prensas usadas para venda (1,718)

; por ordem

Capacidade de impressão máxima. 25 t, tabela 600 x 600 mm, tacada máxima.

tabela 500/600 mm

O Hydr. Prensa de reentrada, linha de pressão máx. 50 t, tabela 600 x 550 mm >>

ver imagem no apêndice

Behaeltertipper - hidráulico - ver imagem

This 5-axis LVD PPEB 110/30 Press Brake was manufactured in 2001. It offers robust performance for precision bending operations. If you are looking to get high-quality bending capabilities, consider the LVD PPEB 110/30 machine we have for sale. Contact us for more information about this machine.

Bakker horizontal pressLength: 3500 mm Depth: 3100 mm Height: 1600 mm Weight: 6 ton

Camu decoiler 3 ton Dimeco straightener - 800 x 1,1 mm - 11 x 60 mm straightening rolls - 4 x 60 mm feeding rolls - weight: 850 kg CNC mircrofeeding unit Pressix excentric press - 100 ton - 65 strokes/min - adjustable stroke: 10 gt; 130 mm - table: 950 x 660 mm - max opening: 370 mm

Upsetter STANKO RYAZAN B1141 Esforço nominal 1250t Diâmetro máximo da peça de trabalho 140 mm Diâmetro máximo da flange alterada 180 mm Curso do deslizador móvel 220 mm Impulso do deslizador perturbador: total/funcional - 460/310 mm Golpes por min 30 Dimensões da matriz: 700x260x820 mm (LxLxH) Deslizador e matrizes de perturbação de distância 180 mm Potência do motor elétrico 75 kW Dimensões totais da máquina: 6400x4365x3340 mm Peso: 135t Excelente estado. Muito pouco uso – nota-se pelas engrenagens. Pode ser inspecionado em funcionamento

REIS TUS 115 OK 100 Imprensa Die Spotting pressão 100 t área de superfície da mesa 890 x 1280 mm Superfície RAM 1000 x 1200 mm distância entre colunas 1250 mm curso 1035 mm tabela de distância/RAM, curso máximo para cima, ajuste até 1035 mm janela lateral 700 mm altura da mesa sobre o piso 630 mm Peso máximo da ferramenta 7 t Capacidade máxima da placa de carneiro giratório 3,5 t volume de óleo 180 l capacidade de potência 9,0 kW peso 11 t Dimensões (LxPxA): 2,1 x 3,8 x 3,9 m carneiro giratório mesa móvel tabela - inclinável intertravamento hidráulico de carneiro ejetor na tabela

Prensa usada para cortiças CALLAHAN. Muito bom estado de trabalho. Tamanhos das folhas 896x734 mm. Cortiças curtas - 6,00 mm.

Capacidade 100 toneladas Tabela 880x715 mm Már. Espessura da folha 3 mm Acidente vascular cerebral por min. 360 Curso de AVC 25 mm Ajuste de carneiro 70 mm Distância Ram-table 400 mm 15 kW Dimensões LxWxH 3300x1600x2600 mm Peso total 10 toneladas

PKZZ 250 Double Column Crank stamping Press Completamente revisto. Elétrico e Controlo- Não disponível. Tabela 2500 x 1400 mm Ram 2320 x 1250 mm Distância entre as colunas 2525 mm Janela na largura da mesa 2300 mm Janela na profundidade da mesa 850 mm Avc. Traçados por minuto SPM 12 Regulação do ram 120 mm Shutheight 550 mm Força de almofada de mesa 50 para Traçado de almofada 160 mm Motor 32 kW Peso ca. 39 toneladas

Para venda, pressione automaticamente PTV 65 produzido a partir da SACMI Itália para tampas ropp. Ferramentas para 25mm e para tampas ropp de 28mm.

As rolhas de coroa usadas pressionam SACMI /Itália/ tipo PTC 027. Condição de trabalho perfeita. 27 pessoas, 27 tacadas. Produzido em Itália.

SLIDE  total force (nominal): 80 to  stroke rate (max.): 72 /minTOOL DIMENSIONS  lower table (left-right): 470 mm  lower table (front-back): 420 mm  upper table (left-right): 400 mm  upper table (front-back): 400 mmDIMENSIONS / WEIGHTS  space requirements -left/right-: 1600 mm  space requirements -front/back-: 1400 mm  total height: 2500 mm  total weight approx.: 6000 kg

SLIDE  total force (nominal): 40 to  stroke rate (max.): 110 /minTOOL DIMENSIONS  lower table (left-right): 300 mm  lower table (front-back): 280 mm  shut height max.: 180 mmDIMENSIONS / WEIGHTS  space requirements -left/right-: 1835 mm  space requirements -front/back-: 1500 mm  total height: 1800 mm  total weight approx.: 2500 kg

CONTROLS   SIEMENS SIMATIC PRESS DESIGN  drive system: eccentric / crank PRESS FORCES  total force (nominal): 160 toPRESS TABLE  table surface (left-right): 1200 mm  table surface (front-back): 970 mmSLIDE  stroke rate (max.): 90 /minSLIDE (MECHAN. PRESS)  slide adjustment: 120 mmELECTRICAL SPECIFICATIONS  mains voltage: 400 V  mains frequency: 50 HzDIMENSIONS / WEIGHTS  space requirements -left/right-: 3200 mm  space requirements -front/back-: 1600 mm  total height: 4400 mm  total weight approx.: 32000 kg

SLIDE  total force (nominal): 80 to  stroke rate (max.): 120 /minV-RING  stroke: 90 mmTOOL DIMENSIONS  lower table (left-right): 420 mm  lower table (front-back): 420 mm  upper table (left-right): 420 mm  upper table (front-back): 420 mmDIMENSIONS / WEIGHTS  space requirements -left/right-: 2970 mm  space requirements -front/back-: 1665 mm  total height: 242 mm  total weight approx.: 6000 kg

PRESS DESIGN  drive system: hydraulic SLIDE  total force (nominal): 40 to  stroke: 45 mm  stroke rate (max.): 110 /minTOOL DIMENSIONS  lower table (left-right): 300 mm  lower table (front-back): 280 mm  shut height max.: 90 mmDIMENSIONS / WEIGHTS  space requirements -left/right-: 1835 mm  space requirements -front/back-: 1500 mm  total height: 1800 mm  total weight approx.: 2500 kg

CONTROLS  electronic controls SIEMENS S7 300 PRESS DESIGN  drive system: eccentric / crank   openings in uprights: yes   number of suspensions: 2   table cushion: no   quick die change system: yes PRESS FORCES  total force (nominal): 250 toPRESS TABLE  table surface (left-right): 2000 mm  table surface (front-back): 1100 mm  height above floor level: 1105 mm  opening in bed (left-right): 1700 mm  opening in bed (front-back): 305 mmSLIDE  table surface (left-right): 2080 mm  table surface (front-back): 1000 mm  stroke rate (max.): 120 /minSLIDE (MECHAN. PRESS)  slide adjustment: 120 mm  stroke adjustment: yes   stroke min.: 20 mm  stroke max.: 180 mmTOOL ASSEMBLY DIMENSIONS  shut height (stroke down, adjustment up), BDC: 500 mm  distance between columns (H-frame): 2055 mm  passline opening (free passage in side columns): 810 mmDECOILER  sheet  ...

CONTROLS  PLC SIEMENS S7 SLIDE  total force (nominal): 630 toTOOL DIMENSIONS  lower table (left-right): 900 mm  lower table (front-back): 900 mm  shut height max.: 900 mm

CONTROLS   PNEUTRONIC CYBELEC STEUERUNG PRESS DESIGN  drive system: hydraulic   frame design: H-frame, monoblock   quick die change system: no   feedstock transport direction: left to right SLIDE  total force (nominal): 400 to  stroke: 230 mm  stroke rate (max.): 35 /minSLIDE (HYDR. PRESS)  approximation velocity max.: 120 mm/s  working velocity min.: 5 mm/s  working velocity max.: 50 mm/s  return velocity max.: 135 mm/sCOUNTER RAM  nominal force: 100 to  stroke: 40 mmV-RING  nominal force: 200 to  stroke: 40 mmTOOL DIMENSIONS  lower table (left-right): 1050 mm  lower table (front-back): 800 mm  upper table (left-right): 800 mm  upper table (front-back): 800 mm  shut height max.: 410 mmSTRIP-FEEDER  feeder type: roll feeder   sheet width max.: 350 mm  sheet thickness max.: 16 mm  feeding step min.: 1 mm  feeding step max.: 999.9 mm  s ...

CONTROLS  conventional PRESS FORCES  total force (nominal): 75 toPRESS TABLE  table surface (left-right): 1250 mm  table surface (front-back): 1110 mmSLIDE  table surface (left-right): 960 mm  table surface (front-back): 750 mmSLIDE (MECHAN. PRESS)  slide adjustment: 80 mm  stroke adjustment: yes   stroke min.: 10 mm  stroke max.: 50 mm  stroke rate (min.): 120 /min  stroke rate (max.): 600 /minSTRIP-FEEDER  feeder type: roll feeder   sheet width max.: 300 mmELECTRICAL SPECIFICATIONS  total power consumption: 15.5 kWDIMENSIONS / WEIGHTS  total weight approx.: 13500 kgATTACHMENTS (PRESSES)  strip feeder: yes   feeder type: roll feeder

CONTROLS  PLC SIEMENS S7 PRESS DESIGN  drive system: hydraulic PRESS FORCES  total force (nominal): 300 toPRESS TABLE  table surface (left-right): 2200 mm  table surface (front-back): 1700 mmSLIDE  stroke: 1600 mmTOOL ASSEMBLY DIMENSIONS  shut height (stroke down, adjustment up), BDC: 1600 mmELECTRICAL SPECIFICATIONS  mains voltage: 400 V  mains frequency: 50 HzDIMENSIONS / WEIGHTS  space requirements -left/right-: 6536 mm  space requirements -front/back-: 2923 mm  total height: 6135 mm  total weight approx.: 36000 kg

CONTROLS  PLC SIEMENS SIMATIC PRESS DESIGN  table cushion: yes PRESS FORCES  total force (nominal): 630 toPRESS TABLE  table surface (left-right): 2500 mm  table surface (front-back): 1300 mmDIE CUSHION (TABLE CUSHION)  cushion force: 250 to  stroke: 400 mm  cushion plate surface (left-right): 2450 mm  cushion plate surface (front-back): 1250 mm

PRESS FORCES  total force (nominal): 100 toPRESS TABLE  table surface (left-right): 950 mm  table surface (front-back): 660 mm  thickness of bolster plate: 68 mmSLIDE  table surface (left-right): 540 mm  table surface (front-back): 450 mm  spigot hole diameter: 60 mm  stroke: 130 mm  stroke rate (max.): 65 /minSLIDE (MECHAN. PRESS)  slide adjustment: 100 mmTOOL ASSEMBLY DIMENSIONS  shut height (stroke down, adjustment up), BDC: 370 mmDIMENSIONS / WEIGHTS  total weight approx.: 7000 kgLocated in Barcelona - Spain2 identical units available
