tornos usadas para venda (2,946)

Technical data Manufacturer: Colchester Model: MASCOT (Electronic Mascot) Machine Type: CNC Lathe Control: GE Fanuc Series 20-T Spindle speed: approx. 20 – 1600 rpm Spindle bore: approx. 74 – 76 mm Turning diameter over bed: approx. 430 mm Turning diameter over slide: approx. 260 – 270 mm Center width: approx. 1200 – 2500 mm Spindle motor power: up to approx. 11 kW Weight: approx. 2.2 – 3.0 t Configuration CNC control Fanuc 20-T Tool holder / turret (typical) Tailstock available Coolant Setup Closed machine enclosure Note The technical data was researched on the basis of publicly available information on the Colchester Mascot series. Original machine documentation was not available. Deviations are possible. Auction-ID: A7-46048-31

TEACH IN LATHE Inv. No.: 13.110C1C Make CHEVALIER Model FCL1840 Mach. No. X186A005 Control FAGOR 800TGI Centre Distance 1.000 mm Max. Swing over Bed Ø 460 mm Max. Swing over Cross Slide Ø 230 mm Spindle Bore Ø 58 mm R.P.M. 40 – 2,000 HP 7.5 Volts 400 Cycles 50 Including: 1 x Steady Rest Fixed toolpost multifix 3-jaw chuck Auction-ID: A1-45737-170

CNC LATHE Inv. No. 12.710C1 Make MONDIALE Model GALLIC 420 CNC Control FANUC 10TF Serial number CNCG16AC Centre distance 870 mm Max. swing over Bed Ø 420 mm Max. swing over Cross Slide Ø 214 mm Spindle bore Ø 69 mm R.P.M. 45 – 2500 (inf. var.) kW 11 Volts 400 Cycles 50 Including: 6 Pos. turret Coolant Auction-ID: A1-45737-113

Auction-ID: A1-45737-192

Turning length 1.545 mm Turning diameter 500 mm (710mm) X-axis 690 mm Y-axis 230 mm Z-axis 1550 mm B-axis 225° C-axis 360° (0.001°) W-axis 1550 mm Spindle Bore Ø 98 mm R.P.M. 36x 30-3000 KW 30/22 Tapid traverse 26 – 40 m/min Auction-ID: A1-45737-1

TEACH IN LATHE Inv. No.: 12.689C1 Make CHEVALIER Model FCL40160 Mach. No. X7895C01 Control SIEMENS 810D Centre Distance 4.000 mm Max. Swing over Bed Ø 1.015 mm Max. Swing over Cross Slide Ø 670 mm Spindle Bore Ø 134 mm R.P.M. 0 – 1.200 kW 22/33 Volts 400 Cycles 50 Including: 1 x Steady Rest Ø 300 mm Chip Conveyor 4 Way Automatic Toolpost Fixed toolpost multifix Hydraulic chuck 380mm Auction-ID: A1-45737-4

TEACH-IN LATHE Inv. No. 13.051C1 Make CMT URSUS Model URSUS PLUS 250 Year 1996 Serial number 12628 Centre Distance 1.000 mm Max. Swing over Bed Ø 480 mm Max. Swing over Cross slide Ø 400 mm Spindle bore Ø 105 mm 2 ranges stepless 0 – 2.000 kW 8/11 Volt 380 Cycles 50 Including Toolholder Multifix 3-jaw chuck Ø 315 Auction-ID: A1-45737-161

CNC LATHE WITH SUBSPINDLE AND Y-AXIS Inv. No. 13.032C1 Make MAZAK Model SQT250MSY Control T-PLUS Center distance 495 mm Max. swing over bed Ø 525 mm Max. swing over cross slide Ø 350 mm Spindle bore Ø 64 mm R.P.M. 35 – 4,000 (16x) kW 18 Volts 380 Cycles 50 Including: 12 pos. A.T.C.(driven tools) Hydraulic chuck Ø250mm Auction-ID: A1-45737-9

TEACH IN LATHE Inv. No. 11.581C1 Make CAZENEUVE Model HBCN S575 Year 1995 Mach.no. 9810 Control SOMAB PL+S3 Centre Distance 1.500 mm Max. Swing over Bed Ø 575 mm Max. Swing over Cross Slide Ø 300 mm Centre Height Ø 250 mm Spindle Bore Ø 51 mm R.P.M. 2 ranges 0 – 3000 kW 18,5 Volts 400 Cycles 50 Auction-ID: A1-45737-102

TEACH-IN LATHE Inv. No. 13.224C1 Make TOS TRENS Model SUI500 COMBI Serial number 69005015010003 Control heidenhain Center distance 1500 mm Max. swing over bed Ø 500 mm Max. swing over cross slide Ø 290 mm Spindle bore Ø 71 mm R.P.M. 8 – 2.800 KW 11 Volts 380 Cycles 50 Including: 3-jaw chuck Emergency stop. Threading Coolant system Safety protection screen problem in cabling Auction-ID: A1-45737-196

CNC LATHE Inv. No. 13.016C1 Make MAZAK Model QUICKTURN 20N Control MAZATROL CAM TZ Center distance 1.037 mm Max. swing over bed Ø 510 mm Max. swing over cross slide Ø 310 mm Spindle bore Ø 80 mm R.P.M. 12 – 3,000 kW 18.5 Volts 380 Cycles 50 Including: 8 pos. A.T.C. Auction-ID: A1-45737-127

CNC LATHE Inv. No. 12.711C1 Make MONDIALE Model GALLIC 420 CNC Control FANUC 10TF Serial number CNCG1685B17GE Centre distance 870 mm Max. swing over Bed Ø 420 mm Max. swing over Cross Slide Ø 214 mm Spindle bore Ø 69 mm R.P.M. 45 – 2500 (inf. var.) kW 11 Volts 400 Cycles 50 Including: 6 Pos. turret Coolant Auction-ID: A1-45737-114

CNC LATHE Inv. No. 13.113C1 Make PBR Model T30 SNC x 1500 Control SIEMENS 805T Year 1996 Centre Distance 1.500 mm Max. Swing over Bed Ø 600 mm Max. Swing over Cross Slide Ø 410 mm Max. Swing in Gap Ø 960 mm Spindle Bore Ø 105 mm R.P.M. 47 – 2.000 (in 2 ranges) kW 15/22 Volts 400 Cycles 50 Including: Automatic Turret, 8 positions Enclosed guarding Coolant Auction-ID: A1-45737-172

: neu : ca. 4 Monate ab Auftragse : Bulgarien : 75740 €: 1431.49 €: 600 mm: 1500 mm: 300 mm: 80 mm: 400 mm: 400 mm: 8 : 90 MK: 3 : 20 - 100, 80 - 400, 400 - U/Min: max. 8 m/min: max. 8 m/min: 290 mm: 90 mm: 5 MK: 225 mm: 11 kW: 3,5 / 22 kW/Nm: 1,75 / 11 kW/Nm: 120 Nm: 1250 daN: 1050 daNFast and simple communication between the operator and the lathe.Simple workpieces are machined in the same way as on the universal lathe, but more efficient.Complicated workpieces are machined in the same way as on the universal lathe, but faster.Complicated workpieces are machined in the same way as on the CNC lathe, but easier.Based on the controller Schneider Magelis the intelligent, self-developed ZMM Sliven softwareleads the operator also without programming skills simple and fast to the finished workpiece.The interface is simple and with large icons, which is convenient in a specific work enviro ...

: neu : Bulgarien : 55100 €: 1041.39 €: 600 mm: 2000 mm: 300 mm: 80 mm: 400 mm: 400 mm: 8 : 90 MK: 3 : 20 - 100, 80 - 400, 400 - U/Min: 120 : 64 : 0.5 - 120 mm: 60 - 1/4 Gänge/: 0.125 - 30 : 315 mm: 130 mm: 90 mm: 5 MK: 230 mm: 11 kW: 3600 mm: 1500 mm: 1650 mm: 3110 kgIn contrast to the universal lathes, here the adjustment of the revolutions is infinitely variable by means of a frequency inverter.It is possible to ensure a ",constant cutting speed", (V-const), i.e. when changing the diameter to be machined, the speed remains unchanged and thus a higher accuracy and smoothness of the surface is achieved. At the customer&apos,s request, the machines can be manufactured with a reading of the linear displacement and positioning by mounting a digital display.driven by variable speed control (3 steps)3-axes digital readout Fagor with CSS (constant surface speed)quick change toolp ...

bar material dia.: 20 mmspindle passage: 22 mmturning length: 205 mmControl: Siemens Yaskawa bar material dia.: 20 mmturning speeds: 500-10.000 U/minc-axis: 0,001 °gripping station: 20 mmturning length: 30 mmpositive location each: 0,001 °Number of tools: 10 fest / fix St.total power requirement: 2,2/3,7 kWweight of the machine ca.: 3,5 tdimensions of the machine ca.: 2,6 x 1,2 x 1,8 +FMB mdriven tools: 4+3+3 fire distinguisher: Kraft & Bauer bar loader: FMB minimag 18 1,5m Stangehigh pressure pump: ja/yes parts conveyor: ja / yes CNC-swiss type machine Star SR20-R, built 2002 with FMB Minimag 18,in good condition, comes from medical factory.The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

: neu : ca. 4 Monate ab Auftragse : Bulgarien : 36070 €: 688.94 €: 400 mm: 1000 mm: 200 mm: 52 mm: 235 mm: 320 mm: 6 : 6 MK: 12 : 50-2.240 1/min: 80 : 0.015 - 0.6 mm/U: 0.0075 - 0.3 mm/U: 40 : 0.25 - 7.5 mm: 120 - 4 Gänge/: 0.0625 - 1.875 : 480 - 16 : 235 mm: 110 mm: 50 mm: 4 MK: 100 mm: 4 kW: 2750 mm: 1100 mm: 1600 mm: 1540 kgdriven by manual transmission3-axes digital readout Fagor 40iquick change toolpostMultisuissewith4 holders (3 square, 1 round)3-jaw chuck Bison 3204/DIN6350, Ø 200 mmspindle noseNr. 6 DIN 55027four way rapid traverse devicespindle dead centercoolant equipment1 pce. flange plate for lathe chuckØ 200 mm1 adapter sleevefull length rear splash guardleadscrew and shaft protectionsafety guard for the chucktoolholder guardlevelling bolts and platesquick release tailstocklow voltage machine lampoperating manualmachine according to ",CE",FURTHER TURNING LENGT ...

turning diameter: 340 mmturning length: 1000 mmcontrol: Mazatrol SmoothC total power requirement: kWweight of the machine ca.: tdimensions of the machine ca.: mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter: 350 mmturning length: 650 mmcontrol: 840 D SL ShopTurn Siemensgreates pass round over bed: 385 mmSwing dia. over traverse guideway: 350 mmMain spindle:: turning speed range - main spindle: 0 - 4.500 min/-1power capacity - main spindel: 11,5 / 8 kWmax. Torque: 340 Nmspindle diameter in front bearing: 130 mmspindle bore: 87 mmbar material dia.: max. 65 mmmax. chucking diameter: 250 mmspindle head: 170 h5 C-Axis: turret:: number of toolpositions: 12 pos.Shank diameter: DIN 69880: 30 mmDriven Tool Stations:: Number of driven toolspositions: 6 pos.Spindle speed - driven tool stations: max. 4.500 min -1power capacity driven tool-stations: 5,5 kWaxis stroke:: x-axis: 255 mmz-axis: 800 mmTailstock:: tailstock: 680 mmtaper of center: MK 4 clamping capacity: 6,8 kNfeeds:: feed speeds: 0 - 30.000 mm/minrapid traverse ( X / Y / Z ): 30 / - / 30 m/minFeed force ( X / Y / Z ): ...

Machine is equipped with: - chip conveyor - renishaw probe system Auction-ID: A1-45752-12

Specifications: - X-axis: 162mm - Z-axis: 750mm - Y-axis: +/- 50mm - C-axis: yes - B-axis: 670mm - sub spindle speed: 4500rpm - sub spindle motor power: 5,5kW - live tooling: yes - live tooling speed: 3000rpm - live tooling type: BMT-55 Machine is equipped with: - Chip conveyor - Bar feeder - live tooling - y-axis - tooling in turret included - pallet with tooling included Auction-ID: A1-45752-10

Unchecked Auction-ID: A1-45973-56

faceplate diameter: 4500 mmswing diameter: 5000 mmturning height: 2500 mmworkpiece weight max.: 63 tno. of the slides: 2 max. ram stroke: 1600 mmfaceplate turning speed range: 0,3 - 32 U/minAnzahl der Drehzahlstufen: 4 total power requirement: 130 kWweight of the machine ca.: 145 tdimensions of the machine ca.: 6,6 x 11,4 x 8,4 m- DRO- 2 swivable Rams (-15° / +40°)The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter over bed: 1090 mmturning diameter over slide rest: 700 mmturning length: 6000 mmcentre distance: 6000 mmspindle bore: - mmspindle taper: - turning speed range: U/minpower requirement: 30 kW3-jaw-chuck diameter: mmquick change toolholder: 4 fach Stahlhalter taper in tailstock-quill: MK 6 dia. of quill: 125 mmquill stroke: 260 mmtotal power requirement: 30 kWweight of the machine ca.: 11 tdimensions of the machine ca.: 8,2 x 1,8 x 1,82 m- rapid traverse- tail stock- DROThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter over bed: 20 mmturning diameter over slide rest: 1200 mmturning length: 3.000 mmcentre distance: 3000 mmdigital readout: 4 - Achsen bed width: 800 mmspindle bore: 122 mmturning speed range: 1,80 - 355 U/minpower requirement: 22 kW3-jaw-chuck diameter: mmtaper in tailstock-quill: 100 (1:20) dia. of quill: 150 mmquill stroke: 350 mmcoolant: voltage: 400 Vtotal power requirement: 31 kWspindle nose: Gr. 11, DIN 55027 weight of the machine ca.: 10 tdimensions of the machine ca.: 8,20 x 2,20 x 2,20 m- Serial No.: 75.217- Rapid feed for carriage- 4-Axis DRO-System SINOThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter over bed: 455 mmturning diameter over slide rest: 285 mmturning length: 1.000 mmcenter height over bed: 225 mmcentre distance: 1.000 mmdigital readout: 2-Achsen ANILAMbed width: 330 mmspindle taper: KK 6 DIN 55027spindle bore: 45 mmturning speed range: 16 - 1.000 U/minpower requirement: 3,0 / 4,2 kWtaper in tailstock-quill: MK 4 dia. of quill: 62 mmquill stroke: 145 mmcoolant: voltage: 400 Vtotal power requirement: 4,5 kWweight of the machine ca.: 1,95 tdimensions of the machine ca.: 2,45 x 1,10 x 1,80 m- Serial-No.: 29-2561- ANILAM 2-axis digital readout- 4-jaw tool holder- coolant equipmentATTENTION!Machine is sold without a chuck.Upon request and for an additional charge,the following 3-jaw spiral chuckscan be included:- CENTER Ø 200 mm = 780.00 EUR- CENTER Ø 250 mm = 1,030.00 EURThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG ...

Control: Fanuc 18 iTB Max. turning diameter: 190 mm Max. turning length: 620 mm Greatest: pass round over bed: 190mm Swing dia. over traverse guideway: 190mm Standard turning diameter: 170mm Max. distance between spindles: 970mm Main spindle: - Max. spindle speed: 4.500rpm - Power capacity - main spindel: 18,5 / 15 kW - Spindle bearing diameter: 110mm - Spindle bore: 80mm - Max. bar capacity: 65mm - Spindle nose: A2-6 - Max. chucking diameter: 165mm - C-Axis 0,001 ° Subspindle: - max. spindle speed: 5000rpm - power capacity - Sub spindle 11 / 7,5 kW - spindle bearing diameter: 90mm - spindle bore: 63 mm - max. bar capacity: 51mm - spindle nose: A2-5 - max. chucking diameter: 165mm - C-Axis: 0,001 ° - Traverses Subspindle: 760mm Upper Turret 1: - number of toolpositions: (2x 12) 24 pos. - Number of driven toolspositions: 12 pos - Shank diameter: 25mm - Drill sha ...

Specifications: Control: Fanuc 0i-TD Hours: 12009 Capacity: - Swing over bed: 970mm - Swing over cross slide: 600mm - Centre height: 490mm - Width of carriage: 885mm - Width of cross slide: 350mm - Distance between centers: 4300mm - Width of bed: 560mm Headstock: - Chuck size: 605mm - Spindle bore: 153mm - Spindle nose: A2-11 - Spindle speed: 6.5 ~ 600rpm - Spindle power: 22/26kW Turret: - Tool size: 32mm - 4 positions Tailstock: - Quill diameter: 165mm - Quill traverse: 200mm - Tailstock center: MT#6 - Body movement: motorized Machine is equipped with: - 2 chip conveyors - Motorized tailstock body - Steady rest - Tooling as showed in pictures - Auction-ID: A1-45752-7

greates pass round over bed: 350 mmswing diameter over face slide: 200 mmcentre distance: 800 mmcentre height: 175 mmturning length: 700 mm3-jaw chuck: Röhm Ø 160 spindle bore: 46 mmspindle head: Gr. 5, DIN55027 number of spindle speeds: 18 spindle turning speed range: 31,5-2500 U/mintailstock quill taper MT: 3 weight of the machine ca.: 1000 kg3-axis digital readoutmanual includedThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Machine is equipped with: - chip conveyor - renishaw probe system Auction-ID: A1-45752-13
