CIP plant for Seitz combifilter Year of construction: 1990 The manual system consists of caustic tank, heat exchanger and circulation pump., Additional title: with a heated CIP tank, CIP-Tank: 1500 l, Features: CIP tank, tube bundle heat exchanger, pump, piping

2 vertical stainless steel pressure tanks from the company Chema Process Engineering GmbH Year of construction: 1991 Contents: 180 hl max. pressure: 4 bar Material: stainless steel with insulation and sheet metal cladding, Additional title: 2 pc., Volume: 180 hl, Allowed pressure: 4 bar, Allowed temperature: 25 °C, Test pressure: 4 bar, Weight: 2220 kg, Material: stainless steel, Base construction: with vertical tank with dished bottoms and pipe feet, insulation and sheet metal cladding, Features: shell-manhole, nozzle for sampling

1 Combi-Filter Seitz, type Orion 100 Year of construction: 1982 Output: 100 hl/h complete with beer pump, conductivity measurement, dosing vessel, Control cabinet, switching panel, KG collecting pan with conveyor and disposal pump., Additional title: Kieselguhr and sheet filter, Filterarea kieselguhr appr.: 35 m², Filtration capacity: 100 hl/h, Length: 5200 mm, Width: 1320 mm, Height: 2250 mm, Formats: 1 m x 1 m filter plates, Material: Stainless steel, Position: Horizontal, Base construction: Frame filter, Features: Hydraulic filter compression; altguhr conveyer: up to 200 Filter sheets or 55 kieselguhr plates and 56 filter sheets

5 fermentation and storage tanks (104 hl) with flat conical bottom, frame and cone cooling zone, manhole, sampling tap and central outlet. 1 white beer fermentation tank (81 hl) with flat conical bottom, frame and cone cooling zone, manhole, sampling tap, yeast chute and central outlet. 1 batching/flotation tank (122 hl) with flat conical base, frame and cone cooling zone, manhole, sampling tap and central outlet. The tanks are also available individually or in partial quantities., Additional title: 7 pcs. of vertical, coolable stainless steel tanks, Volume fermentation and storage tanks: 10474 l per piece, Volume wheat beer tank: 8071 l, Volume flotation tank: 12242 l, Material: stainless steel 1.4301, Position: standing on feet, Features: Flat conical bottom, frame and cone cooling zone, manhole, sampling tap, central spout, yeast chute

Kieselguhr dosing system for beverage filtration. Consisting of a mixing tank, pumps and various other components., Additional title: vertical agitator vessel, Capacity: 25000 l/h, Vessel volume: 500 l, Power: 2,42 kW, Voltage: 220/380 V, Frequency: 50 Hz, Material: stainless steel, Position: vertical, Features: agitator, sight glass, level indicator, precoat pump (80 hl/h against 2 bar), piston metering pump (36 hl/h against 8 bar), hinged lid, carbon dioxide fumigation, dust extraction device

Combi filter (kieselgur- and sterilising filter) for beer filtration with hydraulic pressure, 100 x 100 cm filter plates and external risers., Additional title: combination filter, Capacity: 120 hl/h, Plate size: 100 cm edge length, Length: 7000 mm, Width: 1500 mm, Height: 1500 mm, Position: horizontal, Base construction: mounted on steel frame, standing on feet, Features: 31 kieselguhr layers (32 frames), 50 sterilisation layers, 4 pressure manometers (10bar), 6 lanterns, risers, kieselguhr discharge screw (Allweiler), gravity measurement, flow measurement, 3 x turbidity measurement (inlet, outlet Kieselgur filter, outlet 3 x turbidity measurement (inlet, outlet kieselgur filter, outlet sterilisation filter). Spare parts: 295 sealing rings for filter plates, 3 kieselguhr filter support plates

Complete mixing tank system with 3 tanks, pipe fence, pumps, fittings and automatic gassing., Additional title: Mixing system with 3 upright stainless steel pressurised tanks with agitator, Volume: 33000 l per tank, Max. pressure: 2 bar, Pump capacity: 28 m³/h, Operating temperature: 40 °C, Length: 2600 mm, Width: 2600 mm, Height: 8500 mm, Weight: 3900 kg, Operation / Control: Rush-Flow-Dosing: SPS-Typ = C7-633, HMI = ProTool, Material: stainless steel 1.4301, Position: free standing, Base construction: Cylindrical tank with dished ends and pipe feet on spherical caps, Features: 2 zone frame cooling, insulation with stainless steel sheet panelling, agitator in the base, manhole at the side, tank fittings; 2 pumps; pipe fence; panel with CO2 fumigation; measurement and control technology; control cabinet with control panel

The fully-automated carbonisation plant produces the CO2-amount of beer, beer mixing beverages, soft drinks, mineral water and wine in a continuous and high-precision way by precise controlled dosing of CO2., Capacity beer feed: 20000 l/h, Capacity degassed water: 10000 l/h, Capacity blended beer: 30000 l/h , CO2-supply: 8 barg, Power: 23 kW, Current: 50 A, Voltage: 400 V, Frequency: 50 Hz, Compressed air: 6 bar, Length: 2790 mm, Width: 1250 mm, Height: 2440 mm, Weight: 500 kg, Operation / Control: fully automatic, electrical cabinet with control panel, Material: stainless steel, Features: Flange connection: Beer: DN80, degassed water: DN40, CO2: DN25, blended beer: DN65 Beer pump; carbonisation section; flow measurement; Anton Paar original wort, alcohol and CO2 measurement; pressure gauge; sampling taps; various other valves

Fully-automated yeast propagation plant with 2 cylindroconical tanks each 60 hl in stainless steel for yeast propagation and 2 cylindroconical tanks each 60 hl in stainless steel for yeast storage, A conversion and automation was carried out by Esau & Huber in 2007., 2 tanks for yeast propagation each: 80 hl total volume, 2 tanks for yeast storage each: 80 hl total volume, Material: stainless steel, Features: Yeast propagators and yeast tanks have a cooling zone + 1 cone cooling, PT100, weigh cells, circulation pump, yeast aeration

Stainless steel pressure tank for approx. 10 hl net capacity; cooled by means of double jacket on the frame and firmly welded insulated., Additional title: coolable, insulated, clad, Gross content: 1122 l, Perm. working overpressure: 3 bar, Perm. working temperature: 20 °C, Content cooling zone: 5 l, Length: 1000 mm, Width: 1000 mm, Height: 1700 mm, Material: stainless steel, Features: Manhole in the frame, spraying head with spraying head line and shut-off flap DN 25, safety valve and manometer, outlet flap, thermometer Height-adjustable tube feet

Additional title: 3 coolable tanks, Capacity: 205 hl , Operating pressure: 0,3 bar, Width: approx. 2,80 m, Height: approx. 4,20 m, Position: Vertical, Base construction: on feet, Features: manhole; cooling jackets; spunging apparatus; sampling valve

Storage cellar for beer consisting of 8 vertical tanks with temperature control., Additional title: Vertical storage tanks made of stainless steel (coolable, pressurisable), Width: ca. 2,50 m, Height: ca. 2,60 m, Features: 8 storage tanks (6x approx. 165 hl, 2 x approx. 175 hl), temperature control, paneel, blending apparatus

Fermentation cellar with 4 coolable stainless steel tanks. Tank 1-3: C. Gresser, 1986, gross volume 204.60 hl. Tanks standing on 4 legs, each with 2 frame cooling zones, dished bottoms and central outlet. Equipment in each case: safety valve, cleaning line, CIP spray head, sampling tap, manhole in the frame and sight glass in the tank dome. Tank 4: C. Gresser, 1986, gross volume 115.69 hl. Tank standing on 4 legs with frame cooling, dished bottom and outlet pipe. Equipment: Cleaning line, CIP spray head, sampling tap, manhole in the frame., Additional title: coolable stainless steel tanks, 3 tanks each: 20500 l, 1 tank each: 11600 l, Material: stainless steel, Position: free standing, Base construction: Vertical cylindrical tanks on square tube feet, Features: Cooling jackets, cleaning lines, CIP spray heads, discharge lines, safety valves, sampling taps, manholes, sight glasses

Additional title: 2 vessels with agitator, Capacity: 13 hl/vessels, Features: 2 stainles steel vessels with agitator, and podest, incl. fittings

Additional title: coolable tank, Capacity approx.: 116 hl, Width: approx. 2,3 m, Height: approx. 4,1 m, Position: vertical, Base construction: on 4 feets, Features: manhole; cooling jackets; spunging apparatus; sampling valve

Can filling machine with single filling valve, mobile, on wheels. For semi-automatic filling of 5 liter cans with beer. Capacity: approx. 30 - 35 cans/h, Additional title: 5-liter can filling, Capacity approx.: 50 cans/h, Height: 2,0 m, Formats: 5 liter cans, Operation / Control: semiautomatic, Material: stainless steel, Base construction: on wheels

Self-priming centrifugal pump with stainless steel housing., Additional title: self-priming centrifugal pump, Frequency: 1450 1/min, Power: 4,0 kW, Material: stainless steel, Features: stainless steel housing

Paletização com tecnologia de transportadores

Teremos todo o gosto em visitá-lo e planear a sua máquina. Além disso, a adaptação de transportadores de garrafas em caixa pode ser realizada por nós. Também podemos fabricar novas cabeças de agarre.

Teremos todo o gosto em visitá-lo e planear a sua máquina. Além disso, a adaptação de transportadores de garrafas em caixa pode ser realizada por nós. Também podemos fabricar novas cabeças de agarre.

Rico 2 Cabeças Empacotadoras para 2 x 6 Caixa de Vinho 2 x 6

Contentor Vdf empacotador de 1 cabeça

Pack - Tec ano de paletização 2019 6 12 20 caixas Requisito de espaço apertado

Máquina de lavar garrafas Krones construída em 2001 676-039 6000 garrafas/h garrafas 0,2l-1,0l A máquina estará disponível em dezembro de 2026

Arruela de caixa com transportador inclinado Teremos todo o gosto em planear a sua máquina, e mudança, complementando a tecnologia de transportadores

0,5 l Bracket 0,5l Euro 0,33l Longleg

0,5l Quadro 0,5 l Euro 0,33 l Longleg

A máquina está em muito bom estado e também podem ser conduzidas garrafas de tampa oscilante 0,5l Bracket 0,5l Euro 0,33l Longleg

Inspetor Heuft para 0,5l Euro 0,5l Suporte 0,33l Garrafa Longleg A máquina pode ser agendada por nós e a corrida da garrafa pode ser ajustada.

Máquina de lavar garrafas Klinger também para garrafas de tampa oscilante. A máquina pode ser planeada e montada por nós. Também podemos fornecer tecnologia adicional de correias transportadoras
