máquinas e equipamentos para engenharia de processo usadas para venda (7,707)

Manufacturer: Arburg Model: 520S 1500/800 + Robot Type: Injection moulding machine Year of manufacture : 2010 Operating hours: 91720 Closing force: 150 t Screw diameter: 45 mm Max. injection volume: 318 cm3 Fixing plate: 688 x 688 mm Machine weight: 6.84 t Find more here - / Contact us at -

Manufacturer: Engel Model: VC 80/50 Electric Type: Injection moulding machine Year of manufacture: 2007 Operating hours: 33933 Closing force: 50 t Screw diameter: 13 mm Max. injection volume: 25.4 cm3 Fixing plate: 500 x 455 mm Machine weight: 3.3 t Find more here - / Contact us at -

Manufacturer: Engel Model: Insert 80H/35 – Vertical Type: Vertical injection moulding machine Year of manufacture: 2007 Operating hours: 22404 Closing force: 35 t Screw diameter: 18 mm Max. injection volume: 25.4 cm3 Fixing plate: D1200 mm / 560 x 430 mm Machine weight: 6.1 t Find more here - / Contact us at -

Manufacturer:SKADEC Model: CW-C22R1722AP Year of Manufacture : 2023 Dimensions: 5450 x 2350 x 2350 mm Weight: 3142.0 kg Rated Voltage: 400/50/3 V/Hz/Ph Maximum Current: 125.0 A Cooling Capacity: 171.6 kW Power Consumption: 43.66 kW EER: 3.93 Refrigerant: R290 (Natural, environmentally friendly) Refrigeration Circuits: 2 independent circuits Compressors: 2x frequency-controlled (25-70Hz variable speed) Technical Data Design Point: - Cooling capacity: 171.6 kW - Power consumption: 43.66 kW - EER: 3.93 - Design frequency (for VFD compressor): 60 Hz - Ambient temperature: +35 degrees C - Medium temperature inlet/outlet: +18 / +14 degrees C BAFA Setpoint: - Cooling capacity: 141.6 kW - Power consumption: 42.05 kW - EER: 3.36 - Design frequency (for VFD compressor): 67 Hz - Ambient temperature: +35 degrees C - Medium temperature inlet/outlet: +13 / +7 degrees C General: - Refrig ...

Manufacturer: Wagner Type of machine : Powder Coating System Year of Manufacture: 2000 The powder system consists of the following individual components: - 1x Powder coating booth – FBC – plastic booth with discharge conveyor - Cabin extraction system – 1x monocyclone 1x closed post-filter - 2x powder collection containers - 1x Powder Center - PZ - 2008 with its own extraction system - 8x Automatic Powder Guns – PEA – T2 - 2x hand powder guns – PEM – T2 - Control unit for automatic pistols – 8x PM 401 pneumatic module 1x PG 650 control module - 2x Control for handguns – EPG – 2007 in Tribo mode - 2x lifting devices – EBA – 3 - 2x electric sliding unit – VT – 1400 - Light strips – height + gap + depth - 1x external safety device – fire detection (Minimax company) - Find more here - / Contact us at -

Manufacturer: Ramatech Model: Speedy 35 Year of Manufacture: 2007 Operation hours : since February 2008 has run daily for 6-10 hours until February 2025 without knife block / with tool rack base TECHNICAL SPECIFICATIONS Function : Cutting and stripping of cables Cable diameter : 4 mm to 35 mm Cable cross-section : Up to 185 mm² Cable length : 220 mm to 1000 m Length tolerance : Repeat accuracy better than ±0.2% for lengths over 2 m Stripping length : At start and end from 10 mm up to 9999 mm Partial stripping length : Freely programmable Processing speed : 0.1 – 2.2 m/s, programmable Acceleration: Programmable Cable guidance : Quick-change cable guides Cable pulling force : Not specified Electrical connection : 3 x 400 VAC + N / 25 A Frequency : 50 Hz Pneumatic supply : 6 bar Weight : 450 kg Dimensions (L x W x H) : 1300 x 800 x 1500 mm Find more here - / C ...

Manufacturer: ESC Model: Continuous Dryer Perfecton S with UV Year of Manufacture: 2020 Technical Specifications Heating Chamber 80°C - Galvanized nozzle plate - Process fan: TRZ 250-3 - Indirect air intake from process room - Recirculated air volume: 3,400 m³/h at 510 Pa - RRH heating register: 18 kW at max. 80°C - Drive motor: 2.2 kW / B3 / 1,410 rpm / insulation class F - Length: 2,000 mm Cooling Chamber - Process fan: TRE 250-3 - Supply and exhaust air volume: 3,400 m³/h at 800 Pa - Stainless steel drip tray for process fan - Drive motor: 2.2 kW / B3 / 1,500 rpm / insulation class F - Without cooling register and refrigeration unit - Length: 2,000 mm Discharge Element - Steel drive roller with rubber coating - Mounting for belt drive - Length: 500 mm Construction Details - All hoods and cladding panels made of electrolytically galvanized steel sheet - Heating chamber  ...

Manufacturer: ESC Model: Continuous Dryer Perfecton S Year of Manufacture: 2021 Technical Specifications Heating Chamber 80°C - Galvanized nozzle plate - Process fan TRZ 250-3 - Indirect air intake from process room - Air circulation volume: 3,400 m³/h at 510 Pa - Electric heating register: 18 kW at max. 80°C - Drive motor: 2.2 kW / B3 / 1,410 rpm / ISO F - Length: 2,000 mm Cooling Chamber - Process fan TRE 250-3 - Supply and exhaust air volume: 3,400 m³/h at 800 Pa - Stainless steel drip tray for process fan - Drive motor: 2.2 kW / B3 / 1,500 rpm / ISO F - Without cooling register and chiller - Length: 2,000 mm Discharge Element - Rubber-coated steel drive roller - Mounting for belt drive - Length: 500 mm General Construction - All hoods and cladding panels made of electro-galvanized steel sheet - Heating chamber hoods are insulated DIMENSIONS - Belt width: 1,700 mm -  ...

ABB IRB 1600 M2004 Industrial Robot with IRC5 Controller – Used, Serviced Manufacturer - ABB Robot Model - ABB IRB 1600 M2004 Controller - IRC5 Controller - Includes IRC5 control cabinet / control unit Type / Configuration - Industrial articulated robot - With Manipulator + Controller - Includes A-position encoder (as stated: mit A-Positionierer”) Condition - Used - Controller was serviced / refurbished: - Deep cleaning of controller - Replacement of filters - Replacement of C-MOS battery - Replacement of SMB battery Find more here - / Contact us at -

Manufacturer: Kautex Model: KBS2-20/40-S90/22D Year of Manufacture: 1999 PLC control: Siemens S5 Grinder: Rapid 3545 Conveyor Material feeding system Piovan Dedusting system Piovan Automatic component gripper and scale Spare parts Control Voltage: - AC: 230 V - DC: 24 V Working Voltage (AC, 3-phase): - Drive I: 400 V - Drive II: 400 V - Heating: 400 V Frequency: 50 Hz Rated Current: - Drive I: 285 A - Heating: 70 A Maximum Fuse Rating: - Drive I: 315 A (time delay) - Heating: 100 A (fast acting) Find more here - / Contact us at -

Manufacturer: Engel Model: Emotion 440/160 Year of Manufacture: 2018 Max. installation height :460 mm • Center support package • Max. closing force :1600 kN Cylinder size: 40 mm • Screw CRN coated • OptiShut backflow preventer • max. spray pressure 1940 bar • Injection volume 55-220 cc Max. injection weight :174 g Operating hours: 33526 h Equipment: • 1 core pull incl. auxiliary unit • Plasticizing cylinder set, highly wear-resistant design • Needle valve nozzle • E-Flomo • IQ weight control • IQ Clamp control • EM 63 interface • separate water and electricity connections Find more here - / Contact us at -

Manufacturer: Krauss Maffei Model: 80-390-C2 Year of Manufacture: 2001 Type of Machine : Hydraulic Injection Molding Machine Tonnage (Clamping Force): 80 t Tie Bar Distance (H x V): 405 x 405 mm Platen Size: 610 x 610 mm Ejector Hole: Centre Knee Lever: No Minimum Mold Height: 250 mm Maximum Mold Height: Not applicable Opening Stroke: 750 mm Screw Diameter: 35 mm Shot Weight: 140 g Core Functions: 2 Handling System: No Electrical Data Operating Voltage: 400 V, 3-phase Frequency: 50 Hz Total Current (Iges): not specified Motor Current (In Motor): 97 A Heating Current (In Heating): 117 A Single Motor Current: 37 A Fuse Protection: - Motor: 100 A - Heating: 125 A Find more here - / Contact us at -

Manufacturer: Cofely Model: Quantum II X030 Year of Manufacture: 2015 Type: Industrial refrigeration/chiller system Refrigerant: R134a Refrigerant quantity: 100 kg MAXIMUM OPERATING PRESSURE High pressure (HD): 18.3 bar / 63 °C Low pressure (ND): 18.3 bar / 63 °C OPERATING LIMITS Evaporator - Water side pressure: max. 10 bar - Flow rate: 22.3–53.6 m³/h - Outlet temperature: 3–20 °C - Inlet temperature: 7–25 °C Condenser - Water side pressure: max. 10 bar - Flow rate: 28.6–68.5 m³/h - Outlet temperature: 20–56 °C - Inlet temperature: 15–52 °C MAIN COMPONENTS Turbo Compressors - Model: TT300-H6-1-ST-E-O-CE - Cooling capacity: 300 kW - Power consumption: 2 × 51 kW - Max. current per compressor: 140 A - Voltage: 400 V - Frequency: 50 Hz - Manufacturer: Turbocor Inc. Evaporator - Model: VRMH46.60.180.4 - Evaporating temperature: 9 °C - Volume flow chill ...

Manufacturer: Fu Chun Shin Machinery Model: SD 60004M Year of Manufacture: 2009/ 2015/2016 Type of Machine : Injection Molding Machine Heater Capacity: 46.68 kW Motor Power: 44 kW Pump Pressure:140 kg/cm² Find more here - / Contact us at -

We have two grain unloaders capable of discharging vessels with a draft of up to 17 meters (approximately 100,000 DWT). One unit is a mechanical unloader and the other is a pneumatic unloader. Details are as follows: Manufacturer: Bühler Year of Manufacture: 1983-1985 Mechanical Chain Transporter HM1-T1 + HM2-T1 Transporter type: HL-SKT RSH-450 Feed capacity: 1000 t/hour grain Total length: 28.1 m Chain speed: 2.28 m/s Drive shaft speed: 37.7 rpm Torque on drive shaft: 40,200 Nm Drive power at shaft: 164 kW Drive system: two hydro motors on each drive shaft Hydraulic motor type: MK 43-09200-CO-RN Absorption capacity: 9.2 liters per rotation Specific torque: 147 Nm/bar Nominal torque: 20,100 Nm Nominal pressure: 156 bar Chain Transporter in Boom HM1-T2 + HM2-T2 Transporter type: BKT 1210/290 142V 002 TWIN Feed capacity: 1000 t/hour grain Total length: 33.2 m Chain sp ...

Manufacturer:Prozap Type of Machine : EK0 Assembly line station Year of Manufacture: 2023 Power supply: TN-S Voltage: 400 V, 50 Hz Current: 40 A Power: 15 kW Pneumatic pressure: 4.5 bar Weight: 1600 kg Certifications: ISO 9001, CE Find more here - / Contact us at -

Manufacturer: Prozap Model: EK0 Bushing Assembly Year of Manufacture: 2023 Power supply: TN-S Voltage: 400 V, 50 Hz Current: 15 A Power: 8 kW Pneumatic pressure: 6 bar Hydraulic pressure: 255 bar Weight: 6000 kg Certifications: ISO 9001, CE Find more here - / Contact us at -
