mandriladoras e centros de usinagem usadas para venda (3,216)

CONTROLS  CNC controls WORKING RANGE -CUBIC-  number of processing axes (excl parallel axes): 3   X-axis travel: 1040 mm  Y-axis travel: 510 mm  Z-axis travel: 640 mmTABLE  table surface (left-right): 1460 mmSPINDLE / HEAD  spindle revolutions (max): 7000 /minTOOL MAGAZINE  number of positions: 24 ELECTRICAL SPECIFICATIONS  mains voltage: 400 V  mains frequency: 50 Hz

CONTROLS  CNC controls HELLER UNI-PRO CNC 90 WORKING RANGE -CUBIC-  number of processing axes (excl parallel axes): 4   X-axis travel: 1250 mm  Y-axis travel: 1000 mm  Z-axis travel: 1250 mmTABLE  table surface (left-right): 1000 mm  table surface (front-back): 800 mmSPINDLE / HEAD  tool fixture: ISO SK 50 AUTOMATIC WORKLOAD EQUIPMENT  store type: pallet changer   number of store positions: 2 DIMENSIONS / WEIGHTS  total weight approx.: 26500 kgATTACHMENTS  European CE standards: yes Machine in very good condition. DismantledStill available for sale:HELLER MCP-H 250 HS 1997DECKEL MAHO FP5-80 1994HELLER MCP-H 200 1998

CONTROLS  CNC continuous-path control 3D MILLPLUS IT V600 WORKING RANGE -CUBIC-  number of processing axes (excl parallel axes): 3   X-axis travel: 500 mm  Y-axis travel: 450 mm  Z-axis travel: 400 mmTABLE  table surface (left-right): 700 mm  table surface (front-back): 500 mm  workpiece load (max): 500 kgSPINDLE / HEAD  spindle revolutions (min): 20 /min  spindle revolutions (max): 10000 /min  tool fixture: ISO SK 40   drive power: 13 kWAXIS DRIVES  traverse velocity X (max): 24000 mm/min  traverse velocity Y (max): 24000 mm/min  traverse velocity Z (max): 24000 mm/minTOOL MAGAZINE  number of positions: 30   tool diameter max.: 80 mm  - with free neighbour positions: 130 mm  tool length max.: 300 mm  tool weight max.: 6 kg  tool changing time: 8 sATTACHMENTS  European CE standards: yes No cooling system; the machine is connected to a central c ...

CONTROLS  CNC controls SIEMENS SOLUTION LINE WORKING RANGE -CUBIC-  number of processing axes (excl parallel axes): 3   X-axis travel: 600 mm  Y-axis travel: 560 mm  Z-axis travel: 510 mmTABLE  table surface (left-right): 900 mm  table surface (front-back): 560 mm  workpiece load (max): 600 kgSPINDLE / HEAD  spindle revolutions (min): 20 /min  spindle revolutions (max): 12000 /min  tool fixture: ISO SK 40   drive power S6 40%: 13 kW  drive power S1 100%: 9 kW  spindle torque S6 40%: 82 Nm  spindle torque S1 100%: 54 NmAXIS DRIVES  traverse velocity X (max): 20000 mm/min  traverse velocity Y (max): 20000 mm/min  traverse velocity Z (max): 20000 mm/min  rapid traverse X: 30000 mm/min  rapid traverse Y: 30000 mm/min  rapid traverse Z: 30000 mm/minTOOL MAGAZINE  number of positions: 30   tool diameter max.: 80 mm  - with free neighbour position ...

CONTROLS  CNC controls HELLER UNI-PRO CNC 90 WORKING RANGE -CUBIC-  number of processing axes (excl parallel axes): 4   X-axis travel: 800 mm  Y-axis travel: 800 mm  Z-axis travel: 710 mmTABLE  table surface (left-right): 630 mm  table surface (front-back): 500 mmSPINDLE / HEAD  spindle revolutions (max): 12000 /minAUTOMATIC WORKLOAD EQUIPMENT  store type: pallet changer   number of store positions: 2 ATTACHMENTS  chip conveyor: yes   European CE standards: yes Machine in production, under powerStill available for sale:HELLER MCS-H 400 2001DECKEL MAHO FP5-80 1994HELLER MCP-H 200 1998

CONTROLS  CNC controls GRUNDIG DIALOG 12 WORKING RANGE -CUBIC-  X-axis travel: 800 mm  Y-axis travel: 550 mm  Z-axis travel: 500 mmSPINDLE / HEAD  spindle revolutions (max): 5000 /min  tool fixture: ISO SK 40 DIMENSIONS / WEIGHTS  total weight approx.: 4500 kgThe machine needs a new control card (price €2,000).

CONTROLS  CNC controls HEIDENHAIN ITNC 530 BASIC DESIGN  basic design: moving column WORKING RANGE -CUBIC-  number of processing axes (excl parallel axes): 5   X-axis travel: 3000 mm  Y-axis travel: 1000 mm  Z-axis travel: 1100 mmTABLE  table surface (left-right): 3000 mm  table surface (front-back): 1035 mmSPINDLE / HEAD  tool fixture: HSK A63 TOOL MAGAZINE  tool manipulator: change gripper ELECTRICAL SPECIFICATIONS  mains power supply: 60 kVA  mains voltage: 400 V  mains frequency: 50 HzDIMENSIONS / WEIGHTS  space requirements -left/right-: 14000 mm  space requirements -front/back-: 3760 mm  total height: 3770 mm  total weight approx.: 24000 kgATTACHMENTS  tool breakage detector: yes   zero-point workholding system: yes   chip conveyor: yes   band filtration unit: yes   closed cabin: yes   European CE standards: yes

CONTROLS  CNC controls FANUC 310 IS WORKING RANGE -CUBIC-  number of processing axes (excl parallel axes): 5   X-axis travel: 600 mm  Y-axis travel: 410 mm  Z-axis travel: 460 mm  rotating range A-axis from: -30 °  rotating range A-axis up to: 120 °TABLE  clamping surface diameter: 350 mmSPINDLE / HEAD  spindle revolutions (max): 12000 /min  drive power: 18 kWAXIS DRIVES  rapid traverse: 4800 mm/minTOOL MAGAZINE  number of positions: 30 DIMENSIONS / WEIGHTS  space requirements -left/right-: 3000 mm  space requirements -front/back-: 2400 mm  total height: 1980 mm  total weight approx.: 7500 kgOperating hours: 35`000hInklusieve: Vices see picture

CONTROLS  CNC controls FANUC 18 MB WORKING RANGE -CUBIC-  number of processing axes (excl parallel axes): 4   .. among of them simultaneous CNC axes: 3   X-axis travel: 900 mm  Y-axis travel: 800 mm  Z-axis travel: 980 mm  rotating range B-axis from: 0 °  rotating range B-axis up to: 360 °TABLE  table surface (left-right): 630 mm  table surface (front-back): 630 mm  workpiece load (max): 1200 kgSPINDLE / HEAD  spindle type: horizontal   spindle revolutions (max): 10000 /minAXIS DRIVES  rapid traverse: 50000 mm/minTOOL MAGAZINE  number of positions: 140 AUTOMATIC WORKLOAD EQUIPMENT  store type: table changer   number of store positions: 2 ELECTRICAL SPECIFICATIONS  mains voltage: 400 V  mains frequency: 50 HzDIMENSIONS / WEIGHTS  total weight approx.: 19000 kgATTACHMENTS  chip conveyor: yes   coolant unit: yes   band filtration unit: yes   ...
