9 mm/minwork-spindle diameter: 110 mmtotal power requirement: 28,2 kWweight of the machine ca.: 9 tdimensions of the machine ca.: 3,8 x 2,3 x 2,5 mGear shaping machine for the production of spur gears, forInternal and external gears - Built under licence from LORENZ and identical in construction to LORENZ LS 630complete Modernisation + overhaul in 2012 with:- new painting- new electrical system from Telemecanique- Counter Holder- Chip conveyor- Coolant unit- change gearsNot used in production again after overhaulThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. wheel diameter: 1600 mmgear width: 250 mmmax. module: 20 min. module: 1,5 base circle dia. - max.: 1450 mmbase circle dia. - min.: 150 mmspecimen weight from/to: 4000 kgfeeler adjustment movement - parallel: 1400 mmmax.helical angle: 0 - 90 °wheel diameter with counterstay: 1000 mmfeeler adjustment movement - parallel: 800 mmcentre height: 1150 mmelectrics - voltage/frequency: 400 / 50 V/Hzdimensions of the machine ca.: 2,8 x 2,4 x 2,3 mtotal power requirement: 2 kWweight of the machine ca.: 3 tUniversal Involute and Helix Testing Machine - modernized 1995Machine is suitable for measuring all individual tooth data on straight and helical spur gears, and shaping andshaving cutters. Following tooth data can be t ...

max. wheel diameter: 2000 mmgear width: . mmmax. module: 22 max. hob diameter: 250 mmhob turning speeds: 16-92 U/mintotal power requirement: 13 kWweight of the machine ca.: tdimensions of the machine ca.: mThe tech. Data are manufacturer or operator information and therefore non-binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively.About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit.Your Markus Hirsch TeamThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. wheel diameter: 600 mmgear width: 150 mmmax. module: 15 min. module: 1 clamping length min.: 45 mmclamping length max.: 750 mmworkpiece weight: 150 kgtotal power requirement: kWweight of the machine ca.: 0,55 tdimensions of the machine ca.: 1,2x0,8x1,95 mWorkpiece diameter with counterholder 300The tech. Data are manufacturer or operator information and therefore non-binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively.About us Morethan 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit.Your Markus Hirsch TeamThe data for this ad was created wit ...

max. wheel diameter: 0-200 mmmax. module: 25 min. module: 0,5 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

workpiece dia.: 40 mmmax. module: 2 min. module: 0,1 workpiece length - max.: 665 mmweight: 4,5 tspindle bore diameter: 82,5 mmControl: Siemens total power requirement: 5,5 kWTechnical datamax. module 2Pitch 0.5 - 25 mmNumber of speeds multi-speed / multiplemax. workpiece diameter40 mmmax. workpiece length180 mmMilling cutter diameter max.80 mmmax. milling cutter width12 mmZ-axis (milling length with counter point)90 mmZ-axis (milling length without counter point)113 mmMilling head swivelling angle30° / 30°DescriptionGear hobbing and thread cutting machine. LAMBERT - 124 CNCThe machine is in a well-maintained condition.The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

hobbing length: 1750 mmmilling width: 260 mmmax. module: 10 mmtable size incl. water gutter: 460 x 2100 mmtable clamping surface:: 250 x 1850 mmcutter width - max.: 100 mmfeed of the milling slide, stepless: 0 - 500 mm/min.rapid traverse feeds: 3000 mm/minmilling head -swivable +/-: 30 °Rotation speed range of milling head, in 9 steps: 29 - 178 rpmMilling head swivable 2 sides helical gearcutting: 30 °total power requirement: kWweight of the machine ca.: 4 tdimensions of the machine ca.: 4 x 1,85 x 1,85 mEquipment/accessories- 7 vices- change wheels - Clamping devices- DocumentationThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

module: 10 diameter: 180 mmBore diameter: 40 mmwidth: 75 mm: 2 weight: 14 kgMilling cutter is as new, without signs of useOther used rack and piniongroup cutters up to module 10on requestThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

module: 4 diameter: 180 mmBore diameter: 40 mmwidth: 67 mm: 5 weight: 15 kgMilling cutter is as new, without signs of useOther used rack and piniongroup cutters up to module 10on requestThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. wheel diameter: 600 mmmax. module: 6 range L-W-H: 2540 x 1500 x 1920 mmtable diameter: 160 mmweight of the machine ca.: 3,6 tHigh-performance gear hobbing machineTooth helix angle 15°Tooth width 270 mmWheel diameter 620 mmTooth helix angle 30°Tooth width 250 mmWheel diameter 610 mmTooth helix angle 45°Tooth width 200 mmWheel diameter 500 mmTooth angle 60°Tooth width 100 mmWheel diameter 450 mmMaximum cutter diameter 105 mmMaximum cutter width 115 mmClamping table diameter 420 mmBore of clamping table 75 mmDepth of bore below table surface — mmDiameter of workpiece clamping wheel 450 mmof clamping mandrel 30 mmof milling mandrels 22–27–32 mmThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

gear hobbing diameter - external: 1200 mmgear hobbing diameter - internal: 1200 mmgear hobbing width -max.: 260 mmmax. workpiece diameter: 1500 mmControl: Siemens 840 D table diameter: 900 mmTable hole Diameter / depth: 320 / 520 mmmax. table load: 95 kNcoolant pump: 120 l/minAxial distance between thrust spindle - table: 0-820 mmwork-spindle diameter: 125 mmtool taper: SK 45 DIN Table rpm: 12 1/minpower requirement: 30 kWweight of the machine ca.: 24 tdimensions of the machine ca.: 11,715 x 5,565 x 4,505 mStrokes: - Stroke length min./max.: 0 mm / 270 mm - Stroke length adjustment range: 270 mm - Stroke rate (double strokes): 10 to 270 strokes/minSliding head carriage: - Max. travel speed: 5000 mm/min Machine bed: - Axial travel: 600 mm Slotting head: - Max. module for rolling slotting: 16 mm - Slotting spindle diameter: 125 mm - Max. tool diameter: 300 mm ...

hobbing length: 1750 mmmilling width: 260 mmmax. module: 10 table size incl. water gutter: 460 x 2100 mmtable clamping surface:: 250 x 1850 mmcutter width - max.: 100 mmfeed of the milling slide, stepless: 0 - 500 mm/min.rapid traverse feeds: 3000 mm/minmilling head -swivable +/-: 30 °Rotation speed range of milling head, in 9 steps: 29 - 178 rpmMilling head swivable 2 sides helical gearcutting: 30 °total power requirement: 4 kWweight of the machine ca.: 4 tdimensions of the machine ca.: 4 x 1,85 x 1,85 mMilling length 1750 mmMilling width 260 mmModule - max. 10Table dimensions incl. water channel 460 x 2100 mmTable clamping surface: 250 x 1850 mmMilling cutter width - max. 100 mmFeed of the milling carriage, infinitely variable 0 - 500 mm/min.Rapid traverse 3000 mm/minMilling head - tiltable + / - 30 °Speed range of the milling spindle, in 9 steps 29 - 178 rpmMilling head swivels on  ...

max. wheel diameter: 1000 mmgear width: 200 mmmax. module: 10 min. module: 0,5 max. dia. of teeth cutting: 1000 mmmin. dia. of teeth cutting: 75 mmtable diameter: 1000 mmboring diameter: 400 mmspindle stroke: 0 - 230 mmstroke position adjustment: 250 mmdistance between table / ram: 480 / 730 mmdia. of shaper cutter: 8 Zolltaper: Morse 5 tool taper: 1 3/4 Zolltotal power requirement: ca. 20 kWweight of the machine ca.: 11 tStandard version- Chip conveyor- Two additional tables with diameters of 850 mm and 1,500 mm- Several cutting tools- Set of interchangeable gears- Program for cutting in 1-2-3-4 passes/cycles- Program for spiral cutting- Several holders and clamps for workpiecesThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. wheel diameter: 1250 mmgear width: 600 mmmax. module: 16 min. module: 2 tooth width: 490 mmZahnschrägungswinkel max.: 45 °shifting: 200 mmmax. number of teeth: 12 diameter of hob: 240 mmcutter length max.: 280 mmtable diameter: 1020 mmmilling spindle speeds (infinitely variable): 28 - 200 U/minpower capacity: 25 kWweight of the machine ca.: 16,2 tdimensions of the machine ca.: 4,5 x 4,6 x 2,7 mequipped with:- universal hob head- change gearsmachine has been partly overhauled (electrical and machnical) and is now with programmable, digital InfeedThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. wheel diameter: 2500 mmgear width: 750 mmmax. module: 18 / 22 min. module: table diameter: 1800 mmmin. number of teeth: 12 table hole: 300 mmhob turning speeds: 20 - 100 U/mintable load: 10 tmilling cutter dia. x width: 250 x 340 mmshifting: 150 mmfeeds - tangential: 0,25 - 3 mm/minfeeds - radial: 0,07 - 1,5 mm/minfeeds - longitudinal: 0,55 - 3,5 mm/minmilling feeds: 13,4 - 80 (Einzelteilen) mm/mintotal power requirement: ca. 30 kWweight of the machine ca.: 28 t- change gears, arbors, toolings, clamping plots- universal hob head- swiveling outer steady - single indexing deviceparty overhauled in 2023The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

: workpiece length - max.: mmmax. module: 0total power requirement: kWweight of the machine ca.: trequired space: mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. wheel diameter: 1400 mmgear width: 400 mmmax. module: 25 min. module: 1 total power requirement: - kWweight of the machine ca.: 7,0 tdimensions of the machine ca.: 3,0 x 1,2 x 3,2 mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. wheel diameter: 1000 mmgear width: 180 mmmax. module: 7 min. module: 0,5 min. ram stroke: 16 mmmax. ram stroke: 180 mmtable hole: 160 mmtotal power requirement: 4 kWweight of the machine ca.: 5,2 tdimensions of the machine ca.: - mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
